Page 1 S2 Digital I/O Analogue Radio Broadcast Mixer User Handbook DAVE LANGER (Creative Services) 27 Cavendish Road, Salford, M7 4WP, England. Telephone: +44 161 740 7171 Facsimilie: +44 161 792 9595 Internet: http://www.jingle.org E-mail: info@jingle.org...
Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Sonifex Ltd. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising form the use of information or any error contained in this manual.
Page 3: Table Of Contents
S2-CML Mic/Line Input Channel S2-CMM Mic/Mic Input Channel S2-CS Dual Stereo Line Input Channel S2-CSE Dual Stereo Line Input with EQ Channel S2-CSG Stereo Line with Gram Input Channel S2-CDS Digital Dual Stereo Input Channel S2-CDSE Digital Dual Stereo Input with EQ Channel...
Page 4 S2-CDSE/S2-CDS Digital Dual Stereo Line Channel With & Without EQ Panel Controls Rear Panel Channel Options, Jumper Settings and Presets 10 S2-C6SS 6 Way Stereo Line Source Select Channel With EQ Panel Controls Channel Options, Jumper Settings and Presets 11 S2-CT Telco Channel With EQ...
Page 5 Meterbridge Distribution Board S2-MB1-5 Meterbridge Blanking Plates S2-ML Meterbridge Loudspeaker Monitor Panel S2-MVU Meterbridge VU Meter Panel, S2-MPPM PPM Meter Panel, S2-MPPT True PPM Meter Panel & S2-ML53 LED Meter Panel S2-MPH Meterbridge Phase Meter Panel S2-MTB6 Meterbridge 6 Way Talkback Panel...
Page 6 Fig 6-1 : S2 Mic/Mic Input Board Layout. Fig 7-1 : S2 Dual Stereo Input With & Without EQ Board Layout. Fig 8-1 : S2 Stereo Line & Gram With & Without EQ Board Layout. Fig 9-1 : S2 Digital Dual Stereo Input Board Layout.
Page 7: Warranty And Liability
Company. In respect of any item manufactured by a person other than the Company, the Purchaser shall only be entitled to the beneﬁt of any warranty or guarantee provided by such manufacturer to the Company. S2 User Handbook...
Page 8 Seller in Condition (c). Where the Goods are sold under a consumer transaction (as deﬁned by the Consumer Transactions (Restrictions on Statements) Order 1976) the statutory rights of the Purchaser are not aﬀected by these Conditions of Sale. S2 User Handbook...
Page 9: Returning The Warranty Card
In order to register the date of purchase so that we can keep you informed of any design improvements or modiﬁcations, it is important to complete the warranty registration document that is enclosed and return it to Sonifex Ltd in the UK, or register online at www.sonifex.co.uk/register For your own records you should write down the serial number of both the power supply and the mixer chassis (2 for a split desk).
Page 10: Safety Of Mains Operated Equipment
If for any reason, you need to use the product with a diﬀerent power cable, you should use the following wiring guidelines Wire Colour Connection Green, or green and yellow Earth (E) Blue, or Black Neutral (N) Brown, or Red Live (L) S2 User Handbook...
Page 11: Weee & Rohs Directives - Sonifex Statement
It gives a contact for individuals who are unsure about the correct procedure when the product has reached its “end of use”. Sonifex Ltd will be happy to give you information about local organisations that can reprocess the products, or alternatively all products that have reached “end of use” can be returned to Sonifex and will be reprocessed correctly free of charge.
Page 12: Reporting Faults
R E P O R T I N G A FAU LT Reporting Faults Although this Sonifex product is manufactured to the highest standards, it is possible that minor faults may appear in the equipment over its normal lifetime. If you ﬁnd any problems...
Page 13: Introduction
Innovative Design • The S2 chassis is available in 5 channel width sections, allowing 5, 10, 15, 20, 25 and 30 channel width mixers. This means S2 can be used for small newsrooms or large on-air situations. The following table shows the model number along with the total channel width.
Page 14: Fig 1-2 : S2-7Ss Script Space
I N T R O D U C T I O N • The Script Space (S2-7SS) occupies an area of 7 channel widths, and is designed to hold documents / scripts for the Mixer operator when desk space is at a premium.
Page 15: Superb Audio Quality And Unquestionable Reliability
I N T R O D U C T I O N Superb Audio Quality and Unquestionable Reliability • The S2 uses the latest Crystal semiconductor technology to allow input and output of digital audio signals up to 24 bit, 96kHz sample rate. •...
Page 16: Installation Notes
2 Installation Notes Atmosphere The S2 mixer should be installed in an area which is not subject to excessive heat or cold. Also, you should avoid installing it in atmospheric conditions which are dusty, smoky, or dirty, or where there is moisture or vibration.
