xPC560PADPT144S HARDWARE & JUMPER SETTINGS
5.1
Boot Configuration
The following jumpers affect the operation of the processor as it initially
comes out of the reset state:
J7 – FAB Configuration
Controls whether the processor boots from internal FLASH or from a serial
interface (CAN, SCI)
Jumper Setting
1+2
2+3 (default)
J8 – ABS0 Configuration
This jumper configures the ABS[0] pin.
Jumper Setting
1+2
2+3 (default)
J9 – ABS2 Configuration
This jumper configures the ABS[2] pin.
xPC560P EVB User Manual
Effect
The MPC560xP processor uses serial boot mode
The MPC560xP processor uses internal boot mode
Effect
The ABS[0] pin is pulled up logic high
The ABS[2] pin is pulled down logic low
