Long Range Ethernet Extender
Model Number: EIDM-EXTEND-2
User's Manual
Rev. 1.0
International Headquarters
B&B Electronics Mfg. Co. Inc.
707 Dayton Road
Ottawa, IL 61350 USA
Phone: (815) 433-5100 General Fax: (815) 433-5105
Website:
www.bb-elec.com
European Headquarters
B&B Electronics
Westlink Commercial Park
Oranmore, Co. Galway, Ireland
Phone: (+353) 91-792444 Fax: (+353) 91-792445
Website:
www.bb-europe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EIDM-EXTEND-2 and is the answer not in the manual?

Questions and answers

Related Manuals for B&B Electronics EIDM-EXTEND-2

Summary of Contents for B&B Electronics EIDM-EXTEND-2

  • Page 1 Long Range Ethernet Extender Model Number: EIDM-EXTEND-2 User’s Manual Rev. 1.0 International Headquarters B&B Electronics Mfg. Co. Inc. 707 Dayton Road Ottawa, IL 61350 USA Phone: (815) 433-5100 General Fax: (815) 433-5105 Website: www.bb-elec.com European Headquarters B&B Electronics Westlink Commercial Park Oranmore, Co.

  • Page 2: Table Of Contents

    EIDM-EXTEND-2 Long Range Ethernet Extender ..............2 1. INTRODUCTION ............2 2. APPLICATION NOTES ................3 3. FEATURES ............3 4. PACKING CONTENTS .......... 4 5. INSTALLATION PROCEDURES ........5 6. FRONT PANEL LED INDICATORS ..........6 7. CONSOLE PORT CONTROL 7.1.

  • Page 3: Introduction

    LAN connectivity between two Ethernet networks. This is enough speed to support VoIP, Web hosting, and teleconferencing. The EIDM-EXTEND-2 conforms to the ITU-T Rec. G.991.2, to meet G.shdsl.bis network requirements. It offers a cost-effective symmetrical broadband solution for applications such as LAN to LAN, Internet access, and VoIP.

  • Page 4: Features

     8 LED status indicators.  Power Input: 100-240VAC. 4. Packing Contents Inside the package you should find: (1) One EIDM-EXTEND-2 Long Range Ethernet Extender unit (260x151x44mm) (2) One power cord (3) One RS232 cable (4) One CAT 5 Ethernet Cable (5) One Quick Start Guide (6) One User’s Manual on CD-ROM...

  • Page 5: Installation Procedures

    EIDM-EXTEND-2 Long Range Ethernet Extender 5. Installation Procedures Step 1: Connect the SHDSL line (1 or 2 pairs) to the RJ-48 connector (marked Line) on the rear panel of the Ethernet Extender. Please note: RJ-48 and RJ-45 connectors are physically identical RJ-48 Connector Pin Assignment for SHDSL Line Interface, straight through Note: RJ48 connectors hold up to eight wires.

  • Page 6: Front Panel Led Indicators

    EIDM-EXTEND-2 Long Range Ethernet Extender 6. Front Panel LED Indicators There are 8 LED indicators on the front panel of the Long Range Ethernet Extender displaying the current status. These LED indicators are described as following. POWER: “Green On” shows Ethernet Extender power supply is normal.

  • Page 7: Console Port Control

    EIDM-EXTEND-2 Long Range Ethernet Extender 7. Console Port Control The Long Range Ethernet Extender provides an RS232C console port for users to monitor the status and configure the Extender through a VT100 terminal. This section covers the operation procedures, settings and for all screen selections.

  • Page 8: Main Menu

    EIDM-EXTEND-2 Long Range Ethernet Extender 7.1. Main Menu Main Menu will display the connection status of the Ethernet Extender and settings including two sections: Configuration, and Status. For details please refer to Table 7-1. Table 7-1 Main Menu The pull-down tree structure of the main menu is shown in Figure 7-2.

  • Page 9: Configuration Screen

    EIDM-EXTEND-2 Long Range Ethernet Extender 7.2. Configuration Screen Configuration screen will display the selections of connection for the Ethernet Extender unit and the screen includes three selections: DSL Mode Settings, DSL Speed Settings, and Default Configuration. For details please refer to Table 7-2.
  • Page 10 EIDM-EXTEND-2 Long Range Ethernet Extender DSL Mode Settings: Table 7-3: DSL Mode Settings screen This screen provides DSL mode settings and user can update the settings from this screen. CO/RT: The item of CO/RT has 2 options: STU-C and STU-R. To establish a successful connection for two Ethernet Extenders, it is necessary to set one unit to STU-C and the other unit to STU-R.
  • Page 11 EIDM-EXTEND-2 Long Range Ethernet Extender DSL Speed Settings: Table 7-4 DSL Speed Settings screen This screen provides DSL Speed Settings and user can configure DSL speed to set the transmission rate. For 1-pair setting in the DSL Mode menu, the options are as following;...
  • Page 12 EIDM-EXTEND-2 Long Range Ethernet Extender automatically adapt to maximum speed according to the loop distances. The maximum speed is 4608Kbps for 1-pair mode and 9216Kbps for 2-pair mode. Default Configuration Setting: Table 7-5 Default Configuration Setting screen When Default Configuration is selected, all the settings of the Ethernet Extender will go back to default settings.

  • Page 13: Status Screen

    EIDM-EXTEND-2 Long Range Ethernet Extender 7.3. Status Screen The Status screen shows the connection status of the Ethernet Extender unit. The screen covers two selections: System Information and System Status. For details please refer to Table 7-6. Table 7-6 Status screen...
  • Page 14 EIDM-EXTEND-2 Long Range Ethernet Extender System Information: Table 7-7 System Information screen Items listed in the above screen are as follows: Firmware Version: The firmware version in this unit. Vendor Model: The model name. Vendor Information: Website information.

  • Page 15: System Status Screen

    EIDM-EXTEND-2 Long Range Ethernet Extender System Status Screen: Table 7-8 System Status screen. The distance of this example is 6K ft and 26AWG. Items list in the above screen are explained as follows: DSL mode: The current DSL mode setting.
  • Page 16 EIDM-EXTEND-2 Long Range Ethernet Extender Line Attenuation of pair #1(dB): Indicates the Line Attenuation value in dB of pair #1. The maximum value is 43 dB when the DSL distance is 20500 ft, 26AWG. Line Attenuation of pair #2(dB): Indicates the Line Attenuation value in dB of pair #2. The maximum value is 43 dB when the DSL distance is 20500 ft, 26AWG.

  • Page 17: Specifications

    EIDM-EXTEND-2 Long Range Ethernet Extender 8. Specifications IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3x, Applicable Ethernet over SHDSL Standards LAN1 and LAN2 ports: 2 x 10/100Mbps Ethernet port with RJ-45 Fixed Ports connector Line port: 1 x Ethernet Extender port with RJ-48 interface...
