Summary of Contents for netsys NVF-200SE/PD KIT
- Page 1 ’ ’ ’...
-
Page 2: Copyright
National Enhance Technology Corp. hereby disclaims any and all warranties and liabilities of any kind, including without limitation warranties of non-infringement of intellectual property rights of any third party. - Page 3 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Foreword NVF-200SE system delivers power and IP connectivity at distances up to 1km (3,280ft) using existing or new copper twisted pair phone cable. These innovative transmission techniques result in power feeding and data over a single pair phone wire and are ideal for deploying extended Ethernet where there are no or limited electricity at one end.
-
Page 4: Safety Warnings
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. -
Page 5: Table Of Contents
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Table of Contents COPYRIGHT ................................ 1 SAFETY WARNINGS ............................3 TABLE OF CONTENTS ............................4 CHAPTER 1. UNPACKING INFORMATION ......................7 1.1 Check List ......................................7 CHAPTER 2. INSTALLING THE BRIDGE......................8 2.1 Hardware Installation..................................8 2.2 Pre-installation Requirements ................................8 2.3 General Rules ....................................9... - Page 6 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 3.1 NVF-200SE / NVF-200PD Detailed View .............................13 3.2 Front Panel....................................14 3.3 Front Indicators ....................................15 3.4 Rear Panel ....................................16 CHAPTER 4. ABOUT PERFORMANCE ......................18 4.1 Auto and manual data speed selector description:.........................18 4.2 Distance &...
- Page 7 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 WARRANTY ............................... 37 CHINESE SJ/T 11364-2006..........................38...
-
Page 8: Chapter 1. Unpacking Information
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the checklist. Package Contents: • 1 x NVF-200SE + 1 x NVF-200PD • 2 x 48V / 0.4A Power Adapter •... -
Page 9: Chapter 2. Installing The Bridge
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Chapter 2. Installing the Bridge 2.1 Hardware Installation This chapter describes how to install the bridge and establishes network connections. You may install the bridge on any level surface (e.g. a table or shelf). However, please take note of the following minimum site requirements before you begin. -
Page 10: General Rules
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 2.3 General Rules Before making any connections to the bridge, please note the following rules: • Ethernet Port (RJ45) All network connections to the bridge Ethernet port must be made using Category 5 UTP for 100Mbps, Category 3, 4 UTP for 10Mbps. - Page 11 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Figure2.1: NVF-200SE/PD line ports straight connection Figure 2.2: NVF-200SE/PD line ports crossover connection...
-
Page 12: Connecting The Line / Ethernet Ports
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 2.5 Connecting the Line / Ethernet Ports 1. The bridge’s line port supports max distance of 1km at 5M/5M or max speed of 25M symmetrically with distance up to 500m for data service across existing phone wiring. It is easy-to-use which do not require installation of additional wiring. - Page 13 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Notes: Be sure each twisted-pair cable (RJ-45) does not exceed 100 meters (328 feet). Line port must use 22 ~ 26 gauge phone wiring, we do not recommend 28 gauge or above. We advise using Category 3, 4, 5 cables for cable bridge or router connections to avoid any confusion or inconvenience in the future when you attached to high bandwidth devices.
-
Page 14: Chapter 3. Hardware Description
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Chapter 3. Hardware Description This section describes the important parts of the bridge. It features the front panel and rear connectors. 3.1 NVF-200SE / NVF-200PD Detailed View Figure 3.1: NVF-200SE detailed view Figure 3.2: NVF-200PD detailed view... -
Page 15: Front Panel
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 3.2 Front Panel The figure shows the front panel of both NVF-200SE and NVF-200PD. (Figure 3.3) Figure 3.3: Front Panel of NVF-200SE/PD At a quick glance of the front panel, it is easy to tell if the bridge has power, if it has signal from its Ethernet RJ-45 port, if it is either providing or receiving power and if there is line signal on the line port. -
Page 16: Front Indicators
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 3.3 Front Indicators The bridge has LED indicators. The following table shows the description. (Table 3-2) Table 3-2: LED Indicators Description and Operation LEDs Color Status Descriptions PWR (Power LED The system power is normal and functioning properly. Green For NVF-200SE only) The system power is not ready or has malfunctioned. -
Page 17: Rear Panel
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 3.4 Rear Panel The following figure shows the rear connectors. (Figure 3.4) Figure 3.4: Rear connectors of NVF-200SE/PD respectively At quick glance, you can see the DIP switch setting at default mode, where it is in auto-speed and interleave delay is set to 0ms as shown in (Figure 3.5). - Page 18 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Speed Mode config: To config the data speed to 25Mbps: Pin 2 must be switch ON while pin 1 is OFF. To config the data speed to 15Mbps: Pin 1 must be switch ON while pin 2 is OFF. To config the data speed to 5Mbps: Both pin 1 and pin 2 have to switch to ON.
