I. 3. What is Network Adapter?
The Network Adapter enables the network management of UPS units or other
equipment. Adapter is supplied with basic accessories that can be completed according to
individual customer's needs and requirements. In Figure 1 you see the Network Adapter
(NetMan101 version), in Figure 2 there is an example of connection between Network
Adapter NetMan 102 and UPS; this device is an expansion card for your UPS to insert directly
into UPS slot (for Ups models supporting that), but functionality is exactly the same of
NetMan101: in this manual everything explained about NetMan101 is the same for
NetMan102.
Fig. 1 Network Adapter NetMan 101
Description of controls and connectors :
1. UTP Ethernet LAN
2. Signaling LED's for network activity
3. Terminal connect to configure adapter
Rear side
of UPS
Fig.2 Network adapter NetMan 102
2
1
3
NetMan 102
1
2
3
7
