  • Page 1 S2 Digital I/O Analogue Radio Broadcast Mixer User Handbook...
  • Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Sonifex Ltd. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising form the use of information or any error contained in this manual.

  • Page 3: Table Of Contents

    S2-CML Mic/Line Input Channel S2-CMM Mic/Mic Input Channel S2-CS Dual Stereo Line Input Channel S2-CSE Dual Stereo Line Input with EQ Channel S2-CSG Stereo Line with Gram Input Channel S2-CDS Digital Dual Stereo Input Channel S2-CDSE Digital Dual Stereo Input with EQ Channel...
  • Page 4 S2-CSGE/S2-CSG Stereo Line And Gram Channel With & Without EQ Panel Controls Rear Panel Channel Options, Jumper Settings and Presets S2 -CDSE/S2-CDS Digital Dual Stereo Line Channel With & Without EQ Panel Controls Rear Panel Channel Options, Jumper Settings and Presets...
  • Page 5 CO N T E N T S 16 S2-ODAF/S2-ODA Digital Output AUD Channel With & Without Master Fader (Version 1) Panel Controls Rear Panel Channel Options, Jumper Settings and Presets 17 S2-ODAF/S2-ODA Digital Output AUD Channel With & Without Master Fader (Version 2)
  • Page 6 Switch Panel With 1 Button. 145 Without EQ Board Layout. Fig 20-11b : S2-MSB1 Diagram. Fig 8-1 : S2 Stereo Line & Gram With & Fig 20-12a : S2-MSB3 S2 Meterbridge Without EQ Board Layout. Switch Panel With 3 Buttons. 145...

  • Page 7: Warranty And Liability

    Company. In respect of any item manufactured by a person other than the Company, the Purchaser shall only be entitled to the benefit of any warranty or guarantee provided by such manufacturer to the Company. S2 User Handbook...
  • Page 8 Seller in Condition (c). Where the Goods are sold under a consumer transaction (as defined by the Consumer Transactions (Restrictions on Statements) Order 1976) the statutory rights of the Purchaser are not affected by these Conditions of Sale. S2 User Handbook...

  • Page 9: Returning The Warranty Card

    In order to register the date of purchase so that we can keep you informed of any design improvements or modifications, it is important to complete the warranty registration document that is enclosed and return it to Sonifex Ltd in the UK, or register online at www.sonifex.co.uk/register For your own records you should write down the serial number of both the power supply and the mixer chassis (2 for a split desk).

  • Page 10: Safety Of Mains Operated Equipment

    If for any reason, you need to use the product with a different power cable, you should use the following wiring guidelines Wire Colour Connection Green, or green and yellow Earth (E) Blue, or Black Neutral (N) Brown, or Red Live (L) S2 User Handbook...

  • Page 11: Weee & Rohs Directives - Sonifex Statement

    It gives a contact for individuals who are unsure about the correct procedure when the product has reached its “end of use”. Sonifex Ltd will be happy to give you information about local organisations that can reprocess the products, or alternatively all products that have reached “end of use” can be returned to Sonifex and will be reprocessed correctly free of charge.

  • Page 12: Reporting Faults

    R E P O R T I N G A FAU LT Reporting Faults Although this Sonifex product is manufactured to the highest standards, it is possible that minor faults may appear in the equipment over its normal lifetime. If you find any problems...

  • Page 13: Introduction

    Fig 1-1 : S2-15 Chassis Complete with Channels. Innovative Design and 30 channel width mixers. This means S2 can be used for small newsrooms or large on-air situations. The following table shows the model number along with the total channel width.

  • Page 14: Fig 1-2 : S2-7Ss Script Space

    Input channels can be individually removed and repaired whilst still on-air. purposes is easy. maintenance. You can even add another S2 mixer and link them together with a bus connector cable to allow for split desk configurations. S2 User Handbook...

  • Page 15: Superb Audio Quality And Unquestionable Reliability

    Each channel is individually checked twice before being assembled into the finished chassis and the whole unit is tested before shipping. XLR connectors used are an industry standard. mechanical and electronic noise. the mixer. high humidity environments. Features S2 User Handbook...

  • Page 16: Installation Notes

    2 Installation Notes Atmosphere The S2 mixer should be installed in an area which is not subject to excessive heat or cold. Also, you should avoid installing it in atmospheric conditions which are dusty, smoky, or dirty, or where there is moisture or vibration.

  • Page 17: Channel Configuration

    It is recommended that, wherever possible, pre-wired cables are purchased from recommended manufacturers. If you need bespoke cables making, please ensure that a qualified engineer carries out the work. S2 User Handbook...

  • Page 18: Fig 2-3 : Xlr Connectors

    I N S TA L L AT I O N N OT E S The main types of connectors used with the S2 mixers are the following: XLR 3 Pin Connectors The following diagram shows the pin details for the 3 pin XLR sockets and plugs: Line, Mic &...

  • Page 19: Fig 2-6 : 1/4" Jack Connectors

    Fig 2-6 : 1/4” Jack Connectors. D Type Connectors Several different D type connectors are used on the S2. A 9 pin plug is used for the remotes on input channels and external inputs on monitor channels. A 15 pin socket is used for the analogue outputs and mute relays on the output channels.

  • Page 20: Fig 2-8 : 25 Pin D-Type Connectors

    Fig 2-8 : 25 Pin D-Type Connectors. 9 Pin D-Type Plug used 9 Pin D-Type Socket used for Power Connections for Power Interconnect Cable Pin 5 Pin 1 Pin 1 Pin 5 Fig 2-9 : 9 Pin D-Type Power Connectors. S2 User Handbook...

