RL-328SK
Professional Portable Radio
VHF/UHF
Transceiver
USER'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RL-328SK and is the answer not in the manual?

Questions and answers

Summary of Contents for REXON RL-328SK

  • Page 1 RL-328SK VHF/UHF Transceiver USER’S MANUAL Professional Portable Radio...
  • Page 2: Table Of Contents

    Table of Contents Parts Name & Functions ������������������������������������������������������������������� 1 Fitting & Removing the Battery Pack ���������������������������������������������� 3 • To Install the battery pack ����������������������������������������������������������������������� 3 • To remove the battery pack ������������������������������������������������������������������� 3 Charging the Battery Pack ��������������������������������������������������������������� 3 Symbols Description ������������������������������������������������������������������������ 4 Basic Operation ��������������������������������������������������������������������������������...
  • Page 3 • DCS code ���������������������������������������������������������������������������������������������������������������� 8 • TOT (Time-Out Timer) ���������������������������������������������������������������������������������������� 9 • BCLO (Busy Channel LockOut); BTLO (Busy Tone LockOut) ����������������� 9 Busy Lockout On/OFF �������������������������������������������������������������������������������������� 9 • Burst Tone ������������������������������������������������������������������������������������������������������������� 9 Burst Tone On/OFF �������������������������������������������������������������������������������������������� 9 • Talk Around ����������������������������������������������������������������������������������������������������������� 9 •...
  • Page 4: Parts Name & Functions

    Parts Name & Functions • • Power/Volume Knob: Antenna Connector: Rotate it to turn on Fit the antenna to this the transceiver and to MX Type connector adjust the volume. • LED: indicates radio status. Red color for transmitting; Green color for receiving; Orange color for wrong CTCSS/DCS •...
  • Page 5 A key: This key defines three features 1) Priority feature (simply press once) 2) Emergency feature (keep pressing until trigger time is reached) • A key 3) Auto transmitter ( keep pressing the key and turn on the radio) • B key B key: •...
  • Page 6: Fitting & Removing The Battery Pack

    Fitting & Removing the Battery Pack � To Install the battery pack Fit the bottom edge of the battery pack into the holes of the transceiver cabinet bottom. Push the battery pack down to the transceiver aluminum chassis till the end click. �...
  • Page 7: Symbols Description

    Symbols Description : indicates this channel is priority channel. (Dealer Programmable) : indicates this channel has BCLO feature. : indicates this channel with CTCSS (Continuous Tone Coded Squelched System). : indicates this channel with DCS (Digital Coded Squelch). : indicates this channel with signalling (2/5 tone) feature. : indicates this channel with DTMF feature : indicates monitor feature is activated.
  • Page 8: Basic Operation

    Basic Operation � Turn the radio On & OFF Rotate the PWR/VOL knob clockwise till the radio is turned on. The radio gets started to auto test for two seconds. During auto testing, all icons on LCD will appear. After auto testing is done, LCD will show channel name tag and what functions have been activated by your dealer.
  • Page 9: Transmitting

    � Transmitting Before transmitting, you can monitor the channel you are using to ensure it is not busy. Simply press B key that is defined as PTT button and start talking at approximately 2 inches from the MIC hole. During transmitting, the LED on the top of the radio will glow red. Release PTT button when you have finished talking.
  • Page 10: Delete A Nuisance Channel

    Delete A Nuisance Channel Allows you to remove temporarily the channels which you don’t want to hear from the scan list. During scanning, when the radio is locked on a busy channel, press button to remove this channel from the scan list, and it won’t be scanned until the radio is turned on again. This func- tion should not be used in systems critical or mission critical communication systems and can be disabled by your dealer.
  • Page 11: Keypad Unlock

    e.g. For most licensed radios, we suggest the dealer should set & buttons to be locked and unlocked with user’s access. By this way, the user can only switch channels & activate scan without changing other setting. � Keypad Unlock By keep pressing the button to be unlocked for 5 seconds, the button can be unlocked for 10 seconds.
  • Page 12: Tot (Time-Out Timer)

    � TOT (Time-Out Timer) TOT is the function that prevents from locking up a repeater or frequency by prolonged keying of PTT. The time-out timer limits the amount of time you have to transmit your message. When you reach the time limit which has been programmed by your dealer, your transmission will be cut off.
  • Page 13: Start To Talk Around

    � Start to talk around Press D key till trigger time is reached, the radio will transmit in accoding with talk around set- ting. These functions should only be used after a full discussion with your dealer,  misuse of these functions can disrupt your radio system. �...
  • Page 14: Receiving A Selective Call

    Receiving A Selective Call When the Called radio receives a SelCal, its LCD will show the ID of the Calling radio. Then, the called radio will automatically make a response call, a beep will be heard. In the meantime, the speaker will be programmed(open) and PTT will be enabled.
  • Page 15 Page ...
