JVC GR-SX867UM Instructions Manual

Compact vhs camcorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
COMPACT
VHS CAMCORDER
GR-SX867UM
INSTRUCTIONS
CONTENTS
Basic Recording .......................... 16
Basic Features ........................... 18
Advanced Features ...................... 21
Basic Playback ........................... 31
Features .................................. 32
Connections ............................... 34
Animation And Time-Lapse ............. 37
Insert Editing ............................. 38
Audio Dubbing ........................... 39
Indications ................................ 44
LYT0502-001A
ENGLISH
2 - 5
6
7
7
8 - 15
16 - 30
31 - 35
36 - 39
40 - 41
42 - 45
46 - 47
48 - 49
50
51
EN

Advertisement

Table of Contents
loading

Related Manuals for JVC GR-SX867UM

Summary of Contents for JVC GR-SX867UM

  • Page 1: Table Of Contents

    COMPACT VHS CAMCORDER GR-SX867UM INSTRUCTIONS CONTENTS SAFETY PRECAUTIONS QUICK OPERATION GUIDE MAJOR FEATURES PROVIDED ACCESSORIES GETTING STARTED RECORDING 16 – 30 Basic Recording ... 16 Basic Features ... 18 Advanced Features ... 21 PLAYBACK 31 – 35 Basic Playback ... 31 Features ...

  • Page 2: Safety Precautions

    Dear Customer, Thank you for purchasing the JVC Compact VHS camcorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of this product. Using This Instruction Manual •All major sections and subsections are listed in the Table Of Contents on the cover.
  • Page 3 This camcorder is designed to be used with NTSC-type color television signals. It cannot be used for playback with a television of a different standard. However, live recording and viewfinder playback are possible anywhere. Use the BN-V11U/V12U/V20U battery packs and, to recharge them, the provided multi-voltage AC Power Adapter/Charger.

  • Page 4: Safety Instructions

    IMPORTANT PRODUCT SAFETY INSTRUCTIONS Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.
  • Page 5 1. Accessories To avoid personal injury: •Do not place this product on an unstable cart, stand, tripod, bracket or table. It may fall, causing serious injury to a child or adult, and serious damage to the product. •Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.

  • Page 6: Quick Operation Guide

    SUPPLY POWER Hook on. BATTERY RELEASE Using the battery pack Hook its end to the camcorder battery pack in until it locks in place (Charging procedure, pg. 8) To remove the battery pack Slide BATTERY RELEASE and pull out the battery pack.

  • Page 7: Major Features

    Setting Menu (so you will not have to go through the main Menu Screen.) Rotate the Select Wheel to select “OFF” and press it. * “DEMO MODE” remains “ON” even if the camcorder power is turned off. NOTE: When a tape whose Erase Protection tab is in the position that allows recording is loaded in the camcorder, demonstration is not available.

  • Page 8: Getting Started

    To avoid interference with reception, do not use the AC Power Adapter/Charger near a radio. If you connect the camcorder’s DC cord to the adapter during battery charging, power is supplied to the camcorder and charging stops.

  • Page 9: Using A Car Battery

    Hook on. Push in. BATTERY RELEASE Switch ATTENTION: Before detaching the power source, make sure that the camcorder’s power is turned off. Failure to do so can result in a camcorder malfunction. To DC IN connector To DC OUT connector...

  • Page 10: Slot Clock (Lithium) Battery Insertion/Removal

    See “SAFETY PRECAUTIONS” ( on safe handling of lithium batteries. To avoid losing the battery and/or battery holder, place the camcorder with the grip side up as shown in the illustration when inserting/removing the battery. Loading/Unloading A Cassette Slide EJECT until the cassette holder opens. Do not use force to open.

  • Page 11: Date/Time Settings

    “EXIT”, and press it. The Menu Screen reappears with the highlight bar on “RETURN”. Press the Select Wheel to close the Menu Screen. NOTE: To display the date and time in the camcorder’s display and on a connected TV, see “Date/Time Insert” pg. 26).