  • Page 21: System Block Diagrams

    AND ROUTING MIX BUS Input Channels Diagram - CSG,CSGE,CS,CSE,CDS,CDSE, and CSMM C6SS AUD PFL C/FEED L R L R L R 1 2 1 2 ROUTING LEFT TO S2-OMC & TRIM TRIM S2-OMS CPU INPUT 1 LINE LEFT LINE 1/2 HF/LF...
  • Page 22 LEFT (S2-CSMM) PGM METERS MONITOR METERS TO CLEANFEED S2-MPPM DUAL PPM METER PANEL RIGHT (S2-CSMM) S2-MPPT TRUE DUAL PPM METER PANEL S2-MVU DUAL VU METER PANEL S2-ML53 DUAL LED BAR GRAPH METER S2-MPH PHASE METER PANEL PFL METERS PHASE METER Fig 2-11 : System Block Diagram (Sheet 2).

  • Page 23: Applications

    Shown below is an example of connecting one of the latching relay contacts on the PGM or AUD modules to a Sonifex RB-LC3. The remote connection on the RB-LC3 is active low. PGM or AUD Output Module D-Type Outputs &...
  • Page 24 In this case it is only necessary to use the start remote, but you will need to make the contact latching by setting a jumper (See the relevant module for jumper settings). S2 User Handbook...

  • Page 25: Removing & Replacing Channels

    Replace the screws, and reattach the cables to the rear of the channel. S2 User Handbook...

  • Page 26: Connecting A Split Desk

    I N S TA L L AT I O N N OT E S Connecting A Split Desk There are three cables used when connecting an S2 mixer split desk configuration. A 16 way IDC cable which connects the two meterbridge distribution boards, A 60 way jacketed IDC cable which connects the two main mixer bus cables and an earth braid cable which connects the two chassis’...

  • Page 27: Fig 2-15 : Cable & Channel Connection

    M4 nut and removing the shakeproof washer. Then place the solder tag of the earth braid cable on the bolt and then replacing the shakeproof and M4 nut. S2 User Handbook...

  • Page 28: Power Supply

    Front Panel The S2-PSU is a 2U high rack-mount unit, which can supply power to the entire range of S2 mixers. A lead with a special 9 pin D-Type socket (see Fig 2-9) on each end is used to connect the power supply to the mixer.

  • Page 29: Rear Panel

    The rear panel of the equipment carries the Serial Number of the machine. The operating voltage of the S2 power supply is selectable at the fuse carrier on the power inlet port of the S2-PSU unit. Ensure that the machine operating voltage is correct for your mains power supply.

  • Page 30: Ordering The Correct Mains Lead

    The safety specification of your S2 power supply complies with local requirements and must be earthed through the mains connector. If for any reason, you need to use the S2 with a different power cable, you should use the following wiring guidelines.

  • Page 31: S2-Psu Power Supply (New Version)

    S2-PSU Power Supply (New Version) Fig 3-3 : New S2-PSU Front Panel. The new 1U sized S2-PSU is pin compatible with the original 2U sized S2-PSU power supply, so can be used as a straight like-for-like swap, using the same connection cables. The...

  • Page 32: Fig 3-4 : New S2-Psu Rear Panel

    16948 or earlier. The S2-PSUS has been redesigned (from April 2011) to work with both 1U and 2U S2-PSU power supplies, but this is only for S2-PSUS switchers with a serial number higher than 16948. Contact Sonifex if you need to replace a 2U S2-PSU and are using an S2-PSUS power supply switcher - either a new version of the S2-PSUS will be required or a 2U S2-PSU power supply will need to be specifically requested.

  • Page 33: Front Panel Indicators

    If the unit is in ‘Joint Mode’ , then both active LEDS will be on. In this case, if the same rails are good on both, the primary S2-PSU will be supplying the power for those rails.

  • Page 34: Rear Panel

    S2-PSUS, indicated by the alternating front led sequence. Usage Advice The unit has been designed to give the user as little down time as possible. If an S2-PSU rail reaches an unrecoverable state, please remove and service it. If an extreme fault occurs (total loss of power) on the +VD rail, the switch over can cause a reset of digital modules which will result in a small audio glitch.
  • Page 35 2U S2-PSU. Please Note: There are two jumpers inside the unit to configure it to work with the two types of S2 Power Supply that have been manufactured: the original 2U 19” rack power supply and the new universal input voltage 1U 19”...

  • Page 36: Fig 3-7: New S2-Psu Diagram

    P O W E R S U P P LY The factory default is set to the new 1U S2-PSU. Should you be configuring the S2-PSUS to work with a 2U S2-PSU, you have to modify the appropriate jumper/jumpers as shown overleaf.

  • Page 37: Input Channels

    The Mic/Mic Input channel has all the features of the Mic/Line Input channel except that the Line input is replaced by a second Mic input. S2-CS Dual Stereo Line Input Channel The Dual Stereo Input channel has two balanced stereo inputs with a button switch to select between them.

  • Page 38: S2-Cse Dual Stereo Line Input With Eq Channel

    I N P U T C H A N N E L S S2-CSE Dual Stereo Line Input with EQ Channel This channel is the Dual Stereo Input channel as above but fitted with equalisation, providing 7dB cut and boost at HF (6.5kHz) and LF (100Hz).

  • Page 39: S2-Csmm Stereo Mix-Minus Channel

    9 way D type plug are fed from NPN opto-isolators. S2-PG S2 Penny & Giles Conductive Plastic Fader The input and output channels of an S2 mixer can optionally be fitted with high quality Penny & Giles faders.

  • Page 40: S2-Cml Mic/Line Channel With Eq

    S 2 - C M L M I C / L I N E C H A N N E L W I T H E Q 5 S2-CML Mic/Line Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.

  • Page 41: Rear Panel

    This XLR 3 pin socket is used for the electronically balanced line input and has the following connections; Pin 1: Screen. Pin 2: Phase. Pin 3: Non-phase. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; S2 User Handbook...

