II.4. Upgrading NetMan firmware
Before upgrading the firmware, make sure that you have everything listed in paragraph 1.5 as
well as the firmware file (BIN file) that can be downloaded from our site
technet.com.
II. 4. 1. Upgrading via serial port
Connect the TERMINAL port of NetMan to the serial port on the PC using the supplied
CB378 cable. Activate the Terminal Emulation software with X-Modem protocol
(HyperTerminal), configuring it as described in paragraph II.1.
Then perform the following operations:
1. Power NetMan using the special power supply provided.
2. Access the main menu and select menu 9.
3. Press "9" to start the upgrade.
4. Wait until the message "Press D download software..." appears, as shown in figure 8.