  • Page 12: Recording Mode Setting

    Select Wheel Power Switch SP/EP Recording Mode Button MENU Button Viewfinder Tape length indicator T 3 0 Recording mode indicator Display Menu Screen TAPE LENGTH TAPE LENGTH Setting Menu GETTING STARTED Recording Mode Setting Set depending on your preference. Set the Power Switch to “AUTO” or “PRO.”. Press SP/ EP for more than 1 second.

  • Page 13: Recording Format Setting

    Select Wheel Power Switch MENU Button Display: when a VHS cassette is loaded. Menu Screen – When an S-VHS cassette is loaded: S-VHS S – VHS ET Setting Menu Menu Screen Normal Screen Recording Format Setting Set the recording format according to the format of the tape used or type of recording you wish to perform.

  • Page 14: Recording

    SQPB (S-VHS QUASI PLAYBACK) function, S-VHS picture quality is not available. — Tapes recorded in S-VHS ET mode cannot be played back on some VCRs, including some JVC VCRs. Tapes recorded in S-VHS or S-VHS ET mode cannot be played back correctly on a normal VHS VCR.

  • Page 15: Grip Adjustment

    Then tighten the screw. CAUTION: When using a tripod, be sure to open and extend its legs fully to stabilize the camcorder. To prevent damage to the unit caused by falling over, do not use a small-sized tripod. , making sure...

  • Page 16: Basic Recording

    “PAUSE” is displayed in the viewfinder. Press the Recording Start/Stop Button. “ in the viewfinder while recording is in progress. To Stop Recording ..press the Recording Start/Stop Button. The camcorder re-enters the Record-Standby mode. 119MIN 3MIN AUTO : Suitable for standard recording using NO PRO.

  • Page 17: Viewfinder Indications

    5 minutes. “TAPE END” also appears when a cassette whose tape is already at its end is loaded. If the Record-Standby mode continues for 5 minutes without performing Zoom or any other operations, the camcorder’s power shuts off automatically. Set the Power Switch to “OFF”, and then back to “CAMERA” to turn the camcorder on again.

  • Page 18: Basic Features

    • When shooting scenes with movement in various directions. • When shooting scenes with low-contrast backgrounds. Switch off the Picture Stabilizer when recording with the camcorder on a tripod. The “ ” indicator appears blinking if the Stabilizer cannot be used.
  • Page 19 FEATURE: PURPOSE: To re-record certain segments. OPERATION: 1) Make sure the camcorder is in the Record–Standby mode. 2) Press and hold either RETAKE to reach the start point for new recording. Pressing 3 forwards the tape and pressing 2 reverses it.

  • Page 20: Video Light

    30 cm (11-13/16") between the video light and people or objects. Do not use near flammable or explosive materials. It is recommended that you consult your nearest JVC dealer for replacing the video light. RECORDING Basic Features (cont.) Video Light...
  • Page 21 RECORDING Advanced Features EFFECT Button Power Switch Recording Start/Stop Button NOTES: Pressing and holding the Recording Start/Stop Button allows you to vary the length for the image during fade in/out or wipe in/out. The screen becomes slightly reddish when the Fade/Wipe is used with Sepia ( Fade/Wipe Effects These effects let you make pro-style scene transitions.

  • Page 22: Program Ae With Special Effects

    P.AE Button Power Switch SEPIA The scene being shot is recorded in sepia-tinted (reddish-brown) monochrome, giving the effect of an older movie. Use together with Wide ( for the authentic look of a classic Hollywood movie. SPORTS High shutter speed clearly captures fast-moving action.

