Installation, Operating and
Servicing Instructions
Prestige Solo
Prestige AquaSpeed
Prestige Excellence
EN • 1
MK2
24 - 32
24 - 32
24 - 32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solo 24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Prestige Solo 24

  • Page 1 Prestige Installation, Operating and Servicing Instructions Prestige Solo 24 - 32 Prestige AquaSpeed 24 - 32 Prestige Excellence 24 - 32 EN • 1...
  • Page 2: Table Of Contents

    Distances of hydraulic connections INSTALLATION Connection to the chimney Domestic hot water connection : Prestige Solo Domestic hot water connection : Prestige AquaSpeed / Excellence Connection to the gas Heating connections Installation of simple heating circuit controlled by room thermostat ACV 15...
  • Page 3: Warning

    WARNINGS WHO SHOULD READ THESE INSTRUCTIONS • The parts may only be replaced by genuine factory parts. You will find a list of the spare parts and their reference number These instructions should be read by: ACV to the end of this document. - the specifying engineer - the installer •...
  • Page 4: Introduction

    BURNER above 60°C. ACV uses its BG 2000-M burner for the Prestige: this is an air/gas premix burner providing safe and silent operation while - Exceptional resistance against corrosion and aggression: limiting emissions (NOx and CO) to an incredibly low level.
  • Page 5 INTRODUCTION PRESTIGE AQUASPEED Chimney connection [concentric tubes Ø 80/125 mm] Tappot 6 litres Burner, premix and modulating [not available on Prestige Solo] Heat exchanger, stainless steel Pump, Domestic Hot Water Pump, central heating Electrical panel [The control boxes on the rear are optional]...
  • Page 6: Users Guide

    USERS GUIDE DIRECTIONS FOR USE Setting the domestic hot water temperature Your system must be checked once a year by an approved (Hot water temperature) installer or maintenance company. - Press Mode: The screen displays PARA. - Press Step: the first character is 1 and the last two characters give the current hot water temperature setting.
  • Page 7: Technical Characteristics

    TECHNICAL CHARACTERISTICS NATURAL GAS MODEL Solo AquaSpeed Excellence Central heating Max. Input 80/60°C Min. Input 80/60°C Max. output 80/60°C 23,4 23,4 23,4 Min. output 80/60°C Effi ciency 30% load [EN677] Flue gases CO emissions max. / min. Input mg/kWh 45 / 20 52 / 20 45 / 20 52 / 20...
  • Page 8: Propane Model

    TECHNICAL CHARACTERISTICS PROPANE MODEL Solo P AquaSpeed P Excellence P Central heating Max. Input 80/60°C 30,5 30,5 30,5 Min. Input 80/60°C Max. output 80/60°C 23,4 29,6 23,4 29,6 23,4 29,6 Min. output 80/60°C Effi ciency 30% load [EN677] Flue gases Flue gas pipe - Max.
  • Page 9: Natural Gas Categories

    B = Pressure available (for the heating circuit) circulator on 1 C = Pressure available (for the heating circuit) circulator on 2 A = Pressure drop on the domestic hot water side Prestige AquaSpeed D = Pressure available (for the heating circuit) circulator on 3...
  • Page 10: Installation Instructions

    101,6 mm 101,6 mm 48,4 mm 53,2 mm prestige - The boiler must be mounted on a non-flammable wall. - Drill two 10 mm diameter holes, spaced as indicated on the above drawing. - Secure the wall-mount bracket with the delivered anchor screws.
  • Page 11: Distances Of Hydraulic Connections

    With Kit DHW 10800079 D. Return from the water heater 1” [F] - with Kit DHW 10800079 E. Gas connection 3/4” [M] prestige C / D / E A / B DISTANCES OF HYDRAULIC CONNECTIONS : AQUASPEED A. CH supply 1” [F] B.
  • Page 12: Installation

