Prestige Solo 175 User's Information Manual

Prestige trimax solo series water boiler
Hide thumbs Also See for Solo 175:
Table of Contents

Advertisement

Quick Links

See also: Installation and Maintenance Manual
prestige
If the information in this manual is not followed exactly, a fire or explosion may
WARNING
result causing property damage, personal injury or loss of life.
•
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance
- Do not touch any electrical switch; do not use any phone in your building.
- Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
Revised 1/7/14
User s Information Manual
To maintain the safety & longevity
of your appliance read and follow
the maintenance schedule infor-
mation throughout this manual.
FOR YOUR SAFETY
WARNING
2011-58 Prestige User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Prestige Solo 175

Summary of Contents for Prestige Solo 175

  • Page 1 - Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. - If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 2011-58 Prestige User’s Manual Revised 1/7/14...

  • Page 2: Table Of Contents

    Table of Contents PRODUCT & SAFETY INFORMATION Page 1 Service and Maintenance PRESTIGE Operation Boiler & System Water SECTION I - Combustion Air - Prevention of Contamination Page 3 Potential Contaminating Products Areas likely to find these Products SECTION II - Maintenance Schedule...

  • Page 3: Product & Safety Information

    NFPA 720. combustion air inlet. See page 3 for details. • The PRESTIGE is equipped with a low water cutoff WARNING device. The boiler and system piping must be filled and pressurized to 12 psig prior to startup. The unit ACV-Triangle Tube accepts no liability for any dam- will shut down if the pressure falls below 10 psig.

  • Page 4: Boiler & System Water

    • Continual fresh makeup water will reduce the life of the PRESTIGE. Addition of oxygen can cause inter- nal corrosion in the system components. All leaks in the piping system must be repaired at once to pre- vent makeup water.

  • Page 5: Section I - Combustion Air - Prevention Of Contamination

    WARNING Hydrochloric acid / muriatic acid Cements and glues Do not operate a PRESTIGE unit if its combustion air inlet or the unit is located in or near a laundry room Antistatic fabric softeners used in clothes dryers or pool facility. These areas will always contain haz- Chlorine-type bleaches, detergents, and clean- ardous contaminates.

  • Page 6: Section Ii - Maintenance Schedule

    Additional items if combustion or performance is service and maintenance or follow the directions poor: in this manual could result in damage to the PRESTIGE or in system components, resulting Clean heat exchanger and flue ways. in severe personal injury, death or substantial property damage.

  • Page 7: Section Iii - Maintenance Procedures

    4. In addition flue exhaust openings. If removing the debris to this maintenance, the PRESTIGE should be serv- does not allow the unit to operate correctly, con- iced at the beginning of the heating season by a tact your qualified service technician to inspect qualified service technician.

  • Page 8: Monthly Maintenance

    Fig.1. WARNING Check Automatic Air Vents (If Used) Do not operate PRESTIGE without condensate drain 1. Remove the cap “A” from any automatic air vent assembly firmly installed on unit and filled with in the system and check operation by depressing water.

  • Page 9: 6-Month Maintenance

    This discharge line must be installed by a qualified service technician or heating / plumbing installer in accordance with the PRESTIGE installa- tion manual. The discharge line must be terminated so as to eliminate possibility of severe burns or property damage should the valve discharge.

  • Page 10: Section Iv - Operations Instructions

    Follow the gas supplier’s instructions. OPERATING INSTRUCTIONS STOP! Read the safety information above. This appli- Turn the service switch on the PRESTIGE control panel ance is equipped with an ignition device which auto- “ON”. matically lights the burner. DO NOT try to light the burn- Set room thermostat(s) to desired setting(s).

  • Page 11: Section V - Trimax Operation

    The TriMax Boiler Management System is designed to be flexible yet easy to use. TriMax monitors and controls the Prestige to provide heat as efficiently as possible. All TriMax features are easy to use through a graphical display where information is presented either graphically or in plain English, so code charts are not required.

  • Page 12: Trimax Menu Structure

    TriMax Operation TriMax Menu Structure Home Screen Main Menu CH/DHW Operation Menu Boiler Information Menu EZ Setup Menu Heating Enabled Boiler Information...

  • Page 13: Home Screen

    The Home Screen presents status information in a very user friendly way so that the current state of the boiler can be quickly accessed. The Prestige is represented in the center of the Home Screen. Basic operating information such as supply and return temperatures are displayed as well as current burner status.