  • Page 23: Using Menus For Detailed Adjustment

    LANG. (ex. TITLE LANG.) Normal Screen Using Menus For Detailed Adjustment This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings. Set the Power Switch to “PRO.”. Menu access depends on the function you select.
  • Page 24 WIDE S.LX NORMAL Allows you to superimpose one of eight preset titles ( TITLE Makes the date/time settings appear in the camcorder or on a connected monitor DATE/TIME pg. 26). DISP. Menu Screen Available Using The MENU Button This Menu Screen cannot be accessed while recording.
  • Page 25 Allows you to set the current date and time ( DATE/TIME JLIP ID NO. This number is necessary when connecting the camcorder to a device such as a computer using the J terminal (JLIP). The numbers range from 01 to 99. Factory setting is 06. DEMO MODE...

  • Page 26: Instant Titles

    Date/Time Insert Allows you to display the date and time in the camcorder or on a connected color monitor, as well as to record them manually or automatically. You should have already performed the Date/ Time Setting procedure ( pg. 11).
  • Page 27 NOTES (for Animation and Time-Lapse): For best results, make sure the camcorder is secured when shooting in Animation or Time-Lapse mode. Fade- or wipe-in/out cannot be performed during Animation or Time-Lapse shooting. Before performing other operations following Animation or Time-Lapse recording, make sure the Animation or Time-Lapse mode is deactivated.

  • Page 28: Exposure Control

    Select Wheel Power Switch To brighten the image – – RECORDING Exposure Control This feature automatically adjusts the iris for the best available picture quality, but you can override it and make the adjustment manually. Manual exposure adjustment is recommended in the following situations: •...

  • Page 29: Auto Focus

    When the focus level cannot be adjusted any farther or closer, “ ” or “ Focusing AUTO FOCUS The camcorder’s Full Range AF system offers continuous shooting ability from close-up to infinity. However, correct focus may not be obtainable in the situations listed below (in these cases use manual focusing): •When two subjects overlap in the same scene.

  • Page 30: White Balance Adjustment

    If the white balance is correct, all other colors will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional color/tint reproduction. Set the Power Switch to “PRO.”.

  • Page 31: Playback

    •Press 2 to rewind, or 3 to fast-forward the tape during Stop mode. NOTES: The camcorder shuts off automatically after about 5 minutes in Stop mode. To turn on again, set the Power Switch to “OFF”, then to “PLAY”. The playback picture can be viewed in the viewfinder or on a connected TV ( pg.

  • Page 32: Features

    To return to Auto Tracking, press P.AE and EFFECT simultaneously. “AT” blinks. When Auto Tracking finishes, the indication disappears. When noise bars appear during playback, the camcorder enters the Auto Tracking mode and “AT” is displayed. Manual Tracking may not work with tapes recorded on Set to “PLAY”.

  • Page 33: Using The Cassette Adapter

    Recording safety hole Cassette Adapter (VHS Playpak) Use this to play back an S-VHS-C/VHS-C video cassette recorded with this camcorder on a VHS VCR. It is fully compatible with any S-VHS/VHS video cassette recorder. The C-P7U adapter is battery powered and automatically performs tape loading and unloading.

  • Page 34: Connections

    These are some basic types of connections. When making connections, refer also to your VCR and TV instruction manuals. A. Connection to a TV or VCR equipped with an S-VIDEO IN and A/V input connectors Connector cover* B. Connection to a TV or VCR equipped only with A/V input connectors Connector cover* * When connecting the cables, open this cover.

  • Page 35: Basic Connections

    Basic Connections Make sure all units are turned off. Connect the camcorder to a TV or VCR as shown in the illustration ( If using a VCR . . . go to step 3. If not . . . go to step 4.

  • Page 36: Using The Remote Control Unit

    The Full-Function Remote Control Unit can operate this camcorder from a distance as well as the basic operations (Playback, Stop, Pause, Fast-Forward and Rewind) of your VCR. RM-V715U (provided) Remote sensor Buttons Infrared beam transmitting window ZOOM (T/W) Buttons PLAY Button...

  • Page 37: Animation And Time-Lapse

    Interval time indicator Recording time indicator Remote sensor START/STOP REC. TIME INT. TIME RM-V715U (provided) Animation and Time-Lapse FEATURE: PURPOSE: The remote control lets you set/release Interval Time and Recording Time without using the Menu Screen. OPERATION: Animation 1) Set Instead of performing steps 1 through 3 on pg.

