Sonifex S1 User Handbook Manual

Radio broadcast mixer, 10 channel analogue-digital
Hide thumbs Also See for S1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Handbook
S1 Radio Broadcast Mixer,
10 Channel Analogue-Digital
User Handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sonifex S1

Summary of Contents for Sonifex S1

  • Page 1 S1 Radio Broadcast Mixer, 10 Channel Analogue-Digital User Handbook...
  • Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Sonifex Ltd. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising form the use of information or any error contained in this manual.

  • Page 3: Table Of Contents

    Warranty and Liability Returning the Warranty Card Unpacking the S1 Safety of Mains Operated Equipment Fuse Rating Power Cable and Connection WEEE & RoHS Directives - Sonifex Statement Reporting Faults 1 Introduction Innovative Design Superb Audio Quality & Unquestionable Reliability Progress...
  • Page 4 Auxiliary bus to record an off air phone call Log the presenter Create a talkback source Use an auxiliary bus to create a clean feed for a hybrid unit User Guide – Section 3-4 External equipment and the S1 Headphone distribution amplifiers Microphone amplifiers Telephone hybrid...
  • Page 5 D Type Connectors List of ports: External Inputs Connector Meterbridge Port Talkback Port Auxiliary Output Connector Mono Remote Connector Stereo Remote Connector Technical Specification Default Settings Serial Communication Protocol Serial Data Format Remote Control Commands Error Messages Glossary S1 User Handbook...
  • Page 6 Fig 1-2: Dimensions & Cut-Out Fig 2-27: Program / Meters Follow Monitors 18 Sizes For S1 Mixer Fig 2-28: PPM / VU Fig 1-3: S1 Mixer Rear View Fig 2-29: PGM Output Fig 1-4: S1 Mixer Top View Fig 2-30: Cleanfeed Outputs...
  • Page 7 Company, the Purchaser shall only be entitled to the benefit of any warranty or guarantee provided by such manufacturer to the Company. In respect of computer software supplied by the Company the Company does not warrant that the use of the software will be uninterrupted or error free. S1 User Handbook...
  • Page 8 Seller in Condition (c). Where the Goods are sold under a consumer transaction (as defined by the Consumer Transactions (Restrictions on Statements) Order 1976) the statutory rights of the Purchaser are not affected by these Conditions of Sale. S1 User Handbook...

  • Page 9: Returning The Warranty Card

    In order to register the date of purchase so that we can keep you informed of any design improvements or modifications, it is important to complete the warranty registration document that is enclosed and return it to Sonifex Ltd in the UK, or register online at www.sonifex.co.uk/register...

  • Page 10: Safety Of Mains Operated Equipment

    If for any reason, you need to use the product with a different power cable, you should use the following wiring guidelines Wire Colour Connection Green, or green and yellow Earth (E) Blue, or Black Neutral (N) Brown, or Red Live (L) S1 User Handbook...

  • Page 11: Weee & Rohs Directives - Sonifex Statement

    It gives a contact for individuals who are unsure about the correct procedure when the product has reached its “end of use”. Sonifex Ltd will be happy to give you information about local organisations that can reprocess the products, or alternatively all products that have reached “end of use” can be returned to Sonifex and will be reprocessed correctly free of charge.

  • Page 12: Reporting Faults

    R E P O R T I N G A FAU LT Reporting Faults Although this Sonifex product is manufactured to the highest standards, it is possible that minor faults may appear in the equipment over its normal lifetime. If you find any problems...

  • Page 13: Introduction

    I N T R O D U C T I O N 1 Introduction The Sonifex S1 Mixer is a compact, low cost, fixed format radio on-air mixing console designed to cater for a wide and far reaching broadcast market. On the surface, it is simple and easy to use but it also has hidden layer of variety and flexibility for those who like to get into the heart of their products, tweak the engine so to speak.