    Ø 80/125 Ø 80 Ø 80 - The Prestige has an inbuilt gas/air ratio regulator, which makes it largely independent of the pressure drop in the air intake and flue gas extraction system. However, the maximum pressure drop for this system may not be exceeded, or the pressure will 1 m straight pipe diminish.
  • Page 13: Domestic Hot Water Connection : Prestige Solo

    Optional accessories Code Description prestige Domestic hot water hydraulic kit Kit to connect a Prestige Solo boiler to an external water heater. The kit includes : - one circulator - one NTC sensor 12kΩ (L = 3,2 m) - one check valve...
  • Page 14: Domestic Hot Water Connection : Prestige Aquaspeed / Excellence

    CONNECTION TO THE GAS - The Prestige is fitted with a 3/4” male fitting connector, on which you can connect the gas tap. - Drain the gas pipe and check in minute detail that all the - You must comply with the applicable regulations (e.g.
  • Page 15: Heating Connections

    Make depending on needs or if the pipes are noisy. sure you prevent the freezing of the condensates. - The wall frames of the Prestige AquaSpeed and Solo are fitted with an integrated 12-litre expansion vessel. HEATING CONNECTIONS : GENERAL 1.
  • Page 16: Optional Accessories

    INSTALLATION INSTALLATION OF A SIMPLE HEATING CIRCUIT CONTROLLED BY ROOM THERMOSTAT ACV 15 AF120 ACV 15 General diagram MCBA The On/Off room thermostat controls the central heating system (radiators or convectors). If an outside temperature sensor is connected, the boiler continuously adjusts its operating temperature depending on the outside temperature.
  • Page 17 INSTALLATION INSTALLATION OF A SIMPLE HEATING CIRCUIT CONTROLLED BY ROOM UNIT AF120 Room Unit General diagram MCBA A Room Unit controls the heating system (radiators or convectors). The unit allows the selection various central heating functions and can be programmed for up to 3 schedules per week, both for heating and hot water production.
  • Page 18 INSTALLATION INSTALLATION OF TWO HEATING CIRCUIT CONTROLLED BY ROOM THERMOSTAT ACV 15 AF120 AND AM3-11 MODULE ACV 15 MCBA General diagram AM3 - 11 This is a simple way to control two heating circuits (radiators or floor heating). You can adjust those two circuits depending on the outside temperature.
  • Page 19 INSTALLATION To be wired in accordance with the applicable regulations. Factory typical Factory typical setting setting Description setting setting Description 00 : Heating mode “OFF” Maximum temperature of the 01 : Heating mode “ON” second heating circuit Setting T° for the heating water Minimum temperature of the second (adjustable between 30 and 85°C).
  • Page 20 INSTALLATION INSTALLATION OF TWO HEATING CIRCUIT CONTROLLED BY CONTROL UNIT AND AF120 ZMC-1 MODULE Room Unit MCBA General diagram ZMC1 This configuration controls two heating circuits (radiators or floor heating). In addition, the Room unit features a remote monitoring of the two circuits You can adjust those two circuits depending on the outside temperature.
  • Page 21 INSTALLATION To be wired in accordance with the applicable regulations. AV MPK ZU AUF ZMC1 0 24V A B VF VE 10800036: Interface address “0” Factory typical setting setting Description 00 : Heating mode “OFF” 01 : Heating mode “ON” Setting T°...
  • Page 22: Electrical Connection

    ELECTRICAL CONNECTION EN • 22...
  • Page 23: Commissioning And Maintenance

    Prestige excellence: purge the primary circuit of the tank by - Check that the siphon is not fouled, fill it, if need be, and check means of the manual air vent on the top of the tank.
  • Page 24: Disassembling The Burner

    COMMISSIONING AND MAINTENANCE DISASSEMBLING THE EXCHANGER DISASSEMBLING THE BURNER - Drain the water from the central heating system using the - Close the inlet gas valve. connection under the appliance. - Remove the front panel of the boiler. - Allow the appliance to drain completely. - Unplug the fan plugs (24 Volt), the ignition cable, the gas valve - Dismantle the electrical connections downstream from the control and the ignition electrode earth.
  • Page 25: Mcba Parameters For The Specialist

