Allied A97USMV Installation Instructions Manual

Warm air gas furnace upflow/horizontal left and right air discharge
Hide thumbs Also See for A97USMV:
Table of Contents

Advertisement

Quick Links

Upflow/Horizontal Left and Right Air Discharge
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, personal injury
or loss of life. Installation and service must be performed
by a licensed professional installer (or equivalent), service
agency or the gas supplier.
Unit Dimensions ..................................................................................... 2
Parts Arrangement ................................................................................. 3
Gas Furnace .......................................................................................... 4
Shipping and Packing List ...................................................................... 4
Safety Information .................................................................................. 4
Use of Furnace as a Construction Heater .............................................. 5
General .................................................................................................. 6
Setting Equipment .................................................................................. 6
Filters .................................................................................................... 11
Duct System .......................................................................................... 11
Pipe and Fittings Specifications ............................................................ 12
Joint Cementing Procedure .................................................................. 13
Venting Practices ................................................................................. 14
Vent Piping Guidelines .......................................................................... 15
Gas Piping ............................................................................................. 29
* P 5 0 6 8 8 7 - 0 1 *
(P) 506887-01
506887-01
INSTALLATION INSTRUCTIONS
A97USMV
Warm Air Gas Furnace
This manual must be left with the homeowner for future reference.
CAUTION
WARNING
A thermostat is not included and must be ordered
separately.
• A Comfort Sync
communicating applications.
• In non-communicating applications, a traditional non-
communication thermostat may be used.
In all cases, setup is critical to ensure proper system
operation.
Field wiring for both communicating and non-
communicating applications is illustrated in these
instructions.

TABLE OF CONTENTS

Electrical ............................................................................................... 32
Integrated Control ................................................................................. 41
Blower Motor Performance .................................................................... 46
Unit Start Up ......................................................................................... 57
Gas Pressure Measurement ................................................................. 58
High Altitude Information ...................................................................... 59
Proper Combustion ............................................................................... 59
Other Unit Adjustments ........................................................................ 61
Heating Sequence of Operation ............................................................ 62
Service .................................................................................................. 64
Planned Service .................................................................................... 66
Integrated Control Diagnostic Codes .................................................... 67
Configuring Unit Size Codes ................................................................. 70
Troubleshooting ..................................................................................... 71
Repair Parts List ................................................................................... 77
Issue 1213
NOTICE
TM
thermostat must be used in
Manufactured By
Allied Air Enterprises, Inc.
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
Page 1 of 78