Page 17: Channel Conﬁguration
It is recommended that, wherever possible, pre-wired cables are purchased from recommended manufacturers. If you need bespoke cables making, please ensure that a qualiﬁed engineer carries out the work. S2 User Handbook...
Page 18: Fig 2-3 : Xlr Connectors
I N S TA L L AT I O N N OT E S The main types of connectors used with the S2 mixers are the following: XLR 3 Pin Connectors The following diagram shows the pin details for the 3 pin XLR sockets and plugs: Line, Mic &...
Page 19: Fig 2-6 : 1/4" Jack Connectors
Fig 2-6 : 1/4” Jack Connectors. D Type Connectors Several diﬀerent D type connectors are used on the S2. A 9 pin plug is used for the remotes on input channels and external inputs on monitor channels. A 15 pin socket is used for the analogue outputs and mute relays on the output channels.
Page 20: Fig 2-8 : 25 Pin D-Type Connectors
Fig 2-8 : 25 Pin D-Type Connectors. 9 Pin D-Type Plug used 9 Pin D-Type Socket used for Power Connections for Power Interconnect Cable Pin 5 Pin 1 Pin 1 Pin 5 Fig 2-9 : 9 Pin D-Type Power Connectors. S2 User Handbook...
Page 21: System Block Diagrams
AND ROUTING MIX BUS Input Channels Diagram - CSG,CSGE,CS,CSE,CDS,CDSE, and CSMM C6SS AUD PFL C/FEED L R L R L R 1 2 1 2 ROUTING LEFT TO S2-OMC & TRIM TRIM S2-OMS CPU INPUT 1 LINE LEFT LINE 1/2 HF/LF...
Page 22: Fig 2-11 : System Block Diagram (Sheet 2)
LEFT (S2-CSMM) PGM METERS MONITOR METERS TO CLEANFEED S2-MPPM DUAL PPM METER PANEL RIGHT (S2-CSMM) S2-MPPT TRUE DUAL PPM METER PANEL S2-MVU DUAL VU METER PANEL S2-ML53 DUAL LED BAR GRAPH METER S2-MPH PHASE METER PANEL PFL METERS PHASE METER Fig 2-11 : System Block Diagram (Sheet 2).
Page 23: Applications
Shown below is an example of connecting one of the latching relay contacts on the PGM or AUD modules to a Sonifex RB-LC3. The remote connection on the LC3 is active low. PGM or AUD Output Module D-Type Outputs &...
Page 24 In this case it is only necessary to use the start remote, but you will need to make the contact latching by setting a jumper (See the relevant module for jumper settings). S2 User Handbook...
Page 25: Removing & Replacing Channels
ﬂush with the channels beside it. Replace the screws, and reattach the cables to the rear of the channel. S2 User Handbook...
Page 26: Connecting A Split Desk
I N S TA L L AT I O N N OT E S Connecting A Split Desk There are three cables used when connecting an S2 mixer split desk conﬁguration. A 16 way IDC cable which connects the two meterbridge distribution boards, A 60 way jacketed IDC cable which connects the two main mixer bus cables and an earth braid cable which connects the two chassis’...
Page 27: Fig 2-15 : Cable & Channel Connection
M4 nut and removing the shakeproof washer. Then place the solder tag of the earth braid cable on the bolt and then replacing the shakeproof and M4 nut. S2 User Handbook...
Page 28: Power Supply
Front Panel The S2-PSU is a 2U high rack-mount unit, which can supply power to the entire range of S2 mixers. A lead with a special 9 pin D-Type socket (see Fig 2-9) on each end is used to connect the power supply to the mixer.
Page 29: Rear Panel
The rear panel of the equipment carries the Serial Number of the machine. The operating voltage of the S2 power supply is selectable at the fuse carrier on the power inlet port of the S2-PSU unit. Ensure that the machine operating voltage is correct for your mains power supply.
Page 30: Ordering The Correct Mains Lead
If no moulded plug has been supplied with your S2, please contact your supplier, because an IEC connector is always supplied from the Sonifex factory. If for any reason, you need to use the S2 with a diﬀerent power cable, you should use the following wiring guidelines.
Page 31: Fuse Rating
P O W E R S U P P LY Fuse Rating The S2 is supplied with a single fuse in the live conducting path of the power infeed at the power supply. For reasons of safety it is important that the correct rating and type of fuse is used.
Page 32: S2-Psus Dual Power Supply Switcher
P O W E R S U P P LY S2-PSUS Dual Power Supply Switcher The S2-PSUS is a passive power switcher which takes the power feeds from 2 x S2-PSU units and switches between them in the event of failure. Two trailing leads 0.5m in length connect to 2 x S2-PSU units.
Page 33 P O W E R S U P P LY Power Input Connectors Two trailing leads 0.5m in length are used to connect 2 x S2-PSU units to the power switcher. Power Output Connector This 9 pin D type connector (see Fig 2-9) is used to route power to the Mixer from either the master or slave power supply.
