TB-Electronics Frequency Synthesizer F-SCAN2 Instruction Manual page 10

The button
window 2.
Touch to switch
language of name
tables from German
to English and vice
versa.
Touch to transfer the
content of the ope-
rating memory to an
F-SCAN via the RS232
interface.
Touch to transfer the
content of the ope-
rating memory to an
F-SCAN 2 SATELLITE
via the RS232 interface.
The icon
The icon's black
background signals
that it has been
selected. The time
field to it's right
shows the present
setting and changes
to the new one after
the seconds are
confirmed with 'E'.
Touch to toggle the
"50 TIMER "-feature
ON and OFF.
in window 1 of the tab
in window 1 of the tab
Touch the left or right arrow to move between memory
positions '01' to '50'. A time element entered in position '01'
is valid for all frequencies of a set. If individual time
elements are needed, they can be assigned to the memory
positions corresponding to the frequencies held. The "50
TIMER"-feature must be ON to activate individual TIMERs for
an application.
Seite 10 von 45
has been touched to display
Touch to print either
the content of the
operating memory,
or all data of a DIRP
run, or the DIRP
graph on a serial
printer attached to
the RS232 socket of
the device.
Touch to print
settings of SETUP
window 1 on a serial
printer attached to
the RS232 socket of
the device.
has been touched.
This time field
shows the present
setting and changes
to the new minute
and/or second value
entered after confir-
mation with 'E'.
