JVC GR-SXM38U Instructions Manual

Compact vhs camcorder.
Hide thumbs

Advertisement

AUTOMATIC DEMONSTRATION
Automatic
Demonstration
place when "DEMO MODE" is set to
"ON" (factory-preset).
• Available when the Power Switch is set to
" " or " ".
• To cancel Automatic Demonstration, set
"DEMO MODE" to "OFF" (
COMPACT VHS CAMCORDER
For Customer Use:
Enter below the Model No. and Serial No. which
is located on the bottom of the camcorder.
Retain this information for future reference.
Model No.
Serial No.
Dear Customer,
Thank you for purchasing the JVC Compact
takes
VHS camcorder. Before use, please read
"SAFETY PRECAUTIONS" (
ensure safe use of this product.
pg. 15).
GR-SXM38U
CONTENTS
GETTING STARTED
RECORDING/PLAYBACK
BASIC FEATURES
MENU SETTINGS
TERMS
LYT1518-001B
5 ~ 9
9 ~ 10
10 ~ 12
12 ~ 16
24
pg. 3, 4) to