Page 34: Input Channels
(500mS) or latched for each input. The remote outputs on the 9 way D type plug are fed from NPN opto-isolators. S2-CSE Dual Stereo Line Input with EQ Channel This channel is the Dual Stereo Input channel as above but ﬁtted with equalisation, providing 7dB cut and boost at HF (6.5kHz) and LF (100Hz).
Page 35: S2-Csg Stereo Line With Gram Input Channel
Dual Stereo Line Input channel. S2-CDSE Digital Dual Stereo Input with EQ Channel This channel is the Digital Dual Stereo Input channel as above but ﬁtted with equalisation, providing 7dB cut and boost at HF (6.5kHz) and LF (100Hz).
Page 36: S2-Pg S2 Penny & Giles Conductive Plastic Fader
9 way D type plug are fed from NPN opto-isolators. S2-PG S2 Penny & Giles Conductive Plastic Fader The input and output channels of an S2 mixer can optionally be ﬁtted with high quality Penny & Giles faders.
Page 37: 5 S2-Cml Mic/Line Channel With Eq
S 2 - C M L M I C / L I N E C H A N N E L W I T H E Q 5 S2-CML Mic/Line Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.
Page 38: Rear Panel
Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; • Mic cue light • Line remote start • Line remote stop • Cough/reverse talkback switch • Talkback mic enable S2 User Handbook...
Page 39: Channel Options, Jumper Settings And Presets
Select momentary or latched start. • Select monitor mute for studio or control room. • Select timer option. • Enable or disable Cue/PFL cancel from fader. • Enable continuous momentary start from ON button. • Enable mic on Input 2. S2 User Handbook...
Page 40 None No timer function. 1 & 2 Control room monitor mute from Line input. 2 & 3 Studio monitor mute from Line input. None No mute function. Note: Options in bold are set as default when shipped. S2 User Handbook...
Page 41: Fig 5-1 : S2 Mic/Line Input Board Layout
JMute 1 J13 J15 Timer Mute 2 Fig 5-1 : S2 Mic/Line Input Board Layout. Remote for Mic Cue Light The remote output for the Microphone input (Input 1) can be used to operate a Mic Cue light when the channel is ON and the fader is up. This should not be confused with a Mic Live light.
Page 42 –50dB input when shipped. The line preset, P3, provides 16dB of gain adjustment, allowing an input range of +6dB to –10dB referenced to 0dB output. The preset should be adjusted to give 0dB output for the S2 User Handbook...
Page 43 A third preset, P9, sets the VCA fader gain to 0dB when the fader is fully open. This is preset on ﬁnal test and should not require further adjustment, unless it has been found necessary to replace the fader or other VCA components. S2 User Handbook...
Page 44: S2-Cmm Mic/Mic Channel With Eq
S 2 - C M M M I C / M I C C H A N N E L W I T H E Q 6 S2-CMM Mic/Mic Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.
Page 45: Rear Panel
Pin 3: Non-phase. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; • Mic 1 cue light • Mic 2 cue light • Cough/reverse talkback switch • Talkback mic enable S2 User Handbook...
Page 46: Channel Options, Jumper Settings And Presets
Enable full LF response on microphone inputs. • Enable the Insert Point. • Select momentary or Cue Light. • Select monitor mute for studio or control room. • Select timer option. • Enable or disable Cue/PFL cancel from fader. S2 User Handbook...
Page 47 Not Fitted 1 & 2 Control room monitor mute from Microphone 2 input. 2 & 3 Studio monitor mute from Microphone 2 input. None No mute function. Note: Options in bold are set as default when shipped. S2 User Handbook...
Page 48: Fig 6-1 : S2 Mic/Mic Input Board Layout
Mic 2 J13 J15 Mute 1 Mute 2 Fig 6-1 : S2 Mic/Mic Input Board Layout. Remote for Mic 1 Cue Light The remote output for the Microphone 1 input can be used to operate a Mic Cue light when the channel is ON and the fader is up.
Page 49 A third preset, P9, sets the VCA fader gain to 0dB when the fader is fully open. This is preset on ﬁnal test and should not require further adjustment, unless it has been found necessary to replace the fader or other VCA components. S2 User Handbook...
Page 50: S2-Cse/S2-Cs Dual Stereo Line Channel With & Without Eq
S 2 - C S E / S 2 - C S D UA L S T E R E O L I N E C H A N N E L W I T H & W I T H O U T E Q 7 S2-CSE/S2-CS Dual Stereo Line Channel With & Without EQ...
Page 51: Rear Panel
Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; • Line 1 remote start • Line 1 remote stop • Line 2 remote start • Line 2 remote stop S2 User Handbook...
Page 52: Channel Options, Jumper Settings And Presets
Select momentary or latched start for Input 1. • Select momentary or latched start for Input 2. • Enable continuous momentary start from ON button. • Enable or disable Cue/PFL cancel from fader. • Select timer option. S2 User Handbook...
