Cleaning Instructions –
Avoiding Stainless Steel Corrosion
Corrosion can be prevented by following product
cautions, cleaning instructions and avoiding use
of certain chemicals or objects which will cause
stainless steel corrosion.
Wiring Diagram –
temPerature
ControL
PLug-in-CorD
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice.
Single Door Freezer
single Door Freezer
eVaP
Fan
ConD
Fan
oPen
@ 40ϒ F
DeFrost
CLose
temP. Limit
@ 25ϒ F
sWitCH
internaL
ConneCtions
a1
a2
3
4
W
b
2
1
2
to ConDensing
3
unit
STAINLESS STEEL ENEMY
■ Steel wool or steel scouring pads
■ Cherry/Orange/Olive juice
■ Chlorine Bleach
■ Sharp Objects
normaL CLoseD
Hot gas DeFrost
soLenoiD
DeFrost CYCLe:
1) a Fter 220 minutes:
• a2 oPens.
• b1 CLoses.
• Hot gas VaLVe oPens.
• on DeLaY reLaY ContaCt
reD
CLoses 1 to 2, in 3 minutes.
• tHermostat is bYPasseD.
• ComPressor restarts aFter
3 minutes For Hot gas DeFrost.
1
2) L imit sWitCH oPens at 40ϒ F:
2
• ComPressor PoWer oFF.
• Hot gas remains energiZeD.
on DeLaY
3) a Fter 20 minutes:
reLaY
3 • b1 oPens.
• Hot gas VaLVe is De-energiZeD.
• a2 CLoses.
• ComPressor starts tHrougH
temPerature ControL.
a t11 t12 t13
b2 b1
t14
t15
s.s. timer
4
5
s.P.s.t. momentarY
6
ContaCt DeFrost sWitCH
W/ inDiCator LigHt
5
Form No. Z2255
Rev. 01.04.09