  • Page 38: Insert Editing

    Play back the tape, locate the Edit-Out point and press PAUSE. Press and hold COUNTER R/M on the camcorder for more than 1 second to reset the tape counter, then press again for less than 1 second so that “M”...

  • Page 39: Audio Dubbing

    A. DUB, press and release PAUSE. The Audio Dub- Standby mode is engaged. To begin Audio Dubbing, press PLAY. When the counter reaches “0:00:00”, Audio Dubbing stops automatically and the camcorder enters the Audio Dub-Standby mode. To end Audio Dubbing, press STOP. NOTES: Do not press FF or REW during Audio Dub-Standby, or the edit points will not be accurate.

  • Page 40: Troubleshooting

    If, after following the steps in the chart below, the problem still exists, please consult your JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Power Adapter/Battery Charger, etc.) and clock battery;...
  • Page 41 The scene being shot is adversely affecting the operation of Auto Focus ( pg. 29). If you remove the power source from the camcorder while the power is on, all settings and selections are erased. Make sure to turn the camcorder’s power off before disconnecting the power source.

  • Page 42: Index

    INDEX Controls, Connectors And Indicators &...

  • Page 43: Other Parts

    Clock Battery Slot ... Tripod Mounting Socket ... are located beneath the such as a personal computer. For further details consult your nearest JVC dealer. is not possible if the VCR is not equipped with a J terminal. Be careful not to cover this area; a sensor necessary for shooting is built-in here.

  • Page 44: Indications

    Indications During Recording Tape Remaining Time ... Blinks when a tape is about to reach its end. Recording Mode Indicator (SP/EP) ... Program AE Indicator ... Displayed at for approx. 2 seconds when Program AE with special effects is switched from one mode to another by pressing P.AE., then only the indicator remains at Fade/Wipe-Standby Indicator ...

  • Page 45: Indications During Playback

    Appears when the tape ends during recording, playback or fast-forward. TAPE END Blinks for approx. 5 seconds when the camcorder is turned on with the lens cover closed. LENS COVER These 2 warnings appear alternately every 3 seconds if condensation occurs. In this case, all functions except tape eject and power on/off are disabled.

  • Page 46: Cautions

    In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Video Light DANGER: •The video light becomes extremely hot.

  • Page 47: Main Unit

    Moisture on the head drum can cause severe damage to the video tape, and can lead to internal damage to the camcorder itself. Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer.

  • Page 48: Terms

    Cassette Adapter ... pg. 33 Charge Marker ... pg. 8 Charging The Battery Pack ... pg. 8 Clean The Camcorder ... pg. 50 Clock (Lithium) Battery ... pg. 10 Connection To A VCR/TV ... pg. 34 Contents ... cover page Counter Memory ...
  • Page 49 ND Effect Mode ... pg. 22 Nega/Posi Mode ... pg. 22 Picture Stabilizer ... pg. 18 Power Switch Position ... pg. 16 Program AE With Special Effects ... pg. 22 Provided Accessories ... pg. 7 Quick Review ... pg. 19 Recording Format ...

  • Page 50: User Maintenance

    Set to “OFF”. PUSH Button EJECT Switch After Use Turn off the camcorder. Slide EJECT to open the cassette holder, then remove the cassette. Press PUSH to close and lock the cassette holder. Slide BATTERY RELEASE to remove the battery pack.

  • Page 51: Specifications

    •Compact VHS ( •Remote Control Unit RM-V700U •Active Carrying Bag CB-V7U Some accessories are not available in some areas. Please consult your nearest JVC dealer for details on accessories and their availability. unbalanced, Specifications shown are for SP mode unless otherwise indicated.
  • Page 52 VICTOR COMPANY OF JAPAN, LIMITED Printed in Japan COPYRIGHT© 2000 VICTOR COMPANY OF JAPAN, LTD. 0100MKV...