    MCBA PARAMETERS FOR THE SPECIALIST STANDBY MODE Once the cause of the blockage has been resolved, the burner starts automatically within 150 seconds at most. Standby Mode Status Boiler function After you power down the appliance the screen displays Pilot Internal check —...
  • Page 26 MCBA PARAMETERS FOR THE SPECIALIST SETTING THE MCBA PARAMETERS Parameter Mode To access Parameter mode when the system is in Pilot mode, press MODE once. To scroll through the list of parameters, simply press “step”. To modify a parameter value, use the + or - keys. Then press “Store”...
  • Page 27: Request For Information On The Installation

    MCBA PARAMETERS FOR THE SPECIALIST REQUEST FOR INFORMATION ENTERING THE CODE ON THE INSTALLATION Code Mode Info Mode You can access the following parameters by entering the service code: To switch from Standby to Info mode, press Mode twice. • Parameters 5 - 42 Screen •...
  • Page 28: Mcba Parameters With Code Restricted Access

    Blockage T 0 = Disabled STEP Acceleration time lag 00 = Stop [minute] STEP Night set back heating (°C) STEP Prestige 32 natural gas Prestige 24 Maximum number of fan natural gas revolutions in CH mode Prestige 32 [rpm x 100]...
  • Page 29 MCBA PARAMETERS FOR THE SPECIALIST Factory setting Screen Description of parameters Solo AquaSpeed Excellence Prestige 32 natural gas Prestige 24 Max. number of revs natural gas in domestic hot water mode [rpm x 100] Prestige 32 STEP propane Prestige 24...
  • Page 30 MCBA PARAMETERS FOR THE SPECIALIST Factory setting Screen Description of parameters Solo AquaSpeed Excellence Central Heating modulation hysteresis enabled STEP Central Heating modulation hysteresis disabled STEP Domestic hot water modulation hysteresis enabled STEP Domestic hot water modulation hysteresis disabled STEP Detection of domestic hot water hysteresis enabled STEP...
  • Page 31 MCBA PARAMETERS FOR THE SPECIALIST Factory setting Screen Description of parameters Solo AquaSpeed Excellence First position: Domestic hot water pump [1] or three-way mixer tap [2] Second position: STEP tank with NTC3 probe [2] or tank with thermostat (3) Manual fan number of revolutions STEP First position: Fan control pump level during burning in...
  • Page 32: Communication Mode