  • Page 42: Channel Options, Jumper Settings And Presets

    J1 to J5 and channel identifying links. The Mic/Line channel is identified by having links LK14 and LK15 fitted. Other, customer specific, options can be programmed into the software by special order. Special logic options will be identified by having links LK23 and LK24 fitted. The standard options available are; S2 User Handbook...
  • Page 43 Control room monitor mute from Line input. 2 & 3 Studio monitor mute from Line input. None No mute function. 1&2 MIC1 is selected as Talkback input 2&3 Reserved None No Talkback input Note: Options in bold are set as default when shipped. S2 User Handbook...

  • Page 44: Fig 5-1 : S2 Mic/Line Input Board Layout

    LK14 J13 J15 Timer Mute 2 Fig 5-1 : S2 Mic/Line Input Board Layout. Remote for Mic Cue Light The remote output for the Microphone input (Input 1) can be used to operate a Mic Cue light when the channel is ON and the fader is up. This should not be confused with a Mic Live light.
  • Page 45 To enable the microphone input to be added to the talkback bus, connect pins 7 (0V logic) and 9 (Talkback mic enable) on the remote connector. This is useful if, for example, you want to use the mic channel to talk to a caller connected to the cleanfeed output of the telco channel. S2 User Handbook...
  • Page 46 VCA components. Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 47 Mode 1 : Normal. Mode 2 : Always on. The channel cannot be turned off. Mode 3 : Always on and no LED indication. The channel cannot be turned off and the On button LEDs are never active. S2 User Handbook...

  • Page 48: S2-Cmm Mic/Mic Channel With Eq

    S 2 - C M M M I C / M I C C H A N N E L W I T H E Q 6 S2-CMM Mic/Mic Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.

  • Page 49: Rear Panel

    This XLR 3 pin socket is used for the second microphone input, and has the following connections; Pin 1: Screen. Pin 2: Phase. Pin 3: Non-phase. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; S2 User Handbook...

  • Page 50: Channel Options, Jumper Settings And Presets

    J1 to J4 and channel identifying links. The Mic/Mic channel is identified by having links LK16 and LK17 fitted. Other, customer specific, options can be programmed into the software by special order. Special logic options will be identified by having links LK23 and LK24 fitted. The standard options available are; S2 User Handbook...
  • Page 51 Studio monitor mute from Microphone 2 input. None No mute function. 1&2 MIC1 is selected as Talkback input 2&3 MIC2 is selected as Talkback input None No Talkback input Note: Options in bold are set as default when shipped. S2 User Handbook...

  • Page 52: Fig 6-1 : S2 Mic/Mic Input Board Layout

    Mic 2 J13 J15 Mute 1 Mute 2 Fig 6-1 : S2 Mic/Mic Input Board Layout. Remote for Mic 1 Cue Light The remote output for the Microphone 1 input can be used to operate a Mic Cue light when the channel is ON and the fader is up.
  • Page 53 The level is preset for –50dB input when shipped. Presets P5 & P6 are for altering the audio waveform symmetry (i.e. distortion). They are factory set on final test and should not be adjusted further. S2 User Handbook...
  • Page 54 VCA components. Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.

  • Page 55: S2-Cse/S2-Cs Dual Stereo Line Channel With & Without Eq

    S 2 - C S E / S 2 - C S D UA L S T E R E O L I N E C H A N N E L W I T H & W I T H O U T E Q 7 S2-CSE/S2-CS Dual Stereo Line Channel With & Without EQ...

  • Page 56: Rear Panel

    This XLR 3 pin socket is used for the right analogue channel of input 2, and has the following connections; Pin 1: Screen. Pin 2: Phase. Pin 3: Non-phase. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; S2 User Handbook...

  • Page 57: Channel Options, Jumper Settings And Presets

    EQ is identified by having links LK5 and LK11 fitted. Other, customer specific, options can be programmed into the software by special order. Special logic options will be identified by having links LK9 and LK10 fitted. The standard options available are; S2 User Handbook...

  • Page 58: Fig 7-1 : S2 Dual Stereo Input With

    J3 = Cont. Mom. Start from On Button J4 = Fader Cancel Cue/PFL LK10 Analogue J5 = Unused LK11 Jumper J6A = Timer 1 B = Timer 2 J1-J5 Options Fig 7-1 : S2 Dual Stereo Input With & Without EQ Board Layout. S2 User Handbook...
  • Page 59 Four presets are available for adjustment of the input gain, left and right, for the two line inputs. Presets, P1 (left), P2 (right) adjust the levels for Line input 1 and P3 (left), P4 (right) for Line input 2. They provide 16dB of gain adjustment, allowing an input range of +6dB to S2 User Handbook...
  • Page 60 ON. This setting is then applied by pressing the ON button. The PGM button will flash quickly for about a second to indicate that the setting is stored. General Purpose I/O Function Options GPIO Function Cue/PFL Latching/ Active Low/ ON Button Input/Output Button Button Momentary Active High S2 User Handbook...
  • Page 61 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 62 Mode 2 : Always INP2. INP2 is permanently selected. Mode 3 : Always INP1. INP1 is permanently selected. EQ (S2-CSE only) Mode 1 : Normal. Equalization can be enabled or disabled as normal. Mode 2 : Always enabled. Equalization controls are permanently enabled.
  • Page 63 Mode 8 : Always on. The remote start function is activated whenever the ON button is pressed and the fader is up or when PFL is active while the fader is down. S2 User Handbook...

  • Page 64: S2-Csge/S2-Csg Stereo Line And Gram Channel With & Without Eq

    S 2 - C S G E / S 2 - C S G S T E R E O L I N E A N D G R A M C H A N N E L W I T H & W I T H O U T E Q 8 S2-CSGE/S2-CSG Stereo Line And Gram Channel With & Without EQ...

  • Page 65: Rear Panel

    These phono connectors are used for the gram RIAA (turntable) left and right inputs. These inputs have on-board RIAA equalisation suitable for magnetic pick up cartridges. Inner: Phase. Outer: Screen. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; S2 User Handbook...