Page 53: Fig 7-1 : S2 Dual Stereo Input With & Without Eq Board Layout
J6A = Timer 1 B = Timer 2 Options Fig 7-1 : S2 Dual Stereo Input With & Without EQ Board Layout. Remote for Line 1 Input The remote output for the Line 1 input can be used for a start and stop function wired to other studio equipment such as CD or MD players.
Page 54 –10dB referenced to 0dB output. The presets should be adjusted to give 0dB output for the chosen source, and will cater for professional equipment with nominal output levels up to +4dB and non-professional equipment with nominal output levels down to –10dBV. The levels are preset for 0dB input when shipped. S2 User Handbook...
Page 55 ON. This setting is then applied by pressing the ON button. The PGM button will ﬂash quickly for about a second to indicate that the setting is stored. General Purpose I/O Function Options GPIO Function CUE/PFL ON Button Input / Latching / Active Low / Button Button Output Momentary Active High S2 User Handbook...
Page 56 Once the ON button is pressed, this setting is stored and the action can be selected. • After the next ON button press, the module will exit the setup procedure and the module can now be used as normal. S2 User Handbook...
Page 57: S2-Csge/S2-Csg Stereo Line And Gram Channel With & Without Eq
S 2 - C S G E / S 2 - C S G S T E R E O L I N E A N D G R A M C H A N N E L W I T H & W I T H O U T E Q 8 S2-CSGE/S2-CSG Stereo Line And Gram Channel With & Without EQ...
Page 58: Rear Panel
Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; • Line 1 remote start • Line 1 remote stop • Line 2 remote start • Line 2 remote stop S2 User Handbook...
Page 59: Channel Options, Jumper Settings And Presets
Select momentary or latched start for Input 1. • Select momentary or latched start for Input 2. • Enable continuous momentary start from ON button. • Enable or disable Cue/PFL cancel from fader. • Select timer option. S2 User Handbook...
Page 60: Fig 8-1 : S2 Stereo Line & Gram With & Without Eq Board Layout
J4 = Fader Cancel Cue/PFL Dual Stereo with EQ J5 = Unused Analogue LK10 J6A = Timer 1 B = Timer 2 LK11 Jumper J1-J4 Options Fig 8-1 : S2 Stereo Line & Gram With & Without EQ Board Layout. S2 User Handbook...
Page 61 0dB output. The presets should be adjusted to give 0dB output for the chosen source, and will cater for professional equipment with nominal output levels up to +4dB and non-professional equipment with nominal output levels down to –10dBV. The levels are preset for 0dB input when shipped. S2 User Handbook...
Page 62 • Now select GPIO 1’s action using the PGM button as before. Currently this can only be set to the module ON action or none (as shown in the table below), by illumination of the ON button. S2 User Handbook...
Page 63 Once the ON button is pressed, this setting is stored and the action can be selected. • After the next ON button press, the module will exit the setup procedure and the module can now be used as normal. S2 User Handbook...
Page 64: S2-Cdse/S2-Cds Digital Dual Stereo Line Channel With & Without Eq
S T E R E O L I N E C H A N N E L W I T H & W I T H O U T E Q 9 S2 -CDSE/S2-CDS Digital Dual Stereo Line Channel With & Without EQ...
Page 65: Rear Panel
Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; • Line 1 remote start • Line 1 remote stop • Line 2 remote start • Line 2 remote stop S2 User Handbook...
Page 66: Channel Options, Jumper Settings And Presets
Select momentary or latched start for Input 2 remote output. • Enable continuous momentary start from ON button. • Enable or disable Cue/PFL cancel from fader. • Select timer option. • Select AES/EBU or S/PDIF for Input 1. • Select AES/EBU or S/PDIF for Input 2. S2 User Handbook...
Page 67: Fig 9-1 : S2 Digital Dual Stereo Input Board Layout
J6A = Timer 1 B = Timer 2 LK12 J11 = Unlocked PFL Mute Jumper J1-J5 Jumpers J7 &J8 Options Pos. A = AES Pos. B = SPDIF Input 1 Input 2 Fig 9-1 : S2 Digital Dual Stereo Input Board Layout. S2 User Handbook...
Page 68 1 & 2 will start Timer 1, shifting the jumper to pins 2 & 3 will start Timer 2. The default setting of J6 is none (not ﬁtted). Jumpers J7 to J10 are not ﬁtted to this channel. S2 User Handbook...
Page 69 PGM button until only the CUE/PFL button is illuminated ON. This setting is then applied by pressing the ON button. The PGM button will ﬂash quickly for about a second to indicate that the setting is stored. S2 User Handbook...
Page 70 Once the ON button is pressed, this setting is stored and the action can be selected. • After the next ON button press, the module will exit the setup procedure and the module can now be used as normal. S2 User Handbook...
