INSTALLATION FOR 6 & 8 SENSORS
MAIN BOX
Reversing
Stop
light
light
DISPLAY
CISBO RADER SYSTEM USER'S MANUAL
INSTALL ON THE FRONT BUMPER
4 SENSORS
INSTALL ON THE BACK BUMPER
1. This diagram only for 6 and
8 sensors(Front and back).
2. The front sensors begin to
work while the car onbrake
Time.
3. The back sensors begin
work while the car on
Reversing time.
4. The display such as LED
display, LCD display, only
Buzzer, rear view mirror,
detail see Page3.
5.Power line guide:
Reversing light: Power on
while the car on reversing
time.
Stop light: power on while
brake.
