1.5 Product Specifications

Product
Hardware Specifications
SFP/mini-GBIC Slots
Console
Switch Architecture
Switch Fabric
Throughput
Address Table
Share Data Buffer
Flow Control
Jumbo Frame
Reset Button
Dimension (W x D x H)
Weight
LED
Power Requirement
Power Consumption
ESD Protection
Power over Ethernet
PoE Standard
PoE Power Supply Type
PoE Power Output
Power Pin Assignment
PoE Power Budget
PoE Ability PD @ 7 watts
NS3702-24P-4S
4 100/1000Base-X SFP interfaces, shared with Port-21 to Port-24
Compatible with 100Base-FX SFP transceiver
1 x RS-232 DB9 serial port (115200, 8, N, 1)
Store-and-Forward
48Gbps / non-blocking
35.7Mpps@64Bytes
16K entries, automatic source address learning and ageing
4M bits
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
9K bytes
< 5 sec: System reboot
> 5 sec: Factory Default
440 x 300 x 44.5 mm, 1U height
4750g
System:
Power (Green)
FAN1 (Green), FAN2 (Green), FAN3 (Green), PWR (Green)
10/100/1000T RJ45 Interfaces (Port 1 to Port 24):
10/100/1000Mbps LNK/ACT (Green)
PoE In-Use (Orange)
100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24):
1000Mbps (Green), LNK/ACT (Orange)
100~240V AC, 50/60Hz, 6A
422 watts / 1447 BTU Max.
6KV DC
IEEE 802.3af / 802.3at PoE / PSE
End-span
Per Port 56V DC, Max. 30.8 watts
1/2(+), 3/6(-)
440 watts Max.
24 units
