Vfe 4C Hs Wfu Description + Spare Part Numbers - Thermal Arc Fabricator 250C III Operation Manual

11.05 VFE 4C HS III Wire Feed Unit Parts Description + Spare Part Numbers
Figure 30.
Pos Item No
FABV10001‐5
1
FABV10019‐2
2
FABV10004‐6
3
FABV10002‐3
4
FABV10006‐4
5
FABV10007‐4
6
FABVA0011‐4A
7
FABVA0004‐15
8
FABV10013‐3A
9
10 FABV0316
11 FABV10014‐2
12 FABV0317
13 FABV10015‐2
Title
VF E4C III Wire feed unit
Bottom galvanized WFU
PCB cover galvanized WFU
Barrier of connectors galvanized
Cover upper PS matt
Cover left Gloss
Cover right Gloss
Facia panel matt
Support vertical compact galvanized
Front panel matt
Corner Right
Corner support right galvanized
Corner Left
Corner support left galvanized
59
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
