Wall Mounting

Installing Wall Mount

A wall mount kit (not included with TV) allows you to mount the TV onto a wall.
For the proper and safe installation of a wall mount, follow the detailed
instructions included in the wall mount kit.
1
Turn off your TV and disconnect all cables.
Carefully place the TV face down on a flat, clean, and padded surface.
2
If available, put TV cover or protective sheet onto the TV before laying
the TV down on flat surface.
Using a cross-tip screwdriver, remove four screws securing TV stand
3
to rear of TV. Remove TV stand.
Follow instructions in wall mount kit and install wall mount. Install TV
4
onto wall mount in accordance with wall mount kit instructions.
NOTE: Wall mount screw hole pattern on rear of TV is VESA 400 x 400mm, with
M8 screws
Setting Up The TV
For product protection and safety reasons, JVC strongly
recommends contacting a professional installer or technician
for assistance with the installation of the wall mount and with
the setup of your TV. JVC will not be held responsible for any
damage to the product or injury to yourself and others should
you decide to install the wall mount and TV without the
assistance of a professional installer or technician.
Do not install your TV to the wall mount while the TV is turned
on. It can result in personal injury due to electric shock.
A minimum of two people should be used when moving TV,
and when installing TV onto a wall mount.
4
