RL-328CQ
VHF/UHF TRANSCEIVER
INSTRUCTION MANUAL
RoHS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the rl-328cq and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for REXON rl-328cq

  • Page 1 RL-328CQ VHF/UHF TRANSCEIVER INSTRUCTION MANUAL RoHS...
  • Page 2: Table Of Contents

    Table of Contents Packing List ������������������������������������������������������������������������������������������������1 Cautions ������������������������������������������������������������������������������������������������������1 Parts Name & Functions ������������������������������������������������������������������������2 Fitting & Removing the Battery Pack ������������������������������������������������3 To install the battery pack ���������������������������������������������������������������� 3 To remove the battery pack ������������������������������������������������������������� 3 Charging the Battery Pack ��������������������������������������������������������������������3 Symbols Description �������������������������������������������������������������������������������4 Basic Operation�����������������������������������������������������������������������������������������5 Turn the radio ON &...
  • Page 3 Store/Delete a channel ��������������������������������������������������������������������������8 Operation ������������������������������������������������������������������������������������������������� 10 Menu operation ���������������������������������������������������������������������������������10 VOX Sensitivity Level ������������������������������������������������������������������������10 Transmit Power Setting �������������������������������������������������������������������10 Squelch Level ��������������������������������������������������������������������������������������10 Backlight Setting �������������������������������������������������������������������������������11 Display Color Setting ������������������������������������������������������������������������11 Beep Setting ����������������������������������������������������������������������������������������11 ANI Setting �������������������������������������������������������������������������������������������11 +/- Potential Difference� ������������������������������������������������������������������11 TOT (Time-Out Timer) ����������������������������������������������������������������������12 Beat Frequency Setting �������������������������������������������������������������������12 Frequency Step Setting �������������������������������������������������������������������12 CTCSS and DCS Setting �������������������������������������������������������������������12...
  • Page 4: Packing List

    Packing List Please check following table� ITEMS Q’TY RL-328CQ Radio Antenna (MX type) Battery Pack Rapid Charger Belt Clip Instruction Manual Cautions * NEVER transmit without antenna� * USE DC power supply, take notice of power voltage must be between 6V and 8V to avoid damaging the unit�...
  • Page 5: Parts Name & Functions

    Parts Name & Functions Power/Volume Antenna Connector: Knob: Rotate it to Fit the antenna to this turn on the trans- MX Type connector ceiver and to adjust the volume� LED: Indicates radio status Loudspeaker Microphone LCD Display MENU Button UP & Down Button ESCAPE Button ENTER Button [ESC]...
  • Page 6: Fitting & Removing The Battery Pack

    Fitting & Removing the Battery Pack To install the battery pack 1) Fit the bottom edge of the battery pack into the holes of the transceiver cabinet bottom� 2) Push the battery pack down to the transceiver aluminum chassis till the end click� To remove the battery pack 1) Keep pressing the release buckle of the battery pack and lift the battery pack up from the transceiver body�...
  • Page 7: Symbols Description

    Symbols Description Indicates battery condition. Dispersion to hyper received frequency Dispersion to under received frequency Indicates frequency scanning Indicates when the keypad has been locked Indicates Digital Coded Squelch (DCS) Indicates Continuous Tone Coded Squelched System (CTCSS) Indicates VOX is activated Indicates bell call is activated Indicates reverse frequency Indicates the PRIority channel (Dealer Programmable)
  • Page 8: Basic Operation

    Basic Operation Turn the radio ON & OFF 1) Rotate the PWR/VOL knob clockwise till the radio is turned on� The radio gets started to auto test for two seconds� During auto testing, all icons will appear on LCD� 2) After auto testing is done, LCD will show channel number and what functions have been activated by your dealer�...
  • Page 9: Emergency Alarm