-
Page 19: Chapter 4. About Performance
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Chapter 4. About performance 4.1 Auto and manual data speed selector description: NVF-200SE is a VDSL solution which supports real plug & play and can do auto and manual selection of the data speed, the setting of the data speed depends on the phone cable limit length, they can support 5M/15M/25Mbps symmetrical data service. -
Page 20: Distance & Power Relational Tables
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 4.2 Distance & power relational tables The table describes connect to a loading device of the output voltage of 12V, calculate the distance and the relationship between power consumption.(Table 4-1) Table 4-1: Distance & power relational tables Power Output Output... -
Page 21: Appendix A: Cable Requirements
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT. 3, 4 or 5 twisted pair cable is typically used to connect the Ethernet device to the bridge. A 10Base-T cable often consists of four pairs of wires, two of which are used for data transmission and the other two pairs are used for power transmission. - Page 22 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
- Page 23 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 A.2 Telephone wire Standard telephone wire of any gauge or type-flat, twisted or quad is used to connect the bridge to the telephone network. A telephone cable typically consists of three pairs of wires, one of which is used for transmission. The connector at the end of the telephone cable is called RJ-45 connector and it consists of eight pins.
-
Page 24: Appendix B: Ieee 802.3Af Pse And Powered Device Power Classifications
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Appendix B: IEEE 802.3af PSE and Powered Device Power Classifications Table B-1: IEEE 802.3af PSE and Powered Device Power Classifications Class Usage Minimum Power Levels Output at the PSE Maximum Power Levels at the Powered Device Default 15.4W 0.44 to 12.95W... -
Page 25: Appendix C: Product Specification
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Appendix C: Product Specification Key Features & Benefits • Supports Plug & Play (PnP) • Compliant with IEEE802.3 10BASE-T, IEEE802.3u, 100BASE-TX and IEEE802.3af Ethernet PD class 0, 1, 2, or 3 standards •... - Page 26 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Product Specifications IEEE802.3 10BASE-T standard IEEE802.3u 100BASE-TX standard Standard Compliant: IEEE 802.3af PoE standard ITU-G993.1 VDSL standard CE,FCC,VCCI EMC Compliant: Safety Compliant: EN60950 Environmental Protection RoHS Compliant: 1 x RJ-45 for fast Ethernet port with power injector (NVF-200PD only) Interface: 1 x RJ-45 for single pair VDSL line port 1 x Terminal block for VDSL line port...
- Page 27 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Power/Remote Power for system Link/Active Status for Ethernet port LED Indication: Remote Power Link good for POV Power link good for POE Line Speed for line port NVF-200SE Transmitter: 900 kHz ~ 3.9MHz Receiver: 4MHz &...
- Page 28 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Humidity: 10% to 90% (non-condensing) NVF-200SE: 146mm x 97mm x 33mm (5.75" x 3.82" x 1.30”) Dimensions: NVF-200PD: 169mm x 106mm x 33mm (6.65" x 4.17" x 1.30”)
-
Page 29: Appendix D: Troubleshooting
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Appendix D: Troubleshooting Diagnosing the Bridge’s Indicators The bridge can be easily monitored through its comprehensive panel indicators. These indicators assist the network manager in identifying problems that hub may encounter. This section describes common problems you may encounter and possible solutions. - Page 30 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 2.6 Make sure that the phone wire must be connected between NVF-200SE and NVF-200PD first, when both are to be power on. 2.7 Replace the defective bridge or cable if necessary. Bridge speed link cannot be established.
- Page 31 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 NVF-200PD PoE LED does not light up. 5. Symptom: The networking device connecting to the NVF-200PD does not follow IEEE802.3af PoE standards. Cause: Make sure that the networking device must conform to IEEE802.3af PoE standards. Also, Make Solution: sure that the networking device has embedded power splitter.
- Page 32 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 How can I establish the NVF-200PoV connection. 8. Question: When the equipment you want connect to NVF-200PD, please make sure the networking device has built-in power splitter(PD) function, if yes, please connect it directly, if not, please connect between NVF-200PD and networking device through a power splitter(PD side).
- Page 33 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section. However, if the unit power is off after running for a while, check for loose power connections, power losses or surges at the power outlet, and verify that the fan on back of the unit is unobstructed and running prior to shutdown.
- Page 34 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation do not exceed recommendations.
-
Page 35: Appendix E: Compliance And Safety Information
NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Appendix E: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC rules. - Page 36 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.
- Page 37 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 38 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Warranty The original owner that the product delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.
- Page 39 NVF-200SE/PD Power over VDSL Master/Slave USER’S MANUAL Ver. B.4 Chinese SJ/T 11364-2006 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○ ○ ○ ○ ○...