  • Page 14: Status Line Messages

    The domestic circulator continues to operate and the burner will fire again once the supply/system water temperature drops below the setpoint. The central heating circulator is running to remove heat from the Prestige at the CH Post Pump completion of a call.

  • Page 15: Main Menu

    TriMax Operation Main Menu The Main Menu can be entered from the Home Screen by pressing the OK button. The menu system utilizes icons to represent each selection. The currently selected menu is displayed as a reversed image with a text description shown at the top of the display.
  • Page 16 The CH / DHW Operation Menu can be entered from the Main Menu by selecting the CH / DHW Operation icon and pressing the OK button. The CH / DHW Operation Menu provides a simple way to disable either the central heating or domestic hot water functions of the Prestige. CH/DHW Operation...

  • Page 17: Boiler Information

    TriMax Operation Boiler Information Boiler Information can be viewed by selecting the Boiler Information icon and pressing the OK button. Boiler Information provides real time operating information of the Prestige. Boiler Information Select Boiler Information Boiler Information Boiler Information displays six boiler readings at a time.

  • Page 18: Information Items

    Displays the number of domestic hot water ignitions since the unit was installed. DHW Ignitions This counter increases in increments of twenty. Displays the number of hours the Prestige has run for a domestic hot water call DHW Runtime since the unit was installed.

  • Page 19: Lockout History

    TriMax Operation Lockout History Lockout History can be viewed by selecting the Lockout History icon and pressing the OK button. The Lockout History Screen lists the last eight lockouts along with how long ago they occurred. Lockout History Select Lockout History Lockout History Lockout History displays the last eight lockouts.

  • Page 20: Lockout Screen

    The Lockout Screen replaces the Home Screen if a lockout occurs. The screen backlight will also illuminate con- stantly while the Prestige is locked out. Pressing any arrow button will return to the Home Screen so that addi- tional troubleshooting can be performed. See pages 19 and 20 for a list of lockouts and descriptions.

  • Page 21: Manual Reset Hard Lockouts

    TriMax Operation Manual Reset Hard Lockouts Code Lockout Message Description Failed Ignition The burner failed to light after 5 ignition attempts. False Flame A flame is being detected prior to ignition. High Boiler Temperature Boiler temperature has reached 210°F [99ºC] Blower is not at correct speed or speed signal is not being received by Blower Speed control module.

  • Page 22: Automatic Reset Soft Lockouts

    TriMax Operation Automatic Reset Soft Lockouts Code Lockout Message Description High Flue Temperature Flue temperature exceeds high limit. Internal Control Fault EEPROM misconfiguration Internal Control Fault CRC check error. DHW Sensor Shorted A short circuit has been detected in the DHW temperature sensor circuit. DHW Sensor Open An open circuit has been detected in the DHW temperature sensor circuit.

