Chamberlain LiftMaster Security+ WKP5LM User Manual

®
Overview
The Wireless Keypad uses a digitally secure intercom
link that allows it to control up to four access points.
The Wireless Keypad is compatible with various
Liftmaster Wireless Products.
Model WKP5LM can hold up to 5 PIN Numbers.
Model WKP250LM can hold up to 250 PIN Numbers.
Carton Inventory
1 2 3
4
5 6
7 8 9
*
0 #
Cancel
Keypad
Assembly
Install 4 AA Alkaline batteries (not provided). (Lithium
batteries recommended for colder environments.)
Keypad will beep.
Keypad will continuously beep indicating no Master
PIN Number has been programmed. Proceed to

Initial Setup.

Bolt (4)
Screw (4)
Washer (4)
Allen Wrench
Nut (4)
Models WKP5LM & WKP250LM
Initial Setup
Step 1: On keypad press:
Step 2: Enter 4 digit Master PIN Number.
Example: 1234.
NOTE: " * " is the cancel button that will cancel any
call or key sequence.
Multiple Keypads at Same Location
NOTE: This step applies only if more than one
Keypad is being used.
Step 1: On secondary Keypad enter Master PIN
Number:
Step 2: Then:
5
NOTE: To switch a secondary Keypad to a Main
Keypad, enter the Master PIN Number followed by
"57".
Step 3: On Main Keypad enter Master PIN Number:
Step 4: Then:
0
NOTE: If a siren noise is heard the programming has
failed. Repeat process.
The Keypad can be used as a primary or secondary
device. Accessories should be programmed directly to
the primary device.
If programming to a GCU, see page 2.
If programming to an ULTRX900R, see page 3.
If programming to a GAPLM, see page 4.
If programming to existing receiver, see page 4.
1
Wireless Keypad
6
5
