Memory Expansion - Panasonic CF-25 Series Operating Instructions Manual

Hardware Expansion

Memory Expansion

Mounting
Removal
20
A RAM module may be installed in the computer to increase the computer's memory.
RAM module specifications
144 pins, 60/70 ns, 3.3 V, SO-DIMM, EDO
NOTE
Do not add or remove additional memory while the computer is in the suspend or
hibernation mode. Doing so could damage the unit or prevent the module from
being properly recognized.
Turn the computer off by pressing
switch in the ON position simultaneously.
Use a screwdriver or to loosen the two screws located to-
ward the front of the computer.
Remove the cover.
Put the RAM module into the slot diagonally; the side with
the metal connectors goes into the slot. Then, press down
on the module until it snaps into place and is held firmly down
by the hooks.
Hook
Pull the hooks on both sides outwards.
Gently remove the RAM module from the slot.
Replace the cover and tighten the two screws.
and holding the power