  • Page 23: Replacement Parts

    856-228-8881 or www.triangletube.com for tor. When ordering part please provide the list of distributors nearest you. model number and description and/or part number of replacement part. Use only gen- Fig. 3: PRESTIGE Solo 60/110 Jacket Components Item Part # Description PTJKT10R...
  • Page 24 Replacement Parts Fig. 4: PRESTIGE Solo 175/250 Jacket Components Item Part # Description PTJKT12R Rear Panel PTJKT08F Front Jacket Panel PTRKIT129 Control Enclosure Bezel PTJKT22S Side Jacket Panel (Left or Right) PTJKT17T Top Jacket Panel PTJKT20T Top Jacket Access Panel...
  • Page 25 Replacement Parts Fig. 5: PRESTIGE Solo 399 Jacket Components Item Part # Description PTJKT13R Rear Panel PTJKT09F Front Jacket Panel PTRKIT129 Control Enclosure Bezel PTJKT23S Side Jacket Panel (Left or Right) PTJKT16T Top Jacket Panel PSJKT06T Top Jacket Access Panel...
  • Page 26 Replacement Parts Fig. 6: PRESTIGE ExCELLENCE Jacket Components Item Part # Description PTJKT11R Rear Panel PTJKT09F Front Jacket Panel PTRKIT129 Control Enclosure Bezel PTJKT23S Side Jacket Panel (Left or Right) PTJKT15T Top Jacket Panel PTJKT19T Top Jacket Panel - Blower Access...
  • Page 27 Replacement Parts Fig. 7: PRESTIGE Solo 60 Internal Components Item Part # Description PTRKIT125 Heat Exchanger Body PTADPT07 Vent Outlet/ Combustion Air Inlet Adapter PTRKIT115 Polypropylene Vent Pipe PTRKIT122 Supply / Return Temperature Sensor PTRKIT123 Flue Temperature Sensor PGRKIT20 LWCO Pressure Device...
  • Page 28 Replacement Parts Fig. 8: PRESTIGE Solo 110 Internal Components Item Part # Description PTRKIT124 Heat Exchanger Body - Natural PTRKIT125 Heat Exchanger Body - Propane PTADPT07 Vent Outlet/ Combustion Air Inlet Adapter PTRKIT115 Polypropylene Vent Pipe PTRKIT122 Supply / Return Temperature Sensor...
  • Page 29 Replacement Parts Fig. 9: PRESTIGE Solo 175/250 Internal Components Item Part # Description PSRKIT25 Heat Exchanger Body Solo 175 PSRKIT26 Heat Exchanger Body Solo 250 PTADPT07 Vent Outlet/ Combustion Air Inlet Adapter PTRKIT116 Polypropylene Vent Pipe PTRKIT122 Supply / Return Temperature Sensor...
  • Page 30 Replacement Parts Fig. 10: PRESTIGE Solo 399 Internal Components Item Part # Description PSRKIT44 Heat Exchanger Body (30 PSI) PTRKIT128 Heat Exchanger Body (80 PSI) PTADPT08 Vent Outlet/ Combustion Air Inlet Adapter PTRKIT117 Polypropylene Vent Pipe PSRKIT47 Supply / Return Temperature Sensor...
  • Page 31 Replacement Parts Fig. 11: PRESTIGE Excellence Internal Components Item Part # Description PTRKIT124 Heat Exchanger Body - Natural PTRKIT125 Heat Exchanger Body - Propane PTADPT07 Vent Outlet/ Combustion Air Inlet Adapter PTRKIT118 Polypropylene Vent Pipe PTRKIT122 Supply / Return Temperature Sensor...
  • Page 32 Replacement Parts Fig. 12: PRESTIGE Solo 60/175/250 Burner Components Part # Part # Item PRESTIGE PRESTIGE Description Solo 60 Solo 175-250 PSRKIT09 PSRKIT30 Combustion Chamber Insulation PSRKIT11 PSRKIT31 Burner Head with Gasket PTRKIT114 PSRKIT13 Blower with Gasket PSRKIT12 PSRKIT32 Burner Plate...
  • Page 33 Replacement Parts Fig. 13: PRESTIGE Solo 110 / Excellence Burner Components Item Part # Description PSRKIT09 Combustion Chamber Insulation PSRKIT10 Burner Head with Gasket - Natural PSRKIT11 Burner Head with Gasket - Propane PTRKIT114 Blower with Gasket PSRKIT12 Burner Plate...
  • Page 34 Replacement Parts Fig. 14: PRESTIGE Solo 399 Burner Components Item Part # Description PSRKIT37 Combustion Chamber Insulation PSRKIT38 Burner Head with Gasket PSRKIT40 Blower with Gasket PSRKIT39 Burner Plate PSGSK17 Burner Plate Gasket (Not Shown) PTRKIT112 Gas Valve PSRKIT84 Venturi...
  • Page 35 Replacement Parts Fig. 15: PRESTIGE Control Enclosure Item Part # Description PTRKIT109 Pressure Gauge and Fitting (All except Solo 399) PTRKIT110 Pressure Gauge and Fitting (Solo 399) PTSWI01 Power Switch PTSWI02 Power Switch Cover PTRKIT108 Control Enclosure PTRKIT205 TriMax Control Module (Solo 60, 110 &175, Excellence) PTRKIT206 TriMax Control Module (Solo 250 &...
  • Page 36 Additional quality water heating equipment available from ACV- Triangle Tube Brazed Plate Heat Exchangers For domestic water, snow melting, radiant floor, refrigeration Plates made of stainless steel, with a 99.9 % copper and brazed, ensuring a high resistance to corrosion Self cleaning and self descaling Computerized sizing available from ACV-Triangle Tube Available in capacities from 25,000 BTU/hr to 5,000,000 BTU/hr...
