Start-Up, Operation, and Maintenance Instructions

Centrifugal liquid chillers are designed to provide safe

and reliable service when operated within design speci-

ﬁcations. When operating this equipment, use good judg-

ment and safety precautions to avoid damage to equip-

ment and property or injury to personnel.

Be sure you understand and follow the procedures and

safety precautions contained in the machine instruc-

tions as well as those listed in this guide.

DO NOT VENT refrigerant relief valves within a building. Outlet

from rupture disc or relief valve must be vented outdoors in ac-

cordance with the latest edition of ASHRAE 15 (American Society

of Heating, Refrigeration and Air Conditioning Engineers). The ac-

cumulation of refrigerant in an enclosed space can displace oxygen

and cause asphyxiation.

PROVIDE adequate ventilation in accordance with ASHRAE 15,

latest edition, especially for enclosed and low overhead spaces. In-

halation of high concentrations of vapor is harmful and may cause

heart irregularities, unconsciousness, or death. Misuse can be fatal.

Vapor is heavier than air and reduces the amount of oxygen avail-

able for breathing. Product causes eye and skin irritation. Decom-

position products are hazardous.

DO NOT USE OXYGEN to purge lines or to pressurize a machine

for any purpose. Oxygen gas reacts violently with oil, grease, and

other common substances.

NEVER EXCEED speciﬁed test pressures, VERIFY the allowable

test pressure by checking the instruction literature and the design

pressures on the equipment nameplate.

DO NOT USE air for leak testing. Use only refrigerant or dry

nitrogen.

DO NOT VALVE OFF any safety device.

BE SURE that all pressure relief devices are properly installed and

functioning before operating any machine.

DO NOT WELD OR FLAMECUT any refrigerant line or vessel

until all refrigerant (liquid and vapor) has been removed from chiller.

Traces of vapor should be displaced with dry air or nitrogen and

the work area should be well ventilated. Refrigerant in contact with

an open ﬂame produces toxic gases.

DO NOT USE eyebolts or eyebolt holes to rig machine sections or

the entire assembly.

DO NOT work on high-voltage equipment unless you are a quali-

ﬁed electrician.

DO NOT WORK ON electrical components, including control pan-

els, switches, starters, or oil heater until you are sure ALL POWER

IS OFF and no residual voltage can leak from capacitors or solid-

state components.

LOCK OPEN AND TAG electrical circuits during servicing. IF WORK

IS INTERRUPTED, conﬁrm that all circuits are deenergized be-

fore resuming work.

DO NOT siphon refrigerant.

AVOID SPILLING liquid refrigerant on skin or getting it into the

eyes. USE SAFETY GOGGLES. Wash any spills from the skin

with soap and water. If liquid refrigerant enters the eyes, IMME-

DIATELY FLUSH EYES with water and consult a physician.

NEVER APPLY an open ﬂame or live steam to a refrigerant cyl-

inder. Dangerous over pressure can result. When it is necessary to

heat refrigerant, use only warm (110 F [43 C]) water.

Manufacturer reserves the right to discontinue, or change at any time, speciﬁcations or designs without notice and without incurring obligations.

Book 2

PC 211

Catalog No. 531-968

Tab

Hermetic Centrifugal Liquid Chillers

SAFETY CONSIDERATIONS

DO NOT REUSE disposable (nonreturnable) cylinders or attempt

to reﬁll them. It is DANGEROUS AND ILLEGAL. When cylinder

is emptied, evacuate remaining gas pressure, loosen the collar and

unscrew and discard the valve stem. DO NOT INCINERATE.

CHECK THE REFRIGERANT TYPE before adding refrigerant to

the machine. The introduction of the wrong refrigerant can cause

damage or malfunction to this machine.

Operation of this equipment with refrigerants other than those

cited herein should comply with ASHRAE-15 (latest edition). Con-

tact Carrier for further information on use of this machine with other

refrigerants.

DO NOT ATTEMPT TO REMOVE ﬁttings, covers, etc., while ma-

chine is under pressure or while machine is running. Be sure pres-

sure is at 0 psig (0 kPa) before breaking any refrigerant

connection.

CAREFULLY INSPECT all relief devices, rupture discs, and other

relief devices AT LEAST ONCE A YEAR. If machine operates in

a corrosive atmosphere, inspect the devices at more frequent

intervals.

DO NOT ATTEMPT TO REPAIR OR RECONDITION any relief

device when corrosion or build-up of foreign material (rust, dirt,

scale, etc.) is found within the valve body or mechanism. Replace

the device.

DO NOT install relief devices in series or backwards.

USE CARE when working near or in line with a compressed spring.

Sudden release of the spring can cause it and objects in its path to

act as projectiles.

DO NOT STEP on refrigerant lines. Broken lines can whip about

and release refrigerant, causing personal injury.

DO NOT climb over a machine. Use platform, catwalk, or staging.

Follow safe practices when using ladders.

USE MECHANICAL EQUIPMENT (crane, hoist, etc.) to lift or

move inspection covers or other heavy components. Even if com-

ponents are light, use mechanical equipment when there is a risk of

slipping or losing your balance.

BE AWARE that certain automatic start arrangements CAN EN-

GAGE THE STARTER, TOWER FAN, OR PUMPS. Open the dis-

connect ahead of the starter, tower fans, or pumps. Shut off the

machine or pump before servicing equipment.

USE only repair or replacement parts that meet the code require-

ments of the original equipment.

DO NOT VENT OR DRAIN waterboxes containing industrial brines,

liquid, gases, or semisolids without the permission of your process

control group.

DO NOT LOOSEN waterbox cover bolts until the waterbox has

been completely drained.

DOUBLE-CHECK that coupling nut wrenches, dial indicators, or

other items have been removed before rotating any shafts.

DO NOT LOOSEN a packing gland nut before checking that the

nut has a positive thread engagement.

PERIODICALLY INSPECT all valves, ﬁttings, and piping for cor-

rosion, rust, leaks, or damage.

PROVIDE A DRAIN connection in the vent line near each pres-

sure relief device to prevent a build-up of condensate or rain

water.

Printed in U.S.A.

Form 19EF-3SS

50/60 Hz

with HFC-134a

Pg 1

4-95

Replaces: 19EF-2SS