  • Page 14: Superb Audio Quality & Unquestionable Reliability

    Flexible The S1 is a highly configurable unit and has been designed to be jumper free, allowing the user to alter the configuration quickly whilst still on air rather than having to take apart the unit armed with a pair of tweezers and a magnifying glass.

  • Page 15: Atmosphere

    Installation Notes Atmosphere The S1 mixer should be installed in an area which is not subject to excessive heat or cold. Also, you should avoid installing it in atmospheric conditions which are dusty, smoky, or dirty, or where there is moisture or vibration. Do not use any liquids to clean the fascia of the mixer: a soft dry brush is ideal.

  • Page 16: Fig 1-3: S1 Mixer Rear View

    I N T R O D U C T I O N Fig 1-3: S1 Mixer Rear View Fig 1-4: S1 Mixer Top View S1 User Handbook...

  • Page 17: User Guide

    2 User Guide Getting to know your mixer The following section will display and explain the features of S1 Mixer from input through to output. Please read this section thoroughly to acquaint yourself thoroughly with the myriad of options available. However, if you are more interested in setting it up skip to the next chapter - Mixer Applications.

  • Page 18: User Guide - Section

    Stereo XLR Stereo +10dB Stereo XLR Input Phono Stereo Phono Input S/PDIF Aes Receiver Digital Optical Input Digital Source Select +48V Input Trim +10dB Mono Line Input Mono Line Remotes Stereo Line Remotes Fig 2-1: Input Stages S1 User Handbook...

  • Page 19: Fig 2-2: Output & Power Board

    +10dB Additional Connector To F. Panel Presenter EXT 1 External +10dB Inputs EXT 2 Headphones +10dB Guest EXT 2 PGM Output STCF Output Cleanfeed AUX 1 Stereo AUX Outputs AUX 2 Fig 2-2: Output & Power Board S1 User Handbook...

  • Page 20: Fig 2-3: Main Mix Stage

    PFL L HF EQ LF EQ Trim AUX 1 Send PFL R PGM L PGM R AUX 2 AUX 1L Send AUX 1R Insert On Channel 7 Only AUX 2L AUX 2R Fig 2-3: Main Mix Stage S1 User Handbook...

  • Page 21: S1 Input Channels

    User Guide – Section 2-2 Input Channels S1 Input Channels The S1 has 10 fixed format channels with two selectable inputs on each channel: 2 x Mono XLR Mic / Mono XLR Line Inputs 2 x 1 Stereo Jack Line Input...

  • Page 22: Channels 1 And 2 Mic / Line Inputs

    XLR line connectors. Mono Line / Stereo Line Inputs Channel 5 - Mic / Telco Input The telco channel is used to interface the S1 with a telephone hybrid unit. The hybrid unit is connected through an XLR with a Microphone channel provided as an alternative.

  • Page 23: Channel 7 And 8 - Stereo Line / Rca Inputs

    Dual Stereo Line Input channel. External Inputs Two external inputs are available to the S1 through a 9 pin D-Type connector located on the rear panel. The external inputs are used for audio which should be heard in the control room but not on air.

  • Page 24: User Guide - Section 2-3 Front Panel Channel Features

    100 and 150 Hz. Try lowering the LF control on microphone channels to get rid of any unnecessary low frequency audio while slightly boosting the HF to add clarity. Fig 2-15: Equalisation Controls S1 User Handbook...

  • Page 25: Trim Control

    CUE/PFL button except the talkback source is also routed to the respective cleanfeed output when the channel input is set to Input 2 (5. Telco or 6. Stereo Cleanfeed). Fig 2-20: CUE/PFL & T/B Selection S1 User Handbook...

  • Page 26: On Selection

    The channel cannot be opened if the Digital input is not synchronised to a valid source. The button can also flash green and flash orange. Please refer to the tally back portion of section 4 (page 34) for more information. S1 User Handbook...

  • Page 27: Scribble Pad

    If using the auxiliary bus post fade, the fader position also affects the level of the channel on the auxiliary buses. The faders can be forced up for remote control applications using one of the General Purpose Inputs. Fig 2-23: Fader S1 User Handbook...

