Pipeline
Product Sheet
General Pipeline System

Setup Information

Pipeline system architecture
Pipeline is a unique network attached encoder system that can be used in a
variety of capture and playout workflows. Being network attached there are
several architectural constraints that need to be understood in order to
configure an efficient and reliable Pipeline system.
Pipeline system capture workflows consists of taking baseband HD/SD-SDI
inputs, compressing it, creating a file with the compressed data and delivering
the completed file to a folder location. The Pipeline system will consists of one
or more Pipeline network attached encoder devices connected via CAT6
Ethernet to a Pipeline host computer.
Pipeline network attached encoder devices should be connected directly via
CAT6 Ethernet to a Pipeline host computer or via a fully non-blocking
managed Layer 2/3 Enterprise Edge Ethernet switch with adequate per-port
data buffering.
Pipeline System
Because of Pipeline's unique network attached architecture it is important to
understand each component of a Pipeline system in order to create a system
that will meet the needs of your workflow.
A Pipeline System consists of one or more Pipeline channels and a Pipeline
host computer (Mac or Windows PC) connected together via Ethernet wiring.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the General Pipeline System and is the answer not in the manual?

Questions and answers

Related Manuals for Telestream General Pipeline System

Summary of Contents for Telestream General Pipeline System

  • Page 1: Setup Information

    Pipeline Product Sheet General Pipeline System Setup Information Pipeline system architecture Pipeline is a unique network attached encoder system that can be used in a variety of capture and playout workflows. Being network attached there are several architectural constraints that need to be understood in order to configure an efficient and reliable Pipeline system.
  • Page 2 RTSP stream into the appropriate file wrapper and server to assure proper performance (consult with your deliver these files to their respective media storage System Administrator or a Telestream Field Sales locations. Engineer) Pipeline host and Pipeline application software Windows systems only: •...
  • Page 3 Pipeline System Setup • For Pipeline channels that are directly connected to Special care must be taken to insure that a real-time the Pipeline host server’s network adapters, process can be achieved. Other network processes, disable all Networking Property components such as file copying, can consume unbounded band- except Internet Protocol Version 4 (TCP/IPv4) width and excessive network stack cycles which can...
  • Page 4 Pipeline System Setup Pipeline Simple Network Example Pipeline LACP (bonded ports) Network Example Pipeline Direct Attached Example Warning: When directly attaching multiple Pipeline channels to the host’s network adapter always connect them one at a time and configure each on their own subnet (as shown below).
  • Page 5 Pipeline System Setup Pipeline media Storage To evaluate your needs, you must first take into account When deciding on storage, there are two main factors the data rate for the format that you’ll be using and the number of streams your system will be capturing to consider - the overall sustained read/write perfor- mance required and whether local data disk buffering concurrently.
  • Page 6 Pipeline System Setup Capture with concurrent edit or transcode: Capture writing to NAS or shared network folder: For systems that are capturing with concurrent edit or For systems that are capturing media that is being transcode operations you will need to calculate the written to a NAS or shared network folder, it is required overall read/write speed requirements based on the to use the Pipeline data buffering feature (see Disk...
  • Page 7 Pipeline System Setup Example Systems Distributed Pipeline model – individual workstations Multiple channel Transcode while capture – Multiple controlling individual channels. Each workstation Pipeline channels hosted by a central workstation with meeting the single Pipeline channel spec with a delivery to a directly attached storage device. The network to support all traffic.
  • Page 8 Pipeline System Setup Using a Pipeline HD Dual and Vantage on a single system • CPU cores and speed (see System Recommenda- Pipeline HD Dual and Vantage can be installed on the same server in order to create a two (2) channel tion section) •...