  • Page 66: Channel Options, Jumper Settings And Presets

    Gram channel with EQ is identified by having links LK7 and LK11 fitted. Other, customer specific, options can be programmed into the software by special order. Special logic options will be identified by having links LK9 and LK10 fitted. The standard options available are; Bal/Pan Control Setup S2 User Handbook...

  • Page 67: Fig 8-1 : S2 Stereo Line & Gram With

    J4 = Fader Cancel Cue/PFL Dual Stereo with EQ J5 = Unused Analogue LK10 J6A = Timer 1 B = Timer 2 LK11 Jumper J1-J4 Options Fig 8-1 : S2 Stereo Line & Gram With & Without EQ Board Layout. S2 User Handbook...
  • Page 68 0dB output. The presets should be adjusted to give 0dB output for the chosen source, and will cater for professional equipment with nominal output levels up to +4dB and non-professional equipment with nominal output levels down to –10dBV. The levels are preset for 0dB input when shipped. S2 User Handbook...
  • Page 69 ON. This setting is then applied by pressing the ON button. The PGM button will flash quickly for about a second to indicate that the setting is stored. General Purpose I/O Function Options GPIO Function Cue/PFL ON Button Latching/ Active Low/ Button Button Input/Output Momentary Active High S2 User Handbook...
  • Page 70 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra...
  • Page 71 Mode 2 : Always INP2. INP2 is permanently selected. Mode 3 : Always INP1. INP1 is permanently selected. EQ (S2-CSGE only) Mode 1 : Normal. Equalization can be enabled or disabled as normal. Mode 2 : Always enabled. Equalization controls are permanently enabled.
  • Page 72 Mode 8 : Always on. The remote start function is activated whenever the ON button is pressed and the fader is up or when PFL is active while the fader is down. S2 User Handbook...

  • Page 73: S2 -Cdse/S2-Cds Digital Dual Stereo Line Channel With & Without Eq

    S T E R E O L I N E C H A N N E L W I T H & W I T H O U T E Q 9 S2 -CDSE/S2-CDS Digital Dual Stereo Line Channel With & Without EQ...

  • Page 74: Rear Panel

    Two phono connectors are used for S/PDIF Inputs 1 and 2. There are on board jumpers to configure this input in place of the AES/EBU inputs . Inner: Signal. Outer: Screen. Remotes Connector This 9 pin D type plug provides inputs and outputs for the following channel functions; S2 User Handbook...

  • Page 75: Channel Options, Jumper Settings And Presets

    EQ is identified by having links LK5 and LK12 fitted. Other, customer specific, options can be programmed into the software by special order. Special logic options will be identified by having links LK9 and LK10 fitted. The standard options available are; S2 User Handbook...

  • Page 76: Fig 9-1 : S2 Digital Dual Stereo Input Board Layout

    J6A = Timer 1 B = Timer 2 LK12 Jumper J11 = Unlocked PFL Mute J1-J5 Jumpers J7 &J8 Options Pos. A = AES Pos. B = SPDIF Input 1 Input 2 Fig 9-1 : S2 Digital Dual Stereo Input Board Layout. S2 User Handbook...
  • Page 77 1 & 2 will start Timer 1, shifting the jumper to pins 2 & 3 will start Timer 2. The default setting of J6 is none (not fitted). Jumpers J7 to J10 are not fitted to this channel. S2 User Handbook...
  • Page 78 PGM button until only the CUE/PFL button is illuminated ON. This setting is then applied by pressing the ON button. The PGM button will flash quickly for about a second to indicate that the setting is stored. S2 User Handbook...
  • Page 79 The remote pin controls the fader open Fader On function. When active, the fader is fully open. Output Functions GPIO Description Cue/PFL Action Button Button Button None Channel The remote pin goes active when the channel is LIVE. S2 User Handbook...
  • Page 80 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 81 S T E R E O L I N E C H A N N E L W I T H & W I T H O U T E Q EQ (S2-CDSE only) Mode 1 : Normal. Equalization can be enabled or disabled as normal.

  • Page 82: S2-C6Ss 6 Way Stereo Line Source Select Channel With Eq

    S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ 10 S2-C6SS 6 Way Stereo Line Source Select Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses. The buttons are illuminated in green to indicate the routing status.
  • Page 83 S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ ON Selection The ON button works in conjunction with the fader and is used to control channel remotes, routing, timers, etc. The button shows various states. When unlit the channel is off. Flashing red indicates that the channel has been selected to ON but remains unrouted i.e.

  • Page 84: Channel Options, Jumper Settings And Presets

    S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ Source Remotes Connector This 25 pin D type plug provides remote start/stop outputs for all the sources, and has the following connections; Pin 1: Screen, chassis. Pin 2: OS 1 Start.

  • Page 85: Fig 10-1 : S2 6 Way Source Selector

    Special A - Timer 1 B = Timer 2 Logic Fig 10-1 : S2 6 Way Source Selector Board Layout. Cue/PFL Cancel The Cue/PFL function is normally an alternate action. Press the button to select and press again to de-select. However it may be desirable to have the fader up signal cancel a Cue/ PFL selection.
  • Page 86 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 87 S2-C6SS 6 WAY STEREO LINE SOURCE SELECT CHANNEL WITH EQ Each button and their corresponding modes are listed below. Mode 1 : Normal. The program bus can be selected as normal. Mode 2 : Always on. The program bus is permanently selected.

  • Page 88: S2-Ct Telco Channel With Eq

    S 2 - C T T E LCO C H A N N E L W I T H E Q 11 S2-CT Telco Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses.

  • Page 89: Rear Panel

    Pin 6: No connection. Pin 7: 0V logic. Pin 8: General purpose input. Pin 9: No connection. Cleanfeed Output Connector This XLR 3 pin plug is a balanced line level output intended to be fed back to the TBU. S2 User Handbook...

