1. Disarm the system with the remote control.
2. Transmit channel 15 on the master remote (LevelShift three times, then button 3). You will hear one chirp and the LED will turn on.
3. Test the Piezo Sensor's primary zone by thumping the window pillar firmly. You will hear a siren chirp when the primary zone is
triggered.
To change the sensitivity of the primary zone, press and release button 2 to increase sensitivity or button 4 to decrease sensitivity.
To rapidly increase or decrease several steps, press and hold the button. For each sensitivity increase, you will hear a higher and
higher pitched confirmation chirp. For each sensitivity decrease, you will hear a lower and lower pitched confirmation chirp. Two
LoudChirps indicate minimum and maximum settings of the 32-step range of settings. You may now press button 3 to adjust the
warning zone, or press button 1 to fully exit the Piezo Sensor adjustment mode (you will hear 3 chirps).
To change the sensitivity of the warning zone, press button 3 (you'll hear 1 chirp). Then use the same procedure as above, but this
time, thump the window pillar very softly. When done, press button 1 to reselect the primary zone (you will hear 2 chirps), then
button 1 again to fully exit Piezo Sensor adjustment mode (you will hear 3 chirps).
4. Repeat the preceding steps as required. An improperly adjusted sensor will cause the IntelliGuard 7000 to false alarm or not
respond properly to a genuine threat.
Re mote con trolled over ride of Optional Sen sor
Transmitting channel 10 on the master remote control (LevelShift button twice, then button 2), or pressing the
buttons on the companion remote, at any time while the system is armed will override the optional sensor. This comes in handy when
you must temporarily leave a pet or a passenger in the vehicle. The channel 10 optional sensor override is visually confirmed with 4
flashes of the parking lights. The sensor is automatically restored the next time you arm.
The system microprocessor automatically checks for another activated sensor or trigger before sounding the siren a second time, thus
preventing any further false alarms. If you wish to test FACT, simply:
1. Arm the IntelliGuard 7000 with the re mote con trol.
2. Wait 10 seconds after the interior light turns off, then trigger the Piezo Sensor to activate the siren.
3. Do not disarm the system, let the siren complete its cycle.
4. Attempt to trigger the sensor again. The alarm should be silent.
5. Unlock and open a door. The alarm should sound immediately. You may now disarm.
The system's nonvolatile memory records the identity of the last eight activated or malfunctioning triggers and sensors:
NOTE: The CliffNet Wizard dis plays the Eight- Event To tal Re call data in a graphi cal for mat.
1. With the ignition OFF, press and hold the unmarked side of the PlainView 2 Switch.
2. Use the remote control arm, and then again to disarm, and then release the button.
3. The LED will flash 1–10 times, pause, then flash 1–10 times, etc. Write down the number of flashes in each cycle.
4. Refer to the following chart. The first number you wrote down was the most recently activated trigger or sensor. The next number
is the second most recent, and so on up to as many as the last eight activations.
8

Sensor Adjustment

FACT—False Alarm Control and Test

Eight-Event TotalRecall

and
In tel liGuard 7000/199
