PART
1.
Display: Back vision display, distance numeric display, buzzer alarm circuit , etc ,
normally set inside the driving room.
2. Control unit: MCU control circuit, normally set inside the trunk, nearby the
backup lights.
3. Sensor: .Ultrasonic sensor "electronic eye", is the transmisson center for detecting
signals and normally set at the rear or front of bumper.
4.Camera: input the video signal, normally be set in the rear bumper.
5. Mobile phone hands free system: Be set inside the rear view mirror, connected with
the mobile, bring convenience and safety during circumstance.
TECH DATA
1. Rated voltage :
2. Power :
3. Working temperature:
4. Detecting distance:
5. Detecting angle:
6. Radio frequency:
7. Camera angle:
CISBO RADER SYSTEM USER'S MANUAL
2
DC12V (24v available)
3.6W
-20 C---70 C
0.3-2.0M
H>60 ,V>60
315MHz/433MHz
92 or 120