    Emergency Alarm Press and hold “CALL” and “MON” button assigned to make an emer- gency alarm� Turbo /Call Function Turbo Push “Turbo” button would allow you to have high power TX at 6�5W immediately for VHF, and 5W for UHF� HIGH POWER OR CALL FUNCTION MAY BE PROGRAMED BY YOUR DEALER�...
  • Page 10: Priority Channel Function

    on which there is a party you want to talk to, you can directly communi- cate with the party by pressing the PTT button� To stop scanning, press button again� Priority Channel Function Priority scan allows you to select a channel that will be monitored more often than the others while scanning�...
  • Page 11: Channel /Vfo Mode Selection

    channels� SE: Search Scan -> Radio will be locked in a busy channel at all time till you press Up/Down button� Channel /VFO Mode Selection Press and hold button, the radio can switch between channel and frequency mode� YOUR DEALER CAN LIMIT CHANNEL MODE ONLY THROUGH PC PROGRAMMING SOFTWARE�...
  • Page 12: Delete A Channel

    the channel number you wish to store is blinking, press Up/Down button or input keypad numbers to store channel number� Press button to confirm and exit� Delete a channel In Channel/Frequency mode and then turn off radio, Hold down button and turn on the radio� “DEL?” and stored channel will display on LCD�...
  • Page 13: Operation

    Operation Menu operation In any menu mode, press Up/Down button to select and press but- ton to confirm or press button to exit� VOX Sensitivity Level In Channel / Frequency mode, if you want to open VOX, press but- ton and button, then press button till display “VOX OFF”, input the number with keypad (0-9) or press Up/Down button to select the...
  • Page 14: Backlight Setting

    “SQL 5” is set by default� Setting the radio to the tight squelch level, you can avoid unwanted signals or noise, but you may not receive a weak signal� YOU DEALER CAN PROGRAM SQUELCH LEVEL AT CHANNEL MODE THROUGH PC PROGRAMMING SOFTWARE� Backlight Setting To turn backlight on, hold down button and...
  • Page 15: Tot (Time-Out Timer)

    press button to go in to edit , press Up/Down button to select S-D O (same), S-D + (plus), S-S – (minus) TOT (Time-Out Timer) TOT is the function that prevents from locking up a repeater or frequen- cy by prolonged keying of PTT� The time-out timer limits the amount of time you have to transmit your message�...
  • Page 16: Operation Voice Setting

    Operation Voice Setting Press button and then press Up/Down button till “VOICE? 14” ap- pears, press button to edit, press Up/Down to select open or close voice� YOUR DEALER CAN PROGRAM THE VOICE IN ENGLISH OR CHINESE THROUGH PC SOFTWARE� Channel Spacing Selection Press button and then press Up/Down button till “N/W? 21”...
  • Page 17: Quick Index Of Menu

    Quick index of menu In Channel/VFO mode, press button to go in to the menu� Press Up/Down button to select, press button to enter the mode� Press Up/Down button to select parameters, press button to confirm or press button to exit� “Both“ mode is available in VFO & Channel mode�...
  • Page 18 Turn ANI ON/OFF Both ANI ? Switch to Manual / Auto Both KEYBO? Both TOT ? Set time out timer OFF~270 Sec Set scan type Both SCRMS? TO/CO/SE Set voice notice Both VOICE? ON/OFF Set potential 0~70�995 DIFFR? frequency Channel name tag ON/OFF NAME? Set CTCSS frequency...
  • Page 19: Self-Programming

    Self-Programming Press and hold MON+ buttons by turn on the radio, “SELF” will appear on LCD, press button to start editing in accord with follow- ing step to “self-programming” per channel setting�Press button the next function and press Up/Down button to select parameters� Function description Lists Parameters...
  • Page 20: Ctcss & Dcs Code

    Press button REXONT 10 Channel Name Tag to next word � Press button to previous word� CTCSS & DCS Code CTCSS CODE 67�0 85�4 107�2 136�5 165�5 186�2 210�7 254�1 69�3 88�5 110�9 141�3 167�9 189�9 218�1 71�9 91�5 114�8 146�2 171�3 192�8...
  • Page 21: Technical Specifications

    Technical Specifications GENERAL Frequency range (MHz) 136-174MHZ 400-470MHz Number of Channels Channel Spacing 12�5kHz /25kHz Mode of Operation Simplex or Semi-duplex Modulation Mode F3E (FM) Supply Voltage 7�2V DC Nominal Current Consumption Receiver Standby 15mA Transmit: ≤ 1�4 Amps Temperature Range -20°C to +45°C Frequency Stability ±...
