Task Force AP-PW1450-ZE01 Operating Instructions Manual

1450psi electric pressure washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

1450PSI ELECTRIC PRESSURE WASHER
ITEM: 248901
MODEL NO.: AP-PW1450-ZE01
CAUTION !
BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY
AND RETAIN IT FOR FUTURE REFERENCE.
IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS
BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE
TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY.
SEE PAGE 10 FOR WINTERIZING PROCEDURE.
QUESTIONS, PROBLEMS, MISSING PARTS?
Before returning to your retailer, visit our website or call our customer service at
www.activeproducts.com / 1-866-990-9918
PURCHASE DATE: _______________ SERIAL#: ___________________________________
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT.
WARRANTY REGISTRATION BY INTERNET, WWW.ACTIVEPRODUCTS.COM.
TM
TM
US
PW1450-ZE01_12/2006_REV.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-PW1450-ZE01 and is the answer not in the manual?

Questions and answers

Related Manuals for Task Force AP-PW1450-ZE01

Summary of Contents for Task Force AP-PW1450-ZE01

  • Page 1 1450PSI ELECTRIC PRESSURE WASHER ITEM: 248901 MODEL NO.: AP-PW1450-ZE01 CAUTION ! BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE REFERENCE. IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Technical specifications ............Precautions .

  • Page 3: Precautions

    IMPORTANT PRECAUTIONS - READ FIRST! Safety Warnings When using this product, basic precautions The Trigger Gun Safety Lock prevents the • should always be followed: trigger from accidentally being engaged. This safety feature does not lock trigger in the Read all the instructions before using the •...

  • Page 4: Safety Features And Electrical Power Information

    SAFETY FEATURES AND ELECTRICAL POWER INFORMATION The pressure washer is equipped with a stop Extension Cords device that will sense when the trigger on the gun If possible, do not use extension cords with this is released. It will open the power circuit to the motor product.

  • Page 5: Replacement Parts And Diagram

    REPLACEMENT PARTS AND DIAGRAM CORNER ITEMS: 8 USER MANUAL 9 NEEDLE Parts List Item no. Quantity Part Name Parts No. Water filter ZE01-000-0003 Quick-connect coupling & inlet adaptor ZE01-050-0000 Gun assembly ZE01-090-0001 High-pressure hose ZE01-090-0002 Adjustable wand ZE01-090-0003 Turbo wand ZE01-090-0004 Gun/wand holder ZE01-000-0001...

  • Page 6: Assembly And Operating Instructions

    ASSEMBLY AND OPERATING INSTRUCTIONS Assembly Time: 2 minutes / Tools Required: None Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects which could create a hazard. Remove from the workarea which could be tripped over, such as toys or outdoor furniture. Ensure that all doors and windows are closed tight.
  • Page 7 ASSEMBLY AND OPERATING INSTRUCTIONS – continued Fig. 4 Step 4 Attach the high-pressure hose to the water outlet. Twist tightly to avoid leakage. Fig. 5 Fig. 6 Step 5 Step 6 Attach garden hose to water supply and turn Plug the unit into an outlet. Press “TEST”. water on.
  • Page 8 ASSEMBLY AND OPERATING INSTRUCTIONS – continued Fig.7 Step 7 Before turning the unit ON, depress the trigger to bleed any trapped air out of the pump and hose. Fig.8 Step 8 Start the pressure washer by turning ON/OFF switch to ON.

  • Page 9: Using The Accessories

    USING THE ACCESSORIES Fig. 9 Adjusting The Spray Caution The adjustable spray nozzle can be adjusted Jet spray adjustment is very aggressive. Do from fan to jet. The spray is adjusted from jet not adjust while spraying. We recommend to fan spray by turning the nozzle as shown that for most cleaning applications a 20º...

  • Page 10: Working With Detergent

    WORKING WITH DETERGENTS Using the detergent Important notice To enhance the efficiency of the pressure washer, When you have finished using detergent, always sometimes it is necessary to use detergents to follow the “Cleanup Instructions”. Failure to help loosen tough dirt and grime. clean properly will cause the injection system to become clogged and inoperable.

  • Page 11: Taking A Break

    SHUTTING DOWN AND CLEANING UP Step 1 Step 4 Turn the switch to “OFF” (0) position and Disconnect the garden hose from the water unplug cord from outlet. inlet on the unit. Step 2 Step 5 Turn off the water supply. Disconnect the the high-pressure hose from the high-pressure outlet and engage the gun Step 3...

  • Page 12: Winterizing And Long-Term Storage

    WINTERIZING AND LONG-TERM STORAGE Optimum Winterizing Procedure Alternative Procedure Material required: Pump saver If you cannot perform the Optimum Winterizing procedure, you can still protect your pressure Winterizing your pressure washer will help washer from winter-damage: protect and prolong its life. It is strongly recom- mend you follow the below steps using a pump Disconnect all water connections.
  • Page 13 USER MAINTENANCE Connections Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated with non-water soluable grease. Fig.12 Fig.13 Adjustable Nozzle Water Filter Screen When the nozzle is clogged, it will cause the The pressure washer is equipped with a water pump to build pressure and may cause the unit inlet filter that prevents debris going into the to surge.

  • Page 14: Troubleshooting

    TROUBLESHOOTING Symptom Cause Solution Motor will GFCI needs to be reset. Press RESET button on the GFCI. not start. On/Off switch is in the Turn switch to the “ON” ( | ) position. “OFF” (O) position. Power cord is not plugged in. Plug in power cord.
  • Page 15 TROUBLESHOOTING – continued Symptom Cause Solution Garden hose Loose fittings. Tighten fittings. connection leaks. Missing/worn rubber washer. Insert new washer. Spray wand, or Spray nozzle not properly attached. Insert the spray nozzle into the trigger extension, or gun. Carefully press in against the nozzle leaks.
  • Page 16 WARRANTY LIMITED 1 YEAR WARRANTY This pressure washer is warranted to be free of defects in materials and workmanship under normal residential use for one (1) year. Specific warranty applies to: • Electric motor and pump are warranted for one (1) year. •...