  • Page 90: Channel Options, Jumper Settings And Presets

    Set-up for cleanfeed bus 2. 1 & 2 Set-up for cleanfeed bus 1. 2 & 3 Set-up for cleanfeed bus 2. Not Fitted Not Fitted Not Fitted Note: Options in bold are set as default when shipped. S2 User Handbook...

  • Page 91: Fig 11-1 : S2 Telco Input Board Layout

    Cleanfeed Mix-Minus Null Fig 11-1 : S2 Telco Input Board Layout. Remote for Hybrid Hold The remote output of the Telco channel can be used to hold the line on a telephone hybrid when the channel is ON and the fader is up. The hybrid is also put on hold when the Cue/ PFL &...
  • Page 92 PGM button until only the CUE/PFL button is illuminated ON. This setting is then applied by pressing the ON button. The PGM button will flash quickly for about a second to indicate that the setting is stored. S2 User Handbook...
  • Page 93 Mode 3 when this is used. Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 94 If the remote input is not active, then the ON button will be Red. If the remote input is active then the ON button will be green. This is designed to show a visual indication of the state of a TBU connected to the channel. S2 User Handbook...

  • Page 95: S2 Csmm Stereo Mix Minus Channel With Eq

    S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ 12 S2 CSMM Stereo Mix Minus Channel With EQ Panel Controls PGM and AUD Selection Selecting the PGM, AUD buttons routes the channel audio output to the PGM and/or AUD mix busses. The buttons are illuminated in green to indicate the routing status.

  • Page 96: Rear Panel

    S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ The outputs on the this channel can also be configured by jumper settings as a mono sum of mix-minus on the left channel and continuous talkback on the right channel (for use with some ISDN codec applications and telephone balance units).

  • Page 97: Channel Options, Jumper Settings And Presets

    S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ The connector pin-out is as follows; Pin 1: Opto isolated Line input start NPN collector. Pin 2: Common NPN emitter for Line 1 start and stop. Pin 3: Opto isolated Line input stop NPN collector.

  • Page 98: Fig 12-1 : S2 Stereo Mix-Minus Board

    P11 & P12 100Hz Null J1J3 Jumper Options = Latch Start I/P 1 = Cont. Mom. Start = Fader Cancel Cue/PFL J6A = Timer 1 B = Timer 2 Fig 12-1 : S2 Stereo Mix-Minus Board Layout. S2 User Handbook...
  • Page 99 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Remote for Line Input The remote output for the Line input can be used for a start and stop function wired to other studio equipment such as CD or MD players. The default setting for J1 is none (not fitted), which produces a momentary remote contact.
  • Page 100 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Eight presets are used to adjust the cleanfeed null for the left and right channels. Cleanfeed is derived from the PGM or AUD output busses and are set up as follows. With the channel...
  • Page 101 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ General Purpose I/O Function Options GPIO Function Cue/PFL Latching/ Active Low/ ON Button Input/Output Button Button Momentary Active High General Purpose I/O Action Options The functions available are dependent on whether the remote is set as an input or an output.
  • Page 102 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 103 S2-CSMM STEREO MIX MINUS CHANNEL WITH EQ Cue/PFL Mode 1 : Normal. Cue/PFL is selected as normal, with both a momentary or latched operation. Mode 2 : Latched. Cue/PFL is selected as normal, but will only work with a latched operation.

  • Page 104: 13 Output Channels

    PGM output and mono output is available on a 15 way D type connector. Button switches at the top of the channel select the mono output source. The S2-ODPF version has output faders for production use. S2-ODA Digital AUD Output Channel &...

  • Page 105: S2-Oms Studio Monitor Channel

    An illuminated Mute LED shows when a live microphone channel in the control room has muted the control room speakers. S2-OMS Studio Monitor Channel The Studio Monitor channel is used for the monitoring of various sources on the studio loudspeakers and headphones. A suitable power amplifier connected to the channel monitor output must be used to drive the loudspeakers.

  • Page 106: S2-Odpf/S2-Odp Digital Output Pgm Channel With & Without Master Fader (Version 1)

    Version 2. Externally, the only way to check the Version number of this module which has been fitted into your S2, is to look at the layout of the connectors on the rear panel. If the POWER and OUTPUTS AND REMOTES connector is at the bottom of the panel (see page 99), then you have a Version 2 module.

  • Page 107: Rear Panel

    Pin 9: PGM left output non-phase. Pin 10: PGM right output non-phase. Pin 11: No connection. Pin 12: No connection. Pin 13: Mono output non-phase. Pin 14: Control Room mute relay contact 1B. Pin 15: Control Room mute relay contact 2B. S2 User Handbook...

  • Page 108: Channel Options, Jumper Settings And Presets

    J3 to J9 and channel identifying links. The PGM digital output channel is identified by having links LK42 and LK45 fitted. The PGM digital output channel with fader is identified by having links LK42, LK45 and LK46 fitted. The standard options available are; S2 User Handbook...

  • Page 109: Fig 14-1 : S2 Digital Pgm Output Board

    Note: Options in bold are set as default when shipped. LK42 Trim L Trim R Module A SPDIF LK45 Digi Threshold J1J2 Right Left Gain Sym. Sym. J11J10 SPDIF Fig 14-1 : S2 Digital PGM Output Board Layout. S2 User Handbook...

  • Page 110: Fig 14-2 : S2 Digital Pgm Output With Fader Board Layout

    Sym. J11J10 SPDIF Fig 14-2 : S2 Digital PGM Output With Fader Board Layout. Cleanfeed Terminations If the console is supplied without Telco channels then J1 and J2 will be fitted to terminate the cleanfeed mix busses. With one Telco channel only J2 is fitted and with two Telco channels no jumpers are fitted.
  • Page 111 VCA components. Presets, P5 (left) and P4 (right), set the peak digits through the conditioning circuits to the analogue to digital converter. This is preset on final test and should not require further adjustment. S2 User Handbook...
  • Page 112 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.

