Summary of Contents for Vinotemp VT-46TS-2Z
- Page 1 A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y D U A L - Z O N E W I N E C O O L E R V T - 4 6 T S - 2 Z ( 4 6 b o t t l e s ) O W N E R ’...
- Page 2 Y o u r W i n e C e l l a r This unit can be used for Storage and/or Service. The unit has a glass door and soft interior light to elegantly display your wine. S e r v i n g W i n e s Storing wines at the proper temperature is important.
- Page 3 Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged. Contact our customer service at 1-800-777-8466 or info@vinotemp.com. READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE -Save these instructions- 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1...
-
Page 4: Table Of Contents
Table of Contents IMPORTANT SAFETY INSTRUCTIONS ......5 ELECTRICAL CONNECTION ........6 PARTS AND SPECIFICATIONS ......... 7 INSTALLATION ............. 8 OPERATING YOUR WINE COOLER ......8 CARE AND MAINTENANCE ........10 TROUBLESHOOTING ..........12 TERMS OF SALE AND WARRANTY ......13 W W W . -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions: Do not operate this or any other appliance with a damaged cord. Do not operate if housing is removed or damaged. ... -
Page 6: Electrical Connection
ELECTRICAL CONNECTION Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, frayed or shows cracks or abrasions across its length, have it replaced at an authorized service center. For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding-type plug, and should be used in combination with a properly connected grounding-type outlet. -
Page 7: Parts And Specifications
PARTS AND SPECIFICATIONS Model No. VT-46TS-2Z Voltage AC 115/120V Frequency 60 Hz Ambient Temperature Range 60°- 90°F Control Temperature Range 40°- 72°F Refrigerant R134a/3.88oz Power Consumption 0.8kw.h/24h Input Power 100W Volume 428L Net Weight 103.4 LBS Gross Weight 114.4 LBS 23.625”... -
Page 8: Installation
INSTALLATION Remove all packing material before using your wine cooler. IMPORTANT: Before connecting the unit to a power source, let it stand upright for approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. - Page 9 LIGHT To control the inner light turn on/off. Used to raise (warm) the set temperature by 1°C or 1ºF. DOWN Used to lower (cool) the set temperature by 1°C or 1ºF. ºF/ºC Selector Select the temperature display setting in Fahrenheit or Celsius degree. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, touch and hold mark for 5 seconds.
-
Page 10: Care And Maintenance
STORING WINE While bottles may vary in size and dimension, approximately 46 traditional Bordeaux 750ml bottles can be stored in your wine cooler. You can place 16 standard bottles in the upper zone with 8 bottles on each shelf and 30 standard bottles in the lower zone with 8 bottles on each full size shelf and 6 bottles on each half size shelf. - Page 11 drip tray by the compressor where it evaporates. POWER FAILURE Most power failures are corrected within a few hours and should not affect the temperature of your appliance. If the power is off for an extended period of time, proper steps should be taken to protect your contents.
-
Page 12: Troubleshooting
TROUBLESHOOTING You can solve many common wine cellar problems easily, saving you the cost of a possible service call. Try the suggestion below to see if you can solve the problem before contacting Vinotemp at info@vinotemp.com. SYMPTOM POSSIBLE CAUSE Door will not close ... -
Page 13: Terms Of Sale And Warranty
TERMS OF SALE AND WARRANTY Vinotemp International (“Seller”) and the person or entity that acquires these goods from Seller (“Purchaser”) hereby fully agree to the following terms and conditions of the sale: Shipping fees are the responsibility of the Purchaser whether freight prepaid or freight collect. Seller assumes no responsibility for the goods sold to the Purchaser once the goods have left the Seller’s premises, including, but not limited to, late delivery by the... - Page 14 W W W . V I N O T E M P . C O M...
- Page 15 1 7 6 2 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1 i n f o @ v i n o t e m p .
- Page 16 Rancho Dominguez, CA 90221 www.vinotemp.com Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for errors, omissions, or future changes.
