  • Page 1 Specific Information Manual 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 3: Table Of Contents

    350 Sundancer ® Printed in the U.S.A. June 2008 © Sea Ray Boats, Inc. • A Brunswick Company Sea Ray Boats, Inc. 0 Sea Ray Blvd., Knoxville, TN 37914 For information call 1-800-SRBOATS or fax 1-314-213-7878 (International 1-314-216-3333) Internet Address: http://www.searay.com Note: Not all accessories shown in pictures or described herein are standard equipment or even available as options.
  • Page 4 THIS PAGE INTENTIONALLy LEFT BLANK 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 5: Load Capacity

    Wear slip resistant footwear secured to your feet and Rear facing transom seats MUST NOT be used while hold on to rails or boat structure. engine is running or boat is moving. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 6 Carbon monoxide will be around the back of the boat when engines or generators are running. Move to fresh air, if you feel nausea, headache, dizziness, or drowsiness. NW-206-05 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 7 SUcH DiScHARGE cAUSES A FiLm oR SHEEN UPoN oR A DiScoLoRATioN oF THE SURFAcE oF THE WATER oR cAUSES A SLUDGE oR EmULSioN BENEATH THE SURFAcE oF THE WATER. VioLAToRS ARE SUBJEcT To A PENALTY oF $5,000. mRP 1744737 SR-744 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 8 Get fresh air is carbon monoxide detector alarm sounds. Carbon monoxide detoctor must be functioning at all times. NW-205-05 DANGER LEAViNG WiNDoW oPEN coULD iNDUcE EXHAUST FUmES iNTo cABiN RESULTiNG iN SEVERE PERSoNAL iNJURY oR DEATH MRP 1747493 SR-7135 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 9 MATERIALS THAT FLOAT and does not include drainage ter, and gray water. from toilets, urinals, hospitals, 12 TO 25 MILES and cargo spaces. PLASTICS LOCATED ON INSIDE OF GALLEy CABINET DOOR 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 10: Specifications

    NOTE: DIMENSIONS CAN VARy DEPENDING ON LOAD imenSionS and learanceS AND RUNNING CONDITIONS . 6.1) WATERLINE KEEL 350 Sundancer SpecificationS HeigHt dimenSionS ® (A) Overall Length (D) Keel to Top of Mast Light ....16' 1½" 4.91 m With Std. Swim Platform ..37' 6"...
  • Page 11 TRANSDUCER (OPT) MACERATOR (OPT) PORT RUDDER A/C PICKUP DEPTH STBD RUDDER TRANSDUCER (OPT) STBD ENGINE EXHAUST STBD ENGINE STERN THRUSTER ZINC PLATE SEACOCK GARBOARD (OPT) STBD SHAFT LOG GENERATOR DRAIN PICKUP (OPT) 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 12 CONTROLS VHF RADIO ENGINE SySTEMS DISPLAy NAVIGATION AIR SENSOR ELECTRONICS* IGNITION SWITCH STEREO REMOTE PANEL BOW THRUSTER AUTO PILOT* CONTROL VHF RADIO COMPONENT BOARD & SPEAKER FUSE BLOCK ACCESS * OPTIONAL EQUIPMENT 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 13 350 S ® undancer wnerS anual ontrol tation witch . 9.1) ontrol tation tarBoard witch . 9.2) 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 14 AFT SEAT (W/ STORAGE BELOW) ENGINE HATCH TRANSOM STORAGE TRANSOM WALK-THRU FOLDOUT AFT FACING FUEL FILL TRANSOM SEAT STANDARD SWIM SWIM PLATFORM LADDER (STANDARD) SWIM PLATFORM SWIM LADDER W/ (OPT) OPTIONAL PLATFORM 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 15 . 11.1) V-BERTH V-BERTH PRIVACy CURTAQIN GALLEy SINK REMOVABLE SALON TABLE STOVE CONVERTABLE SOFA / BERTH MICROWAVE MDP CABINET MID-BERTH PRIVACy HEAD SINK CURTAIN MID-BERTH HEAD / SHOWER CONVERTABLE SOFA 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 16: Cleats

