IPro Two ™
DESCRIPTION:
The IPro Two is a two microphone, two stereo line input, all analog processor that is especially designed to optimize
audio signals (low or high impedance) for recording or live applications. It is loaded with features that distinguish it from
other units.
The dual full featured mic inputs can be set up as a stereo pair, or independently panned/mixed in the stereo field.
Phantom power, pad, polarity, low cut, gain, and enable are separately provided for each mic. Added to these inputs are
a high impedance stereo line input, which can be mixed with the mic signals, or used by itself. The output of the mic/line
mix is routed through stereo insert jacks which have an enable switch. This provides an additional unprocessed output
(the tip signal is always present), if one is required, as well as a place to insert alternate effects.
The equalization is comprised of two wide range, fully parametric filters. A cut and boost of 15 dB, a bandwidth of 2
to 1/6 octave and a frequency adjustment range of 40 Hz to 15 kHz will shape the sound as needed. Each parametric
equalizer has its own on/off switch to route the signal around it if it is unused.
The second parametric equalizer has an additional feature. It can be moved out from the main signal path into the
dynamic section's side-chain path, where it is in series with (after) the side-chain insert jacks of the RMS detectors. By
setting it up in this mode, it can be used to define the frequencies that control the dynamics' circuitry (expander,
compressor, and limiter). This is used for de-essing, for removing rumble modulation, or for specifying a problematic
frequency band to compress. When configured in this manner, any external signals brought in through the side-chain
insert jacks pass through this equalizer before being sent to the detector to allow frequency shaping to be applied to that
source as needed. The on/off switch still bypasses this filter even in this mode, just as you would expect.
A key part of the IPro Two is its true RMS summed, stereo-linked dynamics section. Using state-of-the-art integrated
circuits for the voltage controlled amplifiers and true RMS detectors, it has very low distortion and noise. Incorporated in
the processing is a downward expander, a compressor, and a limiter. Each has an independently adjustable threshold
control. The expander and compressor sections also have ratio controls. There are side-chain inserts in the detector
path that can be enabled from the front panel (see previous paragraph). The expander is of soft knee topology, and has
a ratio control to allow it to be used as a gentle-slope noise reduction circuit (low ratio), or a gate (high ratio). A threshold
LED illuminates when the expander is active. The compressor is also soft knee, but has a more gradual knee action for
even smoother transitions. It can be adjusted from no compression (1:1) to limit (infinite:1). The limiter is a compressor
with a fixed infinite:1 ratio, a faster knee transition, and an LED to show when it is functioning. All have preset (program
dependent) attack and release times. A twelve segment gain reduction meter displays all VCA activity (expander,
compressor, and limit) so that control action is easily seen, making adjustments a snap.
Heavy compression will give the perception of darkening the signal, since the low frequency components (which
have the most energy) dominate the compressor action. As the signal is compressed, the treble material is reduced at
the same ratio as the bass, causing it to lose definition. To compensate for this apparent loss and to add a new sheen to
signals which do not have much high frequency content, the SmarTube
high frequency harmonic generator based on our SmarTube tube simulation circuitry. A unique feature of the circuitry is
that it behaves as a tube does in its distortion characteristics and is level dependant. This means that more harmonics
are created at higher levels, which decrease as the source fades out, just as a natural sound would. It is tunable and will
add pleasing high frequency detail not found in the source. It can bring a mic to the front of a mix, or add atmosphere to
an instrument.
There may be an occasion when certain frequencies must be compressed then added back to the original "dry"
signal, similar to using the IPro Two as one of the bands of a multi-band compressor. A blend control was added so that
this could be done without having to sacrifice an external mixer channel (if one is available) to accomplish this feat.
Simply turn it to "wet" and set up the frequency band and dynamic action that you want processed, then blend this with
the "dry" signal to taste. By compressing the bass and adding it back to the original, a "fatter" sound can be created.
A headphone monitoring function with an independent level adjustment is included. This is especially needed when
the unit is used as a stereo channel recording preamp. Its signal is picked up before the main level control, and drives a
™ Enhance process was developed. This is a