  • Page 113: S2-Odpf/S2-Odp Digital Output Pgm Channel With & Without Master Fader (Version 2)

    Version 2. Externally, the only way to check the Version number of this module which has been fitted into your S2, is to look at the layout of the connectors on the rear panel. If the POWER and OUTPUTS AND REMOTES connector is at the bottom of the panel (see page 99), then you have a Version 2 module.

  • Page 114: Rear Panel

    Pin 9: PGM left output non-phase. Pin 10: PGM right output non-phase. Pin 11: No connection. Pin 12: No connection. Pin 13: Mono output non-phase. Pin 14: Control Room mute relay contact 1B. Pin 15: Control Room mute relay contact 2B. S2 User Handbook...

  • Page 115: Channel Options, Jumper Settings And Presets

    J3 to J9 and channel identifying links. The PGM digital output channel is identified by having links LK42 and LK45 fitted. The PGM digital output channel with Fader is identified by having links LK42, LK45 and LK46 fitted. The standard options available are; S2 User Handbook...
  • Page 116 AES/EBU sync input selected. 2 & 3 S/PDIF sync input selected. 1 & 2 S/PDIF output selected. 2 & 3 AES/EBU output selected. 1&2 Reserved. None Reserved. Note: Options in bold are set as default when shipped. S2 User Handbook...

  • Page 117: Fig 15-1 : S2 Digital Pgm Output Board Layout

    J4 J6 J8 Left Lim Left SYM Fig 15-2 : S2 Digital PGM Output With Fader Board Layout. Cleanfeed Terminations If the console is supplied without Telco channels then J1 and J2 will be fitted to terminate the cleanfeed mix busses. With one Telco channel only J2 is fitted and with two Telco channels no jumpers are fitted.
  • Page 118 Preset P3 sets the VCA fader gain to 0dB when the fader is fully open. This is preset on final test and should not require further adjustment, unless it has been found necessary to replace the fader or other VCA components. S2 User Handbook...
  • Page 119 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.

  • Page 120: S2-Odaf/S2-Oda Digital Output Aud Channel With & Without Master Fader (Version 1)

    Version 2. Externally, the only way to check the Version number of this module which has been fitted into your S2, is to look at the layout of the connectors on the rear panel. If the OUTPUTS AND REMOTES connector is at the bottom of the panel (see page 113), then you have a Version 2 module.

  • Page 121: Rear Panel

    Pin 9: AUD left output non-phase. Pin 10: AUD right output non-phase. Pin 11: No connection. Pin 12: No connection. Pin 13: No connection. Pin 14: Studio mute relay contact 1B. Pin 15: Studio mute relay contact 2B. S2 User Handbook...

  • Page 122: Channel Options, Jumper Settings And Presets

    J3 to J9 and channel identifying links. The AUD digital output channel is identified by having links LK43 and LK45 fitted. The AUD digital output with fader is identified by having links LK43, LK45 and LK46 fitted. The standard options available are; S2 User Handbook...

  • Page 123: Fig 16-1 : S2 Digital Aud Output Board

    Note: Options in bold are set as default when shipped. Trim L Trim R LK42 Module B SPDIF LK45 Threshold Digi Right Left Gain Sym. Sym. J11J10 SPDIF Fig 16-1 : S2 Digital AUD Output Board Layout. S2 User Handbook...

  • Page 124: Fig 16-2 : S2 Digital Aud Output With Fader Board Layout

    Sym. Sym. J11J10 SPDIF Fig 16-2 : S2 Digital AUD Output With Fader Board Layout. Synchronisation Mode and Sample Rate The following jumpers, J3 to J9, are used for setting the Sync Mode and Sample Rate of the digital output.
  • Page 125 (i.e. distortion) through the limiting stage. They are all factory set on final test and should not be adjusted further. Gain can be altered using P4 and P5 on board versions S2-OP-04 and above, as P8 is no longer fitted on these boards.
  • Page 126 Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.

  • Page 127: S2-Odaf/S2-Oda Digital Output Aud Channel With & Without Master Fader (Version 2)

    Version 2. Externally, the only way to check the Version number of this module which has been fitted into your S2, is to look at the layout of the connectors on the rear panel. If the OUTPUTS AND REMOTES connector is at the bottom of the panel (see page 113), then you have a Version 2 module.
  • Page 128 This 75 ohm BNC socket is used for the word clock input, and has the following connections; Inner: Signal. Outer: Screen. AES/EBU Sync Input Connector This XLR 3 pin socket is used for AES/EBU Sync Input, and has the following connections; S2 User Handbook...

  • Page 129: Channel Options, Jumper Settings And Presets

    AES/EBU sync input selected. 2 & 3 S/PDIF sync input selected. 1 & 2 S/PDIF output selected. 2 & 3 AES/EBU output selected. 1&2 Reserved. None Reserved. Note: Options in bold are set as default when shipped. S2 User Handbook...

  • Page 130: Fig 17-1 : S2 Digital Aud Output Board Layout

    J4 J6 J8 Left Lim Left SYM Fig 17-2 : S2 Digital AUD Output With Fader Board Layout. Synchronisation Mode and Sample Rate The following jumpers, J3 to J6 and J9 on V2, are used for setting the Sync Mode and Sample Rate of the digital output.
  • Page 131 Preset P3 sets the VCA fader gain to 0dB when the fader is fully open. This is preset on final test and should not require further adjustment, unless it has been found necessary to replace the fader or other VCA components. S2 User Handbook...
  • Page 132 (i.e. distortion) through the limiting stage. They are all factory set on final test and should not be adjusted further. Gain can be altered using P4 and P5 on board versions S2-OP-04 and above, as P8 is no longer fitted on these boards.
  • Page 133 Mode 3 : Always off. The Control Room Monitor channel can never be selected as the meter feed. Note: If more than one button is set to mode 2 (Always on) then the meter feed will be a mix of these sources. This may not be desirable in most applications. S2 User Handbook...