  • Page 28: User Guide - Section 2-4 Metering And Monitors

    User Guide – Section 2-4 Metering and Monitors Monitor and headphone sockets The S1 provides a monitoring system to monitor all output channels or the external inputs. The is useful for setting up the mixer outputs or to simply listen to the mix in a control room.

  • Page 29: Monitor And Headphone Controls

    Control Room mute, goes live. This will mute the control room monitors to prevent feedback. Two pairs of contacts on the remote connector of the PGM output channel will close whenever the mute function is active. These can be used to remotely illuminate “Mic Live” lights. S1 User Handbook...

  • Page 30: Dim / Mute

    PGM Output The PGM output provides stereo balanced XLR outputs. The PGM Output is used as the main transmission bus. All channels that are on and faded in are mixed on to this bus. Fig 2-29: PGM Output S1 User Handbook...

  • Page 31: Cleanfeed Outputs

    Fig 2-30: Cleanfeed Outputs Digital Outputs The S1 has two digital outputs that work at the same time. The first is AES/EBU which is on a balanced XLR connector. The second is S/PDIF which is found on an unbalanced RCA connector.

  • Page 32: Auxiliary Outputs

    U S E R G U I D E Auxiliary Outputs The S1 has two auxiliary buses so that alternative outputs from the PGM can be created and used. The mix that is created on these buses is available from a 9 pin d-type connector which is located on the rear panel.

  • Page 33: Mixer Applications

    Before reading this section it is recommended that you familiarise yourself with all the different types of connectors and cabling that is used on the S1. Please refer to appendix A. The following section is divided into these parts: Standard setup and applications.

  • Page 34: Presenter Controlled Studio

    The setup diagrams are divided into 3 figures for clarity. Flashcard/USB Player CD Player Transmitter PC Running Sonifex SCi For Setup & Control PC Radio Playout Software S1 Mixer (Rear View - Flipped upside down) Amplifier Speakers Sonifex SignalLED S1 Mixer Illuminated Signs (Top View)

  • Page 35: Fig 3-1B: Presenter In Studio - Telephone Line Connections

    M I X E R A P P L I C AT I O N S Telephone Sonifex HY-03 TelephoneHybrid S1 Mixer (Rear View - Flipped upside down) S1 Mixer (Top View) Studio Fig 3-1b: Presenter In Studio - Telephone Line Connections S1 User Handbook...

  • Page 36: Fig 3-1C: Presenter In Studio - Presenter And Guest Connections

    RB-HD6 (or go directly out of single Presenter guest headphones) Microphone Guest Microphones Presenter Headphone S1 Mixer (Rear View - Flipped upside down) S1 Mixer (Top View) Studio Fig 3-1c: Presenter In Studio - Presenter and Guest Connections S1 User Handbook...

  • Page 37: Producer Controlled Studio With Seperate Presenter

    Again, the setup diagram is split into 3 figures for clarity. Flashcard/USB Player CD Player Transmitter PC Running Sonifex SCi For Setup & Control PC Radio Playout Software S1 Mixer (Rear View - Flipped upside down) Amplifier Speakers Sonifex SignalLED S1 Mixer Illuminated Signs...

  • Page 38: Fig 3-2B: Presenter And Producer In Control Room - Telephone Line Connections

    M I X E R A P P L I C AT I O N S Telephone Telephone Sonifex HY-03T TelephoneHybrid S1 Mixer (Rear View - Flipped upside down) S1 Mixer (Top View) Control Room Fig 3-2b: Presenter And Producer In Control Room - Telephone Line Connections S1 User Handbook...

  • Page 39: Fig 3-2C: Presenter And Producer In Control Room - Presenter And Guest Connections

    Microphone Headphones Headphones Sonifex Redbox RB-HD6 Producer Microphone Producer Headphone S1 Mixer (Rear View - Flipped upside down) S1 Mixer (Top View) Control Room Fig 3-2c: Presenter And Producer In Control Room - Presenter and Guest Connections S1 User Handbook...

