TB-Electronics Frequency Synthesizer F-SCAN2 Instruction Manual page 14

The icon
The icon „PULSE" offers 5 positions, the pulse rates 5, 10, 15
or 20 (per second) and OFF. Pulsing resets to OFF whenever
the device shuts down.
The icon
has been touched.
has been touched.
Seite 14 von 45
The icon „WOBBLE"
offers 27ranges and
the OFF position.
( ± 10 to 90Hz, 100 to
900Hz, 1,000 to
9,000Hz.) The
selected range
remains active until the
feature is set to OFF
with a continuous
touch on the icon. The
same procedure must
be followed to change
from a higher to a
lower range or to
change a wrong entry.