Page 71: S2-C6Ss 6 Way Stereo Line Source Select Channel With Eq
S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ 10 S2-C6SS 6 Way Stereo Line Source Select Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses. The buttons are illuminated in green to indicate the routing status.
Page 72 S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ ON Selection The ON button works in conjunction with the fader and is used to control channel remotes, routing, timers, etc. The button shows various states. When unlit the channel is oﬀ. Flashing red indicates that the channel has been selected to ON but remains unrouted i.e.
Page 73: Channel Options, Jumper Settings And Presets
S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ Source Remotes Connector This 25 pin D type plug provides remote start/stop outputs for all the sources, and has the following connections; Pin 1: Screen, chassis. Pin 2: OS 1 Start.
Page 74: Fig 10-1 : S2 6 Way Source Selector Board Layout
J1J2J3 Logic A - Timer 1 B = Timer 2 Fig 10-1 : S2 6 Way Source Selector Board Layout. Cue/PFL Cancel The Cue/PFL function is normally an alternate action. Press the button to select and press again to de-select. However it may be desirable to have the fader up signal cancel a Cue/PFL selection.
Page 75 S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ Source Remotes The remote outputs for the six sources can be used for a start and stop function wired to other studio equipment such as CDs or MDs. The default setting for J3 is none (not ﬁtted), which produces a momentary remote contact.
Page 76: S2-Ct Telco Channel With Eq
S 2 - C T T E LCO C H A N N E L W I T H E Q 11 S2-CT Telco Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.
Page 77: Rear Panel
Pin 8: No connection. Pin 9: No connection. Cleanfeed Output Connector This XLR 3 pin plug is a balanced line level output intended to be fed back to the TBU. Pin 1: Screen. Pin 2: Phase. Pin 3: Non-phase. S2 User Handbook...
Page 78: Channel Options, Jumper Settings And Presets
Set-up for cleanfeed bus 2. 1 & 2 Set-up for cleanfeed bus 1. 2 & 3 Set-up for cleanfeed bus 2. Not Fitted Not Fitted Not Fitted Note: Options in bold are set as default when shipped. S2 User Handbook...
Page 79: Fig 11-1 : S2 Telco Input Board Layout
Cleanfeed Mix-Minus Null Fig 11-1 : S2 Telco Input Board Layout. Remote for Hybrid Hold The remote output of the Telco channel can be used to hold the line on a telephone hybrid when the channel is ON and the fader is up. The hybrid is also put on hold when the Cue/ PFL &...
Page 80 Depending on whether you have 1, 2 or no telco channels ﬁtted, you may have to alter the cleanfeed bus termination on the digital PGM and AUD Output channels. Please refer to that section of the handbook for further info. S2 User Handbook...
Page 81: S2-Csmm Stereo Mix Minus Channel With Eq
S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ 12 S2 CSMM Stereo Mix Minus Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses. The buttons are illuminated in green to indicate the routing status.
Page 82: Rear Panel
S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Fader The 100mm VCA fader provides unity gain when fully open. The channel input signal is routed to the outputs whenever the fader is open, the ON button is selected and either or both of the routing buttons are selected.
Page 83: Channel Options, Jumper Settings And Presets
S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ The connector pin-out is as follows; Pin 1: Opto isolated Line input start NPN collector. Pin 2: Common NPN emitter for Line 1 start and stop. Pin 3: Opto isolated Line input stop NPN collector.
Page 84: Fig 12-1 : S2 Stereo Mix-Minus Board Layout
P9 & P10 1kHz Null P11 & P12 100Hz Null Jumper Options = Latch Start I/P 1 = Cont. Mom. Start = Fader Cancel Cue/PFL J6A = Timer 1 B = Timer 2 Fig 12-1 : S2 Stereo Mix-Minus Board Layout. S2 User Handbook...
Page 85 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Remote for Line Input The remote output for the Line input can be used for a start and stop function wired to other studio equipment such as CD or MD players. The default setting for J1 is none (not ﬁtted), which produces a momentary remote contact.
Page 86 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Eight presets are used to adjust the cleanfeed null for the left and right channels. Cleanfeed is derived from the PGM or AUD output busses and are set up as follows. With the channel...
Page 87 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ General Purpose I/O Function Options GPIO Function CUE/PFL ON Button Input / Latching / Active Low / Button Button Output Momentary Active High • Now select GPIO 1’s action using the PGM button as before. This can be set to the Talkback control action, the module ON action, or none (as shown in the table below), by illumination of the ON button and CUE/PFL button.
Page 88: 13 Output Channels
16 to 24 bits. The balanced analogue PGM output and mono output is available on a 15 way D type connector. Button switches at the top of the channel select the mono output source. The S2-ODPF version has output faders for production use.