  • Page 134: 18 S2-Omc Control Room Monitor Channel

    S 2 - O M C CO N T R O L R O O M M O N I TO R C H A N N E L 18 S2-OMC Control Room Monitor Channel Panel Controls PGM, AUD, EXT 1 & EXT 2 Selection The electronically interlocking PGM, AUD, EXT 1 &...

  • Page 135: Rear Panel

    Tip: Talkback audio. Ring: Talkback control. Sleeve: Screen. Talkback Output Connector This standard 6.35mm jack socket is used for the continuous talkback output, and has the following connections; Tip: Talkback audio. Ring: No connection. Sleeve: Screen. S2 User Handbook...

  • Page 136: Channel Options And Jumper Settings

    Note: Options in bold are set as default when shipped. Jumper Options J1 = Global T/B Enable J2 = LS T/B Enable J3 = LS Dim Enable C/Room J4 = HP Dim Enable LK10 Fig 18-1 : Control Room Monitor Board Layout. S2 User Handbook...
  • Page 137 There are no presets to adjust on the control room monitor channel. Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 138 Monitor Auto Cue/PFL Mode 1 : Normal. Monitor Auto Cue/PFL can be selected as normal. Mode 2 : Always on. Monitor Auto Cue/PFL is permanently selected. Mode 3 : Always off. Monitor Auto Cue/PFL is permanently deselected. S2 User Handbook...
  • Page 139 Mode 1 : Normal. Split Cue/PFL can be selected as normal. Mode 2 : Always on. Split Cue/PFL is permanently selected. Mode 3 : Always off. Split Cue/PFL is permanently deselected. Note: Split Cue/PFL is dependent on Headphone Auto Cue/PFL being selected. S2 User Handbook...

  • Page 140: S2-Oms Studio Monitor Channel

    S 2 - O M S S T U D I O M O N I TO R C H A N N E L 19 S2-OMS Studio Monitor Channel Panel Controls PGM, AUD, EXT 1 & EXT 2 Selection The electronically interlocking PGM, AUD, EXT 1 &...

  • Page 141: Rear Panel

    This standard 6.35mm jack socket is the output for the studio monitor loudspeakers, and has the following connections; Tip: Left channel. Ring: Right channel. Sleeve: Screen. A suitable amplifier should be used to send this signal to the loudspeakers, or connect active loudspeakers directly to this output. S2 User Handbook...

  • Page 142: Channel Options And Jumper Settings

    Note: Options in bold are set as default when shipped. Jumper Options J1 = Global T/B Enable J2 = LS T/B Enable J3 = LS Dim Enable J4 = HP Dim Enable LK11 Studio Fig 19-1 : Studio Monitor Board Layout. S2 User Handbook...
  • Page 143 There are no presets to tamper with on the studio monitor channel. Button Mode Settings To make the S2 modules as flexible as possible, every button on each channel can be set to a number of different modes. These will aid in the use of the mixer and allow for extra functionality.
  • Page 144 Mode 3 : Always off. External input 2 is permanently deselected. Mode 4 : Mix. External input 2 can be selected as normal but also allows this button to be mixed with other buttons set to mix mode. S2 User Handbook...
  • Page 145 Headphone Auto Cue/PFL Mode 1 : Normal. Headphone Auto Cue/PFL can be selected as normal. Mode 2 : Always on. Headphone Auto Cue/PFL is permanently selected. Mode 3 : Always off. Headphone Auto Cue/PFL is permanently deselected. S2 User Handbook...

  • Page 146: 20 Meterbridge Modules

    S2-MPPT*. The S2-ML53 is an LED meter for displaying both VU and PPM scales. Illuminated LEDs on each meter panel indicate the monitoring source. A meterbridge panel, S2-MPH can be linked to a dual meter panel and used to display phase information on the selected source.

  • Page 147: Meterbridge Distribution Board

    Six connectors on the board provide power and various signals to the meterbridge modules and it is therefore possible, where space permits, to install 1 x S2-ML, 1 x S2-MT, and up to three of your chosen style of meter panels. Meters can be configured to display PFL, PGM, or Monitor, which is the signal selected by the buttons on the PGM output module.

  • Page 148: S2-Mb1-5 Meterbridge Blanking Plates

    Meterbridge blanking plates are available in channel widths from 1 to 5 inclusive and are used to fill areas in the meterbridge not occupied by active modules. S2-ML Meterbridge Loudspeaker Monitor Panel Fig 20-3 : Loudspeaker Monitor Panel. The speaker is used for monitoring PFL and reverse talkback in the control room directly from the mixer.

  • Page 149: S2-Ml53 Led Meter Panel

    M E T E R B R I D G E M O D U L E S S2-MVU Meterbridge VU Meter Panel, S2-MPPM PPM Meter Panel, S2-MPPT True PPM Meter Panel & S2-ML53 LED Meter Panel* Fig 20-4 : PPM & True PPM Meter Panel.

  • Page 150: Fig 20-6 : Vu & Ppm Led Meter Panel

    PGM output, will indicate a meter reading of 4. Each mark on the PPM scale indicates a 4dB change in signal level. The S2-MVU two moving coil VU meters will be configured such that a 1kHz signal, at +4dBu at the PGM output, will indicate a meter reading of 0VU.

  • Page 151: S2-Mph Meterbridge Phase Meter Panel

    Illuminated LEDs indicate the relevant source shown on the meters. The S2-ML53 has an adjustable pot accessible from the front panel which alters the meter brightness, this can be altered using a jewellers screwdriver.