    MCBA PARAMETERS FOR THE SPECIALIST COMMUNICATION MODE [with code] ERROR MODE [with code] When in this mode, the system displays the communication ERROR mode indicates the most recent error, as well as the between the boiler and the control module, the optional interface status of the boiler and its readings at the time this error kit or the optional programmable room thermostat.
  • Page 33 MCBA PARAMETERS FOR THE SPECIALIST SAFETY STOP [ERROR mode] To unlock the system: • Press RESET on the screen. If a fault occurs while the appliance is running, the system locks • Contact your installer if the fault happens again. and the screen starts to flash.
  • Page 34 MCBA PARAMETERS FOR THE SPECIALIST Codes Description of the fault Resolution of the fault - Check the connection of the NTC3 sensor - Check the wiring of the NTC3 sensor NTC3 short-circuit If the problem persists, replace the NTC3 sensor - Check the connection of the NTC1 sensor - Check the wiring of the NTC1 sensor NTC1 connection open...
  • Page 36 N° Horizontal Terminal Terminal Tereminale Waagerechte Muurdoorvoer oulet horizontal horizontal orizzontale Wanddurchführung Vertical Terminal Terminal Terminale Senkrechte Dakdoorvoer outlet vertical vertical verticale Dachdurchführung Flue pipe Conduite Rookgaspijp Tubo Prolunga Rohr L 250 mm L 250 mm L 250 mm L 250 mm L 250 mm L 250 mm Flue pipe...
  • Page 37 01 : 537D6185 10 : 537D6193 06 : 537D6189 11 : 537D6232 02 : 537D6184 07 : 537D6190 12 : 537D6195 13 : 537D6194 03 : 537D6186 04 : 537D6187 05 : 537D6188 08 : 537D6191 09 : 537D6192 14 : 537D6183...
  • Page 38 EN : NTC sensor [5 x 18 = 12 kΩ] Prestige Solo FR : Sonde NTC [5 x 18 = 12 kΩ] NL : NTC voeler [5 x 18 = 12 kΩ] Prestige AquaSpeed ES : Sonda NTC [5 x 18 = 12 kΩ] IT : Sonda NTC [5 x 18 = 12 kΩ]...
  • Page 39 EN : Transformer [230 Volt / 24 Volt] Prestige Solo FR : Transformateur [230 Volt / 24 Volt] NL : Transformator [230 Volt / 24 Volt] Prestige AquaSpeed ES : Transformador [230 Volt / 24 Volt] IT : Trasformatore [230 Volt / 24 Volt]...
  • Page 40 EN : Water pressure safety switch Prestige Solo FR : Pressostat de sécurité manque d’eau NL : Waterdruk schakelaar Prestige AquaSpeed ES : Presostato falta de agua IT : Pressostato di sicurezza mancanza d’acqua Prestige Excellence 557D3011 DE : Wassermangelsicherung EN : Safety valve [3 bars / Ø...
  • Page 41 MCBA- Brennersteuerung 5476G014 Prestige AquaSpeed 24 kW 5476G015 Prestige Excellence 24 kW 5476G016 Prestige Solo 24 kW 5476G017 Prestige AquaSpeed 24 kW [Propane - Propane - Propaan - Propano - Propano - Propangas] 5476G018 Prestige Excellence 24 kW [Propane - Propane - Propaan - Propano - Propano - Propangas]...
  • Page 42 N° Side panel Latérale Zijkanten Lateral Laterale Seitenblech Front panel Face avant Frontstuk Parte delantero Pannello anteriore Vorderblech Top cover Couvercle supérieur Bovenkap Tapa superior Coperchio superiore Obere Abdeckung Rear panel Panneau arrière Achterpaneel Panel trasero Pannello posteriore Hinterblech Control panel Tableau Paneel Panel...
  • Page 43 Prestige Solo / AquaSpeed A03 : 21475419 A01 : 21471419 A06 : 21480069 A04 : 21474419 A02 : 21473419 A01 : 21471419 A05 : 54761008 A09 : 2147E419 A10 : 21476419 Prestige Excellence A03 : 21475420 A01 : 21471420 A06 : 21480069...
  • Page 44 N° Flue gas pipe Tube de fumées Rookgas pijp Tubo de humos Condotto fumi Abgasrohr Ø 80mm Ø 80mm Ø 80mm Ø 80mm Ø 80 mm Ø 80mm Heat Echangeur Intercambiador Scambiatore Warmtewisselaar Wärmetauscher exchanger de chaleur de calor di calore Tubo de salida del Exchanger Tube de départ...
  • Page 45 Prestige Solo / AquaSpeed B01 : 497B0031 B07 : 507F4083 B03 : 507F4086 B08 : 507F4035 B09 : 507F4088 B02 : 63962009 B04 : 557A4014 B10 : 557A4014 B11 : 507F4089 B05 : 507F4087 B12 : 507F4052 B13 : 507F4053...
  • Page 46 C11 : 507F4096 C06 : 557A0048 C10 : 507F4095 C09 : 537DZ025 - 537DZ026 C07 : 51700061 C08 : 557A0058 Burner propane - Brûleur propane - Brander propaan Quemador propano - Bruciatore propano - Propangasbrenner Prestige Solo / AquaSpeed / Excellence...