    CLEAT CLEAT CLEAT CLEAT MAST LIGHT ALL-ROUND/ ANCHOR LIGHT PORT SWITCH NAVIGATION ANCHOR LIGHT PANEL LIGHT SWITCH SWITCH 11. l ighTing See General Information Manual for a detailed explanation of the lighting. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 17 STERN NAV. / ANcHoR LiGHT BULB REPLACEMENT BULB REPLACEMENT BULB REPLACEMENT FUSE TyPE BULB FUSE TyPE BULB LED LIGHT - NO xENON “xH” MINIATURE #12V10WPERKO #12V10WPERKO #70-0 REPLACEMENT BULB HALOGEN BI-PIN, 24V/10W 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 18 GENERATOR FLOAT SWITCHES WASTE VENT FILTER BILGE PUMP GENERATOR WASTE WATER MUFFLER (OPT) HOLDING TANK PORT POWER MACERATOR (OPT) TRIM PUMP PORT POWER BILGE BLOWER TRIM PUMP TRIM TABS BILGE BLOWER PUMP 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 19 GENERATOR FLOAT SWITCHES WASTE VENT FILTER BILGE PUMP GENERATOR WASTE WATER MUFFLER (OPT) HOLDING TANK PORT POWER MACERATOR (OPT) TRIM PUMP PORT POWER BILGE BLOWER TRIM PUMP TRIM TABS BILGE BLOWER PUMP 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 20 (OPT) HOLDING TANK GENERATOR MACERATOR (OPT) SEACOCK (OPT) GENERATOR PORT ENGINE STRAINER (OPT) MUFFLER GENERATOR A/C PUMP MUFFLER (OPT) STBD ENGINE A/C SEACOCK MUFFLER A/C STRAINER FLOAT SWITCH BILGE BLOWERS BILGE PUMP 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 21 (OPT) HOLDING TANK GENERATOR MACERATOR (OPT) SEACOCK (OPT) GENERATOR PORT ENGINE STRAINER (OPT) MUFFLER GENERATOR A/C PUMP MUFFLER (OPT) STBD ENGINE A/C SEACOCK MUFFLER A/C STRAINER FLOAT SWITCH BILGE BLOWERS BILGE PUMP 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 22: Fuel System

    ENGINE ELECTRIC SHUTOFF VALVE FUEL TANK VENT GENERATOR ELECTRIC SHUTOFF VALVE GENERATOR FUEL FILTER FUEL TANKS ENGINE ELECTRIC FUEL FILL SHUTOFF VALVE FUEL TANK VENT GENERATOR FUEL SUPPLy ENGINE FUEL SUPPLy FUEL FILL 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 23: Entertainment System

    An optional TV with DVD player and game system port is optionally available in the V-Berth and Mid-Stateroom. ENTERTAINMENT A/V INPUT MP3 PORT MDP CABINET SySTEM cabinet door removed for clarity 350 Sundancer ® Manual Part Number: MRP 1944467...

  • Page 24: Engine Hatch

    NOT obligated to make any updates to units built prior to changes. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 25 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (1 . 21.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 26 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (2 . 22.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 27 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (3 . 23.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 28 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (4 . 24.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 29 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (5 . 25.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 30 350 S ® undancer wnerS anual dc w ilge iring chematic drawing no. 09-601 (6 . 26.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 31 350 S ® undancer wnerS anual dc w iring chematic anmar drawing no. 09-605 . 27.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 32 350 S ® undancer wnerS anual dc B reaker anel iring iagram drawing no. 09-606 . 28.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 33 350 S ® undancer wnerS anual dc w aBin iring chematic drawing no. 09-610 (1 . 29.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 34 350 S ® undancer wnerS anual dc w aBin iring chematic drawing no. 09-610 (2 . 30.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 35 350 S ® undancer wnerS anual dc w aBin iring chematic drawing no. 09-610 (3 . 31.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 36 350 S ® undancer wnerS anual hruSter iring chematic drawing no. 09-612 . 32.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 37 350 S ® undancer wnerS anual indlaSS iring chematic drawing no. 09-614 . 33.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 38 09-620 (1 . 34.1) tv S chematic drawing no. 09-620 (2 . 34.2) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 39 09-620 (3 . 35.1) tv S chematic drawing no. 09-620 (4 . 35.2) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 40 350 S ® undancer wnerS anual tv S chematic drawing no. 09-620 (5 . 36.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 41 350 S ® undancer wnerS anual enerator chematic drawing no. 09-634 . 37.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 42 350 S ® undancer wnerS anual tereo chematic tandard drawing no. 09-640 . 38.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 43 350 S ® undancer wnerS anual tereo chematic remium drawing no. 09-642 (1 . 39.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 44 350 S ® undancer wnerS anual tereo chematic remium drawing no. 09-642 (2 . 40.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 45 350 S ® undancer wnerS anual tove witch iring iagram drawing no. 09-655 . 41.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 46 350 S ® undancer wnerS anual mdp w (120vac/12vdc) iring chematic drawing no. 09-660 (1 . 42.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 47 350 S ® undancer wnerS anual mdp w (120vac/12vdc) iring chematic drawing no. 09-660 (2 . 43.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 48 350 S ® undancer wnerS anual mdp w (220vac/12vdc) iring chematic drawing no. 09-662 (1 . 44.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 49 350 S ® undancer wnerS anual mdp w (220vac/12vdc) iring chematic drawing no. 09-662 (2 . 45.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 50 350 S ® undancer wnerS anual dc i nterconnection iagram drawing no. 09-670 . 46.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 51 350 S ® undancer wnerS anual ac S yStem iring iagram drawing no. 09-672 (1 . 47.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
  • Page 52 350 S ® undancer wnerS anual ac S yStem iring iagram drawing no. 09-672 (2 . 48.1) Warning: DO NOT attempt to work on the electrical system of this boat without professional assistance. 350 Sundancer ® Manual Part Number: MRP 1944467...
