Excessive Vacuum Motor noise.
Burnt motor smell from clean air
exhaust.
All switches are ON, ONLY Vacuum
Motor does not run.
Dirty liquid is being discharged
through the Vacuum Motor Exhaust
Tube (C4:10101 / C4-A: 10608).
NOTE: The solution is being sucked
into the Vacuum Motor and then
blowing out the Exhaust Tube.
CLEAN UP Step 1: Sit the Bucket
aside. Move the machine to concrete
surface, such as the garage. Leave
the Lid up. Run the Vacuum Motor
only for 1 minute to blow out any
remaining liquid.
Step 2: Clean the discharged dirty
liquid from carpet immediately ! Spot
Remover or 7 in 1 may be needed.
ALSO: Using the Hand Tool may lift
spot better.
VACUUM SYSTEM CONTINUED
P
O
S
S
B I
L
E
C
A
1. Worn Vacuum Motor bearings
and / or fan blades.
1. Worn Vacuum Motor brushes.
NOTE: Excessive sparking may also
occur.
1. Defective Vacuum Motor.
2. Defective Switch .
3. Terminals not connected or
defective.
1. The cleaning solution was not
poured from the Bucket into the
Solution Tank .
2. Foam is building up in the Bucket . 2. Empty Bucket without refilling the
3. Too much liquid was added to the
Solution Tank .
8
U
S
E
1. Replace Vacuum Motor. (18007)
(See Repair Manual: Removing
Vacuum and Brush Assembly, and
Replacing Vacuum Motor.)
1. Replace Vacuum Motor (18007).
(See Repair Manual: Removing
Vacuum and Brush Assembly, and
Replacing Vacuum Motor.)
1. TEST: Test Vacuum Motor
(18007) using Vacuum / Brush Motor
Test Cable (7202) . If motor runs,
there is a problem with the electrical
system. NOTE: If motor does not
work, replace Vacuum Motor
(18007). (See Repair Manual:
Removing Vacuum and Brush
Assembly, and Replacing Vacuum
Motor.)
2. Replace Switch (10108) .
3. Re-connect or replace Terminals .
1. Pour the cleaning solution from the
Bucket into the Solution Tank .
Solution Tank . If available, add Anti
Foam to the emptied Bucket .
3. Empty Bucket without refilling the
Solution Tank . Do not exceed top Fill
Line of Bucket . Add less water to the
Solution Tank during next cleaning
cycle.
S
O
L
U
I T
O
N