  • Page 40: Global Talkback

    CD player, jingle player etc to also trigger the logging equipment if this option is available. Find out more about the remote control ports in chapter 4. S1 User Handbook...

  • Page 41: Create A Talkback Source

    The presenter can press CUE PFL on the second hybrid channel to listen to the caller. User Guide – Section 3-4 External equipment and the S1 Most of the equipment needed such as microphones, headphones and CD players are self- explanatory.

  • Page 42: Telephone Hybrid

    If your On-Air light is to be mains operated then you should use a suitable opto- isolated solid-state mains relay. The SONIFEX RB-LC3 Light/Power controller is a suitable unit that will control up to three On-Air lights and/or Mic cue lights.

  • Page 43: Use Of The External Inputs

    15V @ 200mA to external equipment if required. Appendix A (Page 44) contains the pin out and pin description for this port. For more information on meterbridge components, please contact Sonifex. S1 User Handbook...

  • Page 44: Advanced Configurations

    The Telco mode sends the start pulse when the channel is initially armed (ON button glows RED) This allows a hybrid to connect before the channel goes live. n this mode the stop signal is generated when the ON button is turned off (not glowing) S1 User Handbook...

  • Page 45: Momentary/Continuous

    User Guide – Section 4-2 General purpose inputs and outputs The S1 has five General Purpose Inputs/Outputs (GPIO) available. Each GPIO has been designed to be very versatile & almost any operation with the mixer can be achieved when utilising them.

  • Page 46: General Purpose Outputs

    When the GPI becomes active the ON button will flash green. To configure all GPIO and tally modes, please refer to the SCi section S1 User Handbook...

  • Page 47: User Guide - Section 4-3 Sci And The S1

    SCi for S1 SCi allows the user control and configure the S1 Mixer remotely via RS-232. When using SCi for the S1 Mixer, itshould not be run with a display resolution less than 1024x768. 1280x1024 is recommended. The user interface consists of the main screen showing the status of the mixing desk and configuration screens for individual channels, system settings and GPIO.

  • Page 48: Main Screen

    The following buttons also have additional options: Input Select: • Set input to A or B (orC for channels 3 & 4) Disable Mono or Stereo input (channels 3 & 4 only) S1 User Handbook...

  • Page 49: Channel Configuration

    Channel Configuration Each channel can be configured and tailored to your requirements through the Channel Configuration screen. This is accessed via the “CONFIG” button bellow the virtual scribble pad for each channel. Fig 4-4: Channel Configuration Screen S1 User Handbook...

  • Page 50: Channel Information Box

    • Telco Mode with CUE/PFL – As per Telco Mode but with the addition of being started when the CUE/PFL button is activated and stopped when it is deactivated. Start Function: This sets whether the Start function is continuous (remains active) or momentary (active for a approximately half a second) S1 User Handbook...

  • Page 51: Stop Function

    Timers This allows you to configure which inputs will trigger a timer signal when the channel becomes routed. This is used with an external timer device such as the Sonifex S2-MT Meterbridge Timer Panel. GPIO Configuration The GPIO screen allows the configuration of up to 10 functions for each GPI/GPO and also options for the functions.

  • Page 52: System Configuration

    This configures the internal memory of the S1 Auto Save Desk State to Memory: This enables or disables the desk state tracking function within the S1. When enabled, the state of the desk including buttons is saved every 10 seconds, unless a button is pressed within those 10 seconds.

  • Page 53: Aux Buttons Box

    The very top selects maximum intensity and the very bottom selects the lowest intensity. For the meters the lowest intensity is off, this is useful when using an external meter display such as the Sonifex S2-MPPT True PPM Meter Panel.

  • Page 54: Guest Headphones

    First, configure the desk as desired. Secondly, click “Save Configuration” and save. To reload the settings, click “Load Configuration” and select your configuration file. Restore defaults: This restores the S1 to factory defaults. Refer to the rest of the manual for information. S1 User Handbook...

