REFERENCE TO RELAY CODE AND ACTUATIONS - ESPRESSO / INSTANT VERSION
Espresso Configuration
RELAY
CODE
Three-way solenoid valve for
K 01
Espresso coffee
Coffee release magnet
K 02
K 03 Coffee grinder motor
K 04 Pump
K 05 Coffee brewer motor
K 06 Solenoid valve 2
K 07 Solenoid valve 1
K 08 Whipper 1
K 09 Sugar doser device
K 10 Doser device 2
K 11 Doser device 1
K 12 Water inlet solenoid valve
K 13 Cup stacker shift ratiomotor
K 14 Cup release ratiomotor
K 15 Stirrer dispensing motor
The control board can be configured for the different machine versions only via software settings.
See Software and Programming chapter
NECTA SPA TECHNICAL MANUAL "COLIBRÌ"
Service Manual: Colibrì
Application
Edition 02-2002
Instant Configuration
RELAY
CODE
Solenoid valve 3
K 01
Doser device 3
K 02
K 03 Whipper 2
K 04 Pump
K 05 Doser device 4
K 06 Solenoid valve 2
K 07 Solenoid valve 1
K 08 Whipper 1
K 09 Sugar doser device
K 10 Doser device 2
K 11 Doser device 1
K 12 Water inlet solenoid valve
K 13 Cup stacker shift ratiomotor
K 14 Cup release ratiomotor
K 15 Stirrer dispensing motor
Application