Page 89: S2-Oms Studio Monitor Channel
An illuminated Mute LED shows when a live microphone channel in the control room has muted the control room speakers. S2-OMS Studio Monitor Channel The Studio Monitor channel is used for the monitoring of various sources on the studio loudspeakers and headphones. A suitable power ampliﬁer connected to the channel monitor output must be used to drive the loudspeakers.
Page 90: S2-Odpf/S2-Odp Digital Output Pgm Channel With & Without Master Fader
P G M C H A N N E L W I T H & W I T H O U T M A S T E R FA D E R 14 S2-ODPF/S2-ODP Digital Output PGM Channel With & Without Master Fader...
Page 91: Rear Panel
Pin 9: PGM left output non-phase. Pin 10: PGM right output non-phase. Pin 11: No connection. Pin 12: No connection. Pin 13: Mono output non-phase. Pin 14: Control Room mute relay contact 1B. Pin 15: Control Room mute relay contact 2B. S2 User Handbook...
Page 92: Channel Options, Jumper Settings And Presets
The standard options available are; • Cleanfeed mix bus termination. • Select mode and sample rate. • Select output sample size. • Select channel status bits. • Select AES/EBU or S/PDIF output. • Select AES/EBU or S/PDIF sync input. S2 User Handbook...
Page 93 S/PDIF sync input selected. 1 & 2 AES/EBU sync input selected. 2 & 3 S/PDIF sync input selected. 1 & 2 S/PDIF output selected. 2 & 3 AES/EBU output selected. Note: Options in bold are set as default when shipped. S2 User Handbook...
Page 94: Fig 14-1 : S2 Digital Pgm Output Board Layout
Sym. J11J10 SPDIF Fig 14-2 : S2 Digital PGM Output With Fader Board Layout. Cleanfeed Terminations If the console is supplied without Telco channels then J1 and J2 will be ﬁtted to terminate the cleanfeed mix busses. With one Telco channel only J2 is ﬁtted and with two Telco channels no jumpers are ﬁtted.
Page 95 Fitted Fitted Reserved Fitted Fitted Fitted Fitted Output Bit Depth 16 bits Not Fitted Not Fitted 20 bits Fitted Not Fitted 24 bits Not Fitted Fitted Reserved Fitted Fitted Channel Status Bits Consumer Not Fitted Professional Fitted S2 User Handbook...
Page 96 To calibrate, hold down the PGM button and press the AUD button 5 times. The lock LED on the front panel will ﬂash quickly for 2 – 3 seconds and will return to it’s previous state. The calibration procedure is now complete. S2 User Handbook...
Page 97: S2-Odaf/S2-Oda Digital Output Aud Channel With & Without Master Fader
O U T P U T AU D C H A N N E L W I T H & W I T H O U T M A S T E R FA D E R 15 S2-ODAF/S2-ODA Digital Output AUD Channel With & Without Master Fader...
Page 98: Rear Panel
Pin 9: AUD left output non-phase. Pin 10: AUD right output non-phase. Pin 11: No connection. Pin 12: No connection. Pin 13: No connection. Pin 14: Studio mute relay contact 1B. Pin 15: Studio mute relay contact 2B. S2 User Handbook...
Page 99: Channel Options, Jumper Settings And Presets
LK43, LK45 and LK46 ﬁtted. The standard options available are; • Select mode and sample rate. • Select output sample size. • Select channel status bits. • Select AES/EBU or S/PDIF output. • Select AES/EBU or S/PDIF sync input. S2 User Handbook...
Page 100 S/PDIF sync input selected. 1 & 2 AES/EBU sync input selected. 2 & 3 S/PDIF sync input selected. 1 & 2 S/PDIF output selected. 2 & 3 AES/EBU output selected. Note: Options in bold are set as default when shipped. S2 User Handbook...
Page 101: Fig 15-1 : S2 Digital Aud Output Board Layout
Sym. Sym. J11J10 SPDIF Fig 15-2 : S2 Digital AUD Output With Fader Board Layout. Synchronisation Mode and Sample Rate The following jumpers, J3 to J9, are used for setting the Sync Mode and Sample Rate of the digital output.
Page 102 Fitted Fitted Reserved Fitted Fitted Fitted Fitted Output Bit Depth 16 bits Not Fitted Not Fitted 20 bits Fitted Not Fitted 24 bits Not Fitted Fitted Reserved Fitted Fitted Channel Status Bits Consumer Not Fitted Professional Fitted S2 User Handbook...
Page 103 (i.e. distortion) through the limiting stage. They are all factory set on ﬁnal test and should not be adjusted further. Gain can be altered using P4 and P5 on board versions S2-OP-04 and above, as P8 is no longer ﬁtted on these boards.
Page 104: 16 S2-Omc Control Room Monitor Channel
S 2 - O M C CO N T R O L R O O M M O N I TO R C H A N N E L 16 S2-OMC Control Room Monitor Channel Panel Controls PGM, AUD, EXT 1 & EXT 2 Selection The electronically interlocking PGM, AUD, EXT 1 &...
