'yes'.
: Click to refresh the Page.

4.9.13 Storm Control Configuration

Storm control for the switch is configured on this Page. There is a unicast storm rate control, multicast storm rate control, and a
broadcast storm rate control. These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC
Address table.
The configuration indicates the permitted packet rate for unicast, multicast or broadcast traffic across the switch.
The Storm Control Configuration screen in
The Page includes the following fields:
Object

Port
Figure 4-9-15 appears.
Figure 4-9-15: Storm Control Configuration Page Screenshot
Description
The port number for which the configuration below applies.
218