  • Page 152: S2-Mtb6 Meterbridge 6 Way Talkback Panel

    S2-MTB6 Meterbridge 6 Way Talkback Panel Fig 20-8 : Meterbridge 6 Way Talkback Panel. The S2-MTB6 Meterbridge Talkback Panel is used for communicating with up to 6 other locations. While a button is pressed, the switch is illuminated and the talkback is active. The buttons work with both a momentary and latched operation.

  • Page 153: S2-Mtbs Meterbridge Station Master Talkback Panel

    The S2-MTBS panel is used for interfacing with a Sonifex Station Master. See the Station Master manual for functionality and connection information. Rear Panel Station Master Talkback Connector This 25 pin D type socket is used for connecting to the Talkback connector on a Sonifex Station Master. S2 User Handbook...
  • Page 154 This 9 pin D type plug is used for connecting the Talkback module to the Control Room Monitor channel. The connection cable is supplied with the Talkback module, which plugs into the S2-MTBS via the mixer meterbridge housing, and down into the two talkback jack sockets on the rear of the Control Room channel.

  • Page 155: Fig 20-10A : S2-M6Ss Panel

    D-Type female (socket) connector, which uses exactly the same pin configuration as the stereo audio source input connector on the S2-C6SS channel. The single stereo output is provided on a 9 way D-type male (plug) and the pin configurations are shown below.

  • Page 156: Fig 20-10B : S2-M6Ss Diagram

    ‘power through’ connector on another meterbridge panel. The ‘power through’ connector can be used to daisy chain power down the meterbridge housing, for example, to an S2-MT panel. Audio Output on 9 Way D-type Plug Power Input Connector.

  • Page 157: Switch Panel With 1

    Panel With 1 Button. button to either GRN, RED or GRN & RED (for orange). The connector used for both the S2-MSB1 and S2-MSB3 is a 9 pin D-type female and the Switch 1 pin-out details are as follows: S2-MSB1...

  • Page 158: S2-Mt Meterbridge Timer Panel

    M E T E R B R I D G E M O D U L E S S2-MT Meterbridge Timer Panel Fig 20-13 : Meterbridge Timer Panel. Overview Each of the dual timers can be used for timing events triggered by Timer 1, Timer 2, or the Mic fader open signal.

  • Page 159: Rear Panel

    Pin 5: No internal connection. Pin 6: Ground. Pin 7: Ground. Pin 8: 5V. Pin 9: 5V. +VD: Digital power rail. ~8.5V. Configuring The Timer The timers are configured according to the following comprehensive instructions, Setting The Time S2 User Handbook...
  • Page 160 Hold down the upper timer “RESET” button while in TIME mode, a status indication will be displayed. This code is identical to that of the time code output string: 0 = not locked, 1 = signal/not locked, 2 = locked Also note that source number 0 (internal RTC) implies “not locked”. S2 User Handbook...
  • Page 161 D = Indication of presence of timecode signal 0 = No signal, 1 = Signal present. \n = New Line. \r = Carriage return. RS232 Input Format “dd/mm/yy,hh:mm:ss\r\n” DATE,TIME (Date format is dependent on setting of option no. 6.) S2 User Handbook...
  • Page 162 On event show to display 2 Mic Timer Control Auto mode: The Mic timer is controlled via the Mic fader only. Manual mode: The Mic timer can be controlled via the module control buttons and/or the Mic Fader. S2 User Handbook...
  • Page 163 Bits 44 to 45 Days Tens Bits 44 to 47 Years Units Bits 52 to 55 Days Units Bits 52 to 55 Months Units Bits 60 to 63 Years Tens Bits 60 to 62 Days Tens Bits 60 to 62 Month Tens S2 User Handbook...

  • Page 164: 21 Technical Specifications

    130Hz with HPF in). Line Inputs: 20Hz to 20kHz –0.5dB, +0dB. RIAA Input: 30Hz to 16kHz ± 1.5dB RIAA equalised. Noise (20Hz to 20kHz) Mic Input E.I.N.: -129dB with 150Ω source. Stereo Inputs (fader down, no routing): -89dB ref 0dB S2 User Handbook...
  • Page 165 Output Sample Rates (Using Onboard Clock): 32kHz, 44.1kHz, 48kHz, & 96kHz Output Sample Width: 16, 20, 24 bit (24 bit on V2 ODA/ODP) Output Headphone Output Load >45 ohms, recommended 400Ω Maximum Output (Analogue) +26dBu balanced into 2k or greater S2 User Handbook...

  • Page 166: S2 Mixer Weights And Boxed Dimensions

    (Boxed): 55cm (W) x 39.3cm (D) x 8.5cm (H) 21.6” (W) x 15.5” (D) x 3.4” (H) Weight (S2-PSUS): Nett: 1.58kg Gross: 2kg Nett: 3.5lbs Gross: 4.4lbs S2 Mixer Weights and Boxed Dimensions Mixer Gross Nett Width (cm) Depth (cm)

  • Page 167: Glossary

    EQualisation. This is the method of cutting or boosting selected bands of frequencies in the signal. S2 User Handbook...
  • Page 168 Talkback (and reverse talkback, Rev T/B). This is the ability for two or more studios to communicate with each other off-air. Telco TELephone COmmunication. The telco module is used by the presenter to talk to telephone callers via a hybrid or TBU. Total Harmonic Distortion. S2 User Handbook...
  • Page 169 Input Channels 25 Installation Notes 4 Technical Specifications Introduction 1 Warranty and Liability Meterbridge Distribution Board 135 WEEE & RoHS Directives - Sonifex Statement v Meterbridge Modules 134 Output Channels 92 Power Supply 16 Removing & Replacing Channels 13 Reporting Faults vi...
  • Page 170 N OT E S S2 User Handbook...
  • Page 171 N OT E S S2 User Handbook...
  • Page 172 w w w . s o n i f e x . c o . u k t:+44 (0)1933 650 700 f:+44 (0)1933 650 726 s a l e s @ s o n i fe x . co. u k...

Table of Contents