Page 105: Rear Panel
Tip: Talkback audio. Ring: Talkback control. Sleeve: Screen. Talkback Output Connector This standard 6.35mm jack socket is used for the continuous talkback output, and has the following connections; Tip: Talkback audio. Ring: No connection. Sleeve: Screen. S2 User Handbook...
Page 106: Channel Options And Jumper Settings
Note: Options in bold are set as default when shipped. Jumper Options J1 = Global T/B Enable J2 = LS T/B Enable J3 = LS Dim Enable C/Room J4 = HP Dim Enable LK10 Fig 16-1 : Control Room Monitor Board Layout. S2 User Handbook...
Page 107 With J4 enabled, incoming talkback will dim the headphone source by –12dB and talkback will be heard at normal level. The default setting for J4 is disabled (not ﬁtted). Presets There are no presets to adjust on the control room monitor channel. S2 User Handbook...
Page 108: 17 S2-Oms Studio Monitor Channel
S 2 - O M S S T U D I O M O N I TO R C H A N N E L 17 S2-OMS Studio Monitor Channel Panel Controls PGM, AUD, EXT 1 & EXT 2 Selection The electronically interlocking PGM, AUD, EXT 1 &...
Page 109: Rear Panel
This standard 6.35mm jack socket is the output for the studio monitor loudspeakers, and has the following connections; Tip: Left channel. Ring: Right channel. Sleeve: Screen. A suitable ampliﬁer should be used to send this signal to the loudspeakers, or connect active loudspeakers directly to this output. S2 User Handbook...
Page 110: Channel Options And Jumper Settings
Note: Options in bold are set as default when shipped. Jumper Options J1 = Global T/B Enable J2 = LS T/B Enable J3 = LS Dim Enable J4 = HP Dim Enable LK11 Studio Fig 17-1 : Studio Monitor Board Layout. S2 User Handbook...
Page 111 With J4 enabled, incloming talkback will dim the headphone source by –12dB and talkback will be heard at normal level. The default setting for J4 is disabled (not ﬁtted). Presets There are no presets to tamper with on the studio monitor channel. S2 User Handbook...
Page 112: 18 Meterbridge Modules
6 other mixers or dedicated talkback systems, and the S2-MTBS is used for interfacing with a Sonifex Station Master. A 3 button switch panel, S2-MSB3, is a meterbridge panel, 1 channel wide, with 3 buttons which can be used for bespoke control of the S2, or for your own purposes, e.g. equipment control. S2-MPPM Meterbridge PPM panel.
Page 113: Meterbridge Distribution Board
Six connectors on the board provide power and various signals to the meterbridge modules and it is therefore possible, where space permits, to install 1 x S2-ML, 1 x S2-MT, and up to three of your chosen style of meter panels. Meters can be conﬁgured to display PFL, PGM, or Monitor, which is the signal selected by the buttons on the PGM output module.
Page 114: S2-Mb1-5 Meterbridge Blanking Plates
Meterbridge blanking plates are available in channel widths from 1 to 5 inclusive and are used to ﬁll areas in the meterbridge not occupied by active modules. S2-ML Meterbridge Loudspeaker Monitor Panel Fig 18-3 : Loudspeaker Monitor Panel. The speaker is used for monitoring PFL and reverse talkback in the control room directly from the mixer.
Page 115: S2-Mvu Meterbridge Vu Meter Panel, S2-Mppm Ppm Meter Panel, S2-Mppt True Ppm Meter Panel & S2-Ml53 Led Meter Panel
M E T E R B R I D G E M O D U L E S S2-MVU Meterbridge VU Meter Panel, S2-MPPM PPM Meter Panel, S2-MPPT True PPM Meter Panel & S2-ML53 LED Meter Panel Fig 18-4 : PPM & True PPM Meter Panel.
Page 116: Fig 18-6 : Vu & Ppm Led Meter Panel
PGM output, will indicate a meter reading of 4. Each mark on the PPM scale indicates a 4dB change in signal level. The S2-MVU two moving coil VU meters will be conﬁgured such that a 1kHz signal, at +4dBu at the PGM output, will indicate a meter reading of 0VU.
Page 117: S2-Mph Meterbridge Phase Meter Panel
Illuminated LEDs indicate the relevant source shown on the meters. The S2-ML53 has an adjustable pot accessible from the front panel which alters the meter brightness, this can be altered using a jewellers screwdriver.
Page 118: S2-Mtb6 Meterbridge 6 Way Talkback Panel
S2-MTB6 Meterbridge 6 Way Talkback Panel Fig 18-8 : Meterbridge 6 Way Talkback Panel. The S2-MTB6 Meterbridge Talkback Panel is used for communicating with up to 6 other locations. While a button is pressed, the switch is illuminated and the talkback is active. The buttons work with both a momentary and latched operation.
