J4 – VPROG Regulators Control
J5 – Regulators Enable & Standby
8
Jumper
Position
Setting
On
1+2
Off
(default)
On
3+4
Off
(default)
On
5+6
Off
(default)
Jumper
Position
Setting
On
1+2
Off
(default)
Effect
V
regulator output is programmed to 1V
KAM
V
regulator output is programmed to 1.5V
KAM
V
regulator output is programmed to 2.6V
STBY
V
regulator output is programmed to 3.3V
STBY
V
regulator output is programmed to 2.6V
DLL
V
regulator output is programmed to 3.3V
DLL
Effect
The power regulator is always on
The power regulator is in standby if jumpers
5+6 are also in the "off" position
xPC560P EVB User Manual
