TB-Electronics Frequency Synthesizer F-SCAN2 Instruction Manual page 12

The icon
This field shows the
present setting in Hz
for the lower
frequency limit
"F MIN" for a broad
band SWEEP or for a
DIRP. It changes as
soon as a new value
has been entered
with the numerical
keys and is confirmed
with 'E'. (NEVER set
to ZERO!)The
numerical block
disappears and the
background of field
and icon changes
from active to
inactive
The icon
This field shows the
present setting in Hz
for the "DELTA F" for
a broad band
SWEEP or for a
DIRP. It changes as
soon as a new value
has been entered
with the numerical
keys and is confirmed
with 'E'. The
numerical block
disappears and the
background of field
and icon changes
from active to
inactive.
has been touched.
Enter a new frequency value and confirm with 'E'. In case of
an input error touch zero until all 8 digit's on the left are filled
with zero. Then input the correct value. The value must be
lower than "F MAX".
has been touched.
Enter a new frequency value and confirm with 'E'. In case of
an input error touch zero until all 8 digit's on the left are filled
with zero. Then input the correct value. The value must be
within the range between "F MAX" and "F MIN".
Seite 12 von 45