Page 119: S2-Mtbs Meterbridge Station Master Talkback Panel
This 9 pin D type plug is used for connecting the Talkback module to the Control Room Monitor channel. The connection cable is supplied with the Talkback module, which plugs into the S2-MTB6 via the mixer meterbridge housing, and down into the two talkback jack sockets on the rear of the Control Room channel.
Page 120 Master manual for functionality and connection information. Rear Panel Station Master Talkback Connector This 25 pin D type socket is used for connecting to the Talkback connector on a Sonifex Station Master. The connector pin-out is as follows; Pin 1: +15V.
Page 121: S2-Msb3 S2 Meterbridge Switch Panel With 3 Buttons
S2-MSB3 S2 Meterbridge Switch Panel With 3 Buttons This is a meterbridge panel, 1 channel wide, with 3 buttons which can be used for bespoke control of the S2, or for your own purposes, e.g. equipment control. S2-MT Meterbridge Timer Panel...
Page 122 Pin 2: Receive Data (From PC). Pin 3: Transmit Data (To PC). Pin 4: DTR. Pin 5: Ground. Pin 6: DSR. Pin 7: RTS. Pin 8: CTS. Pin 9: No internal connection. NOTE: Only Pins 2 & 3 are currently used. S2 User Handbook...
Page 123 • To increment Option numbers press the same mode button. • To increment/decrement sub option number use the Start/Stop & Reset buttons. • Continue to the last option (14), the next mode press will store the settings. S2 User Handbook...
Page 124 Hold down the upper timer “RESET” button while in TIME mode, a status indication will be displayed. This code is identical to that of the time code output string: 0 = not locked, 1 = signal/not locked, 2 = locked Also note that source number 0 (internal RTC) implies “not locked”. S2 User Handbook...
Page 125 38400 baud 57600 baud 115200 baud RS232 Output Disable Enable RS232 Output Format A time code string can be output from the timer module for use in synchronising other devices to the module. “dd/mm/yy,hh:mm:ss,A,B,C,D,hh:mm:ss.tt,hh:mm:ss.tt,hh:mm:ss.tt\n\r” DATE,TIME,[3 MODE CH],TIMER_1,TIMER_2,MIC_TIMER. S2 User Handbook...
Page 126 If the timer is currently running the event can trigger the timer to reset or continue counting. On an event the display will freeze for a determined number of seconds. S2 User Handbook...
Page 127 On second event freeze display for 3 seconds On second event freeze display for 4 seconds On second event freeze display for 5 seconds Time Setting Disallow while locked to time code source Allow while locked to time code source S2 User Handbook...
Page 128: 19 Technical Speciﬁcations
130Hz with HPF in). Line Inputs: 20Hz to 20kHz –0.5dB, +0dB. RIAA Input: 30Hz to 16kHz ± 1.5dB RIAA equalised. Noise (20Hz to 20kHz) Mic Input E.I.N.: -129dB with 150Ω source. Stereo Inputs (fader down, no routing): -89dB ref 0dB S2 User Handbook...
Page 129 32kHz, 44.1kHz, 48kHz, & 96kHz Output Sample Width: 16, 20, 24 bit Output Headphone Output Load >45 ohms, recommended 400Ω Maximum Output (Analogue) +26dBu balanced into 2k or greater Power Filtered IEC, switchable 115V, 230V, Power Rating (S2-PSU): fused, 210W max. S2 User Handbook...
Page 130 T E C H N I C A L S P E C I F I C AT I O N S S2 Mixer Weights and Boxed Dimensions Mixer Gross Nett Width (cm) Depth (cm) Height (cm) Chassis Type Weight (kg)
Page 131: Glossary
EQualisation. This is the method of cutting or boosting selected bands of frequencies in the signal. S2 User Handbook...
Page 132 Talkback (and reverse talkback, Rev T/B). This is the ability for two or more studios to communicate with each other oﬀ-air. Telco TELephone COmmunication. The telco module is used by the presenter to talk to telephone callers via a hybrid or TBU. Total Harmonic Distortion. S2 User Handbook...
Page 133: Index
Input/Output Gain Range S2-OMC Control Room Monitor Channel Input/Output Impedances S2-OMS Studio Monitor Channel Input Modules S2 Mixer Weights and Boxed Dimensions 118 S2 MPH Meterbridge Phase Meter Panel Safety of Mains Operated Equipment iv, 17 System Block Diagrams Meterbridge Module Types...
Page 134 N OT E S S2 User Handbook...
Page 135 N OT E S S2 User Handbook...
Page 136 w w w . s o n i f e x . c o . u k t:+44 (0)1933 650 700 f:+44 (0)1933 650 726 s a l e s @ s o n i fe x . co. u k...