  • Page 55: Update Firmware

    “Update Firmware”, select the DWN file and click Open. It is vital that neither the serial connection nor mains power to the S1 should be interrupted during the update process. If this should happen or the update is unsuccessful for any other reason, the S1 will enter a bootstrap mode.

  • Page 56: Connectors And Cabling

    If you need bespoke cables making, please ensure that a qualified engineer carries out the work. The main types of connectors used with the S1 mixers are the following: XLR 3 Pin Connectors The following diagram shows the pin details for the 3 pin XLR sockets and plugs: Line, Mic &...

  • Page 57: 6.35Mm 'A' Gauge Stereo Jack Plugs

    Fig 5-4: 6.35mm ‘A’ Gauge Stereo Jack Plugs D Type Connectors Several different D type connectors are used on the S1. A 25 pin plug is used for the remotes. A 9 pin socket is use for the external inputs, Auxiliary outputs, RS232, & Talkback Interface.

  • Page 58: External Inputs Connector

    Pin 8: Ext 2 left non-phase. Pin 9: Ext 2 right non-phase. Meterbridge Port Pin 1: METER AUDIO LEFT Audio being displayed on the S1 meter Pin 2: CUE PFL CONTROL Logic output to indicate a pfl button is pressed Pin 3: TIMER 2 Used to start and stop timer modules.

  • Page 59: Auxiliary Output Connector

    Pin 18: GPIO 2 Pin 19: Channel 3 Line Stop Pin 20: DGND Pin 21: Channel 4 Mic Start Pin 22: Channel 4 Line Start Pin 23: GPIO 4 Pin 24: Channel 5 Line Stop Pin 25: DGND S1 User Handbook...

  • Page 60: Stereo Remote Connector

    Pin 20: Channel 8 Input 2 Stop Pin 21: Channel 9 Input 1 Start Pin 22: Channel 9 Input 2 Start Pin 23: DGND Pin 24: Channel 10 Input 1 Stop Pin 25: Channel 10 Input 2 Stop S1 User Handbook...

  • Page 61: Technical Specification

    TRIM pot ± 12dB Telco Output: Stereo Cleanfeed Input: Switch 0dB to +10dB ref 0dBu, TRIM pot ± 12dB Stereo Cleanfeed Output: Digital Input: 0dBFS = +18dBu on input; TRIM pot ± 12dB Digital Output: 0dBFS = +18dBu S1 User Handbook...
  • Page 62 Stereo Inputs (unity gain, two -83 dBu channels routed): Distortion Total Harmonic Distortion: 0.015% at 1kHz, 0dBu 0.015% at 10kHz, 0dBu Crosstalk Inter-channel: > -80dBu typically Equalisation Shelving at 100Hz. ± 7dB Shelving at 6.5kHz. ± 7dB Range S1 User Handbook...
  • Page 63 Output Sample Rates (Using 32kHz, 44.1kHz, 48kHz, & 96kHz Onboard Clock): Output Sample Width: 24 bit Output Headphone Output Load >45 ohms, recommended 400 Maximum Output (Analogue) +26dBu balanced into 2k or greater Weight Unit 10.5 Kg S1 User Handbook...

  • Page 64: Default Settings

    D E FAU LT S E T T I N G S Default Settings The S1 Mixer is supplied with factory defaults set as follows. The unit can be returned to this state via SCi (see page 43) or by holding down the AUX Pre/Post and the RM/MFM buttons during power up.
  • Page 65 Command Disabled Timers Timer 1 on input 1 Disabled Disabled Disabled See TMR: Timer 1 on input 2 Disabled Disabled Command Disabled Timer 2 on input 1 Disabled Disabled Disabled Timer 2 on input 2 Disabled Disabled S1 User Handbook...

