PARTS LIST 12/13

Key Part No. Qty Description
1 12130 1 Main Frame
2 12132 1 Frame Control Handle
3 12131 1 Cutter Wheel
4 12133 1 Inner Belt Guard
5 12136 1 Outer Belt Guard
6 12134 1 Curtain Mount, Rear
7 12135 1 Wheel Slot Cover
8 12145 1 Brake Bracket, LH
9 12138 2 Brake Rotor
10 12139 1 Engine, 13 HP Honda
20122 1 Engine, 11 HP Briggs I/C
11 12140 1 Idler Bracket
12 12141 2 Wheel Assembly
13 12101 2 Brake Caliper
14 16266 2 Muffler Clamp
15 16251 2 Bearing, Pillow Block
16 16256 1 Cutter Wheel Shaft
17 12152 1 Taper Bushing, 1"
18 28801 2 Clevis Pin
19 12143 1 Presence Handle
20 12161 2 Spacer, Presence Handle
21 16219 1 Adjustment Tool (Belt)
22 16260 4 Threaded Tooth Pocket
23 16261 4 Counter Bore Tooth Pocket
24 16262 8 Pocket Bolt
25 16263 4 Straight Tooth
26 16265 2 LH Tooth
27 16264 2 RH Tooth
28 16242 2 Brake Handle
29 12146 2 Brake Cable
30 12144 1 Cover Plate
31 12137 1 Brake Bracket, RH
32 16246 1 Spring, Handle Lock
33 16298 1 Pin, Handle Lock
34 16294 1 Handle Grip, Adj. Pin
35 12147 1 Axle Assembly
36 16221 2 Curtain Mount
37 12149 1 Curtain, Left
38 12148 1 Curtain, Rear
40 12150 1 Curtain, Right
41 16225 2 Curtain Mount, Right
42 12151 2 Pulley, 4 ½"
43 16201 1 Bushing, 1 3/16"
44 12154 2 Belt Main Drive
45 16354 1 Idler Arm
46 16203 1 Idler
47 16339 1 Manual Pack
48 72646 1 Tach/Hour Meter
49 16244 1 Kill Switch
50 58058 2 Hub Cap
51 16299 1 Spacer
52 16295 2 Spacer, Tension Adjustment
53 16314 2 Ball Joint
54 12156 2 Clamp, rubber cushion
Key Part No. Qty Description
Optional Green Teeth
55 16372 8 Stand. Tap & Turn Tooth
56 16373 4 LoPro Rev. Angle Pocket
57 16374 4 LoPro Rev. Straight Pocket
59 16378 8 1 ¾" Flat Head Smart Bolt
