- Page 1 Installation Installation Guide 2/4 port DVI Secure KVM GCS1212TAA / 1214TAA PART NO. M1191 / M1192...
-
Page 3: Table Of Contents
Table of Contents Conventions Package Content System Requirements Components Hardware Setup Operation Specifications Federal Communications Commission (FCC) Statement CE Compliance Technical Support Limited Warranty Contact... -
Page 4: Conventions
1 x Registration Form Verify all the components are present and that nothing was damaged in shipping. If you encounter a problem, contact your dealer, or IOGEAR. Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any... -
Page 5: System Requirements
System Requirements Console: • DVI monitor • USB keyboard and mouse • Speakers and microphone Computer: • DVI port - Single or Dual Link DVI video card • Type “A” USB port *Dual Link DVI-D USB 2.0 KVM Cables sold separately (G2L7D02UD, G2L7D03UD, G2L7D05UD) Operating Systems: •... -
Page 6: Components
4-Port Dual-Link DVI Rear View Note: The GCS1214TAA has been used in these illustrations. The front and rear panels of the GCS1212TAA and the GCS1214TAA are the same, except the GCS1212TAA has two ports/port selection pushbuttons and the GCS1214TAA has four. - Page 7 - Pressing a Port Selection Pushbuttonbrings the focus to the computer attached to its corresponding port. Reset Button- Press this to reset the GCS1212TAA / GCS1214TAA to the default settings. Console Audio Ports- The cables from your main speakers and main microphone plug in here. The speakers and microphone plugged in here have priority over those in the rear panel.
-
Page 8: Hardware Setup
To prevent damage to your installation it is important that all devices are properly grounded. Use a grounding wire to ground the GCS1212TAA / GCS1214TAA by connecting one end of the wire to the grounding terminal, and the other end of the wire to a suitable grounded object. - Page 9 Check that the USB seal is still attached to the CAC reader port to prevent unintended usage. Plug the female end of the power cord into the GCS1212TAA / GCS1214TAA’s power socket; plug the male end into an AC power source.
- Page 10 Installation Diagram...
-
Page 11: Operation
KVM. Port ID Numbering Each KVM port on the GCS1212TAA / GCS1214TAA is assigned a port number (1–2 for the GC- S1212TAA; 1–4 for the GCS1214TAA). The port numbers are marked on the rear of the switch. See Rear View, page 6. -
Page 12: Specifications
Specifications Function GCS1212TAA GCS1214TAA Computer Connections Port Selection Pushbutton Connectors Console Keyboard 1 x USB Type-A F (Black) Video 1 x DVI-I Dual Link F (White) Mouse 1 x USB Type-A F (Black) Audio Speaker 2 x Mini Stereo Jack F (Green;1 x front panel,1 x... - Page 13 Function GCS1212TAA GCS1214TAA Power Consumption 120V / 5.1W; 120V / 6.1W; 230V / 5.1W 230V / 5.7W Environment Operating Temp. 0–40ºC Storage Temp -20–60ºC Humidity 0–80% RH, Non-condensing Physical Housing Metal Properties Weight 3.85 Lbs 4.00 Lbs Dimensions (L x W x H)
-
Page 14: Federal Communications Commission
Electromagnetic Capability (89/336/EMC), Low Voltage (73/23/EEC) and R&TTED (1999/5/EC). Technical Support If you need technical support, please check out our IOGEAR Tech Info Library (T.I.L.) at www.iogear.com/ support for the latest tips, tricks, and troubleshooting. The IOGEAR T.I.L. was designed to provide you with the latest technical information about our products. -
Page 15: Limited Warranty
