Service Bulletin
Subject:
Pre-Delivery and Service Guide
Models:
2005 Chevrolet Corvette
This is a special bulletin to introduce the 2005 Chevrolet
Corvette. The purpose of this bulletin is to make you
familiar with the vehicle's features and describe the
action your Service Department will need to take to
ensure that your dealership is able to fully service this
vehicle.
ABOUT THE VEHICLE
The 2005 Corvette marks the sixth design/engineering
of the Corvette legacy. "C6," as it is nicknamed, aims
at delivering more power, passion and precision to
America's performance icon, enabling it to compete
at the highest level with the world's absolute best
sports cars.
Configuration
Displacement — liters/cubic inches
Valve per Cylinder
Fuel System
Throttle Control
Bore x Stroke
Compression Ratio
Horsepower @ rpm
Torque (foot pounds) @ rpm
Transmission
The Tremec T56 six-speed manual transmission is
standard equipment and is a refined version of the
previous Tremec manual unit. There are two sets of gear
ratios available, base and Z51. The shifter is designed
for shorter throws for a more precise shift feel, and
the clutch has been revised for lighter, smoother effort.
Copyright 2004 General Motors Corporation. All Rights Reserved.

INFORMATION

Powertrain
Engine
The sixth-generation Corvette is powered by the
LS2 V8, one of a family of engines known as Gen4,
which represents the fourth generation of the
small-block V8. The LS2 displaces 6.0 liters, vs. the
5.7 liters of its Gen3 predecessor. The LS2 delivers not
only stunning horsepower for a small-block pushrod
V8 engine, but in a true measure of real-world efficiency,
it also delivers the best combination of horsepower
and fuel economy in the high sport segment
(estimated 18 mpg (12.6 L/100 km) city,
28 (8.1 L/100 km) highway).
LS2 Specifications
The 4-speed 4L65 automatic transmission has an
electronic controller that has been calibrated for
Performance Algorithm Shifting, a feature that
automatically selects the optimal gear for the specific
driving condition, especially for performance driving
and hard cornering. Under these driving conditions, the
transmission also shifts at higher RPM to provide
greater responsiveness and flexibility.
File In Section:
00 - General Information
Bulletin No.:
04-00-89-041
Date:
September, 2004
Overhead Valve (OHV) V8
6.0/364
2
Sequential Electronic Fuel Injection (SEFI)
Electronic Throttle Control (ETC)
101.60 mm x 92.0 mm
10.9:1
400 @ 6,000
400 @ 4,400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Corvette 2005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chevrolet Corvette 2005

  • Page 1 INFORMATION Subject: Pre-Delivery and Service Guide Models: 2005 Chevrolet Corvette This is a special bulletin to introduce the 2005 Chevrolet Powertrain Corvette. The purpose of this bulletin is to make you Engine familiar with the vehicle’s features and describe the...
  • Page 2 Page 2 September, 2004 Bulletin No.: 04-00-89-041 Chassis/Suspension located in the vehicle. It is possible for an operator to place their jacket or handbag in the hatch or Wheel and Tires trunk area with the key FOB inside and close the decklid.
  • Page 3 Bulletin No.: 04-00-89-041 September, 2004 Page 3 Power Seat Lumbar Fuel Quality This vehicle uses a single bladder for the lumbar and Fuel quality can significantly affect the vehicle’s operates differently from previous Corvettes. The performance and can cause fuel system concerns. pumps to inflate the lumbar only operate during the Premium unleaded gasoline with a posted octane of 91 inflate stage.
  • Page 4 Page 4 September, 2004 Bulletin No.: 04-00-89-041 Driving Lamps Fluids and Lubricants Driving lamps are located close to the ground and they Many of the fluids and lubricants specified for the are susceptible to road debris, sand and gravel. All Corvette may differ from those used in other GM of these can cause conditions from pitting to cracked products.
  • Page 5 Bulletin No.: 04-00-89-041 September, 2004 Page 5 Quality Pre-Delivery Inspection (PDI) • Shock Stuffers (Canada & Export Only): Stuffers are fitted to the front and rear shocks to prevent Delivery Condition excessive suspension travel during shipping. These Vehicles are delivered in the following condition: must be removed before the vehicle is driven.
