below has the correct pins listed.
J9 – Buttons Driving Configuration
Selects whether the buttons drive logic high or drive logic low when pressed.
Jumper Setting
1+2
2+3 (default)
12
Jumper Setting Effect
1+2 (default KEY1 connected to PD0
on)
3+4 (default KEY2 connected to PD1
on)
5+6 (default KEY3 connected to PD2
on)
7+8 (default KEY4 connected to PD3
on)
Effect
When pressed, buttons will send logic high to the
connected I/O pin
When pressed, buttons will send logic low to the
connected I/O pin