  • Page 66: Serial Communication Protocol

    S E R I A L CO M M U N I C AT I O N P R OTO CO L Serial Communication Protocol Sonifex SCi remote control software handles all communication with the S1 via a convenient graphical user interface. However, this protocol is provided for those users who wish to develop their own remote control applications or communicate with the S1 using a text-based terminal program.
  • Page 67 0 = Normal Operation AUX:a? Read Auxiliary Button Status AUX:a,b,c,d A = Channel number. (see above) Bnn: Baud Rate ACK: (at old rate) Nn=11 (115200) Nn=57 (57600) Nn=38 (38400) Nn=19 (19200) Nn=96 (9600) BSV: Base Firmware Version BSV:x S1 User Handbook...
  • Page 68 A = Red B = Green C = Green / Orange D = Red / Orange E = 3MM RED LEDs Hex Values for each colour can be in the range 0-f COL:? Read Colour Values COL:a,b,c,d,e S1 User Handbook...
  • Page 69 0 = ON / OFF CON:a? Read ON Button Status CON:a,b,c,d,e,f,g,h,i A = Channel number. (see above) H = Fader Position 0 = Fader Down 1 = Fader Up I = Channel Routed 0 = Not Routed 1 = Routed S1 User Handbook...
  • Page 70 1 = Auto save desk state enabled 0 = Disabled EEP:? Read EEPROM Status EEP:a,b,c C = EEPROM Auto Save Error GPI:a,b Configure GPIO A = GPIO Pin Number ( 1 – 5) B = Data ACK: S1 User Handbook...
  • Page 71 Read Control Room Mute Status MCH:a,b,c A = Channel number. (see above) MFM:a,||b Configure Meter Follows Monitors A = Button Control 1 = on 0 = off B = Lock Out Button 1 = Lock out 0 = Normal Operation ACK: S1 User Handbook...
  • Page 72 0 = Meter Disabled 1 – 7 = Intensity Levels 8 = No Change MTR:? Read Meter Status MTR:a,b OPM:a Configure Digital Synchronisation ACK: a = Mode 0 = Internal 1 = External 2 = External with fallback to internal S1 User Handbook...
  • Page 73 E = Lock Out Button 1 = Lock out 0 = Normal Operation N.B. Mode D is only available on Inputs 5 & 6. If enabled the CUE/PFL Button will on flash when Input 2 is selected. S1 User Handbook...
  • Page 74 If E=1, a GPI must be configured as a tally back for this input (see GPI) N.B. Tally cannot be enabled if the Remotes are not set to TELCO mode If F=1, a GPI must be configured as an Automation Tally Input (see GPI) S1 User Handbook...
  • Page 75 0 = Mix C = Talkback Source 1 = Channel 1 Line 0 = Channel 1 Mic D = Talkback Permanently Routed to Talkback Connector 1 = Always Routed 0 = Only routed when a T/B button is pressed S1 User Handbook...

  • Page 76: Error Messages

    Sy.y is the Stereo board firmware version Error Messages Err:01 Command Not Found Err:02 Missing Parameter Err:04 Parameter out of Range Err:06 Serial Number Write Error Err:07 Command Not Valid in current mode Err:08 EEPROM write is disabled Err:09 TWI / Checksum Error S1 User Handbook...

  • Page 77: Glossary

    This controls the levels (usually of a mono signal) sent to the left and right outputs and is an abbreviation of “panorama”. PFL (CUE) Pre Fade Listen, also called CUE. A function that allows the operator to monitor the pre fader signal independently of the programme output. S1 User Handbook...
  • Page 78 Talkback (and reverse talkback, Rev T/B). This is the ability for two or more studios to communicate with each other off-air. Telco TELephone COmmunication. The telco channel is used by the presenter to talk to telephone callers via a hybrid or TBU. S1 User Handbook...
  • Page 79 N OT E S S1 User Handbook...
  • Page 80 w w w . s o n i f e x . c o . u k t:+44 (0)1933 650 700 f:+44 (0)1933 650 726 s a l e s @ s o n i fe x . co. u k...
