IOGear NetShair Nano GWPAP1 Quick Start Manual

Ultra portable wi-fi router/access point
Hide thumbs
Table of Contents

Advertisement

Quick Links

Quick Start Guide
NetShair Nano
Ultra Portable Wi-Fi Router/Access Point
GWPAP1
PART NO. Q1376
www.iogear.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetShair Nano GWPAP1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IOGear NetShair Nano GWPAP1

Summary of Contents for IOGear NetShair Nano GWPAP1

  • Page 1 Quick Start Guide NetShair Nano Ultra Portable Wi-Fi Router/Access Point GWPAP1 PART NO. Q1376 www.iogear.com...
  • Page 2 IOGEAR makes no warranty of any kind with regards to the information presented in this document. All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR assumes no responsibility for any inaccuracies or errors that may appear in this document.

  • Page 3: Table Of Contents

    Table of Content Package Contents System Requirements Overview Charging Router Mode or AP Mode Hardware Installation Software Setup: Which device do you have? NetShair Nano Setup - iPod / iPhone / iPad Internet Connection - iPod / iPhone / iPad Wireless Security Settings - iPod / iPhone / iPad NetShair Nano Setup - Android Internet Connection - Android...

  • Page 4: Package Contents

    Package Contents 1 x NetShair Nano Wi-Fi Router/ 1 x Quick Start Guide Access Point 1 x Warranty Card System Requirements • USB port or USB charger • Wired Ethernet connection with standard RJ45 connector • Wi-Fi enabled computer or mobile device with either Android 2.3.3+ or iOS 5.1+ •...

  • Page 5: Charging

    Charging USB pass-through charging port: connect to charge most smartphones and USB devices (1A maximum pass-through current). Router Mode or AP Mode The NetShair Nano can be used in one of two operating modes: Router Mode and Access Point Mode Router Mode: This is the default setting and is commonly used for most applications.

  • Page 6: Hardware Installation

    fee for each device connected, use Router Mode to share a single IP address between your connected devices. Using AP mode on these networks would require each device to have a separate IP address, likely causing an access charge for each one. Hardware Installation Do not connect the Ethernet cable until app/client setup is complete!

  • Page 7: Netshair Nano Setup Ipod / Iphone / Ipad

    NetShair Nano Setup iPod / iPhone iPad Do not connect Ethernet cable until last step! (See Internet Connection) 1. Make sure you have downloaded the NetShair Nano App prior to setup! 2. To download the NetShair Nano App, open the App Store on your iPod, iPhone or iPad.

  • Page 8: Internet Connection - Ipod / Iphone / Ipad

    Internet Connection iPod / iPhone / iPad Router Mode Setting Follow the steps below to setup the NetShair Nano for Router Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1.
  • Page 9 Router Mode: DHCP (Default) 1. On the Home screen, tap Advance Setting, then Set WAN Interface. 2. The default setting is DHCP client. If the network requires a username and password to access, select PPPoE. Enter the username and password then tap OK. 3.
  • Page 10 Router Mode: PPPoE NetShair Nano comes preset for DHCP Mode which is the standard mode for cable internet providers. When using NetShair Nano with a DSL Modem please follow the steps below: 1. Make sure the NetShair_Nano_XXXX Wi-Fi Network is connected. 2.
  • Page 11 Access Point Mode Setting Follow the steps below to setup the NetShair Nano for AP Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1. Make sure the “NetShair_Nano_XXXX” Wi-Fi network is connected.

  • Page 12: Wireless Security Settings - Ipod / Iphone / Ipad

    Wireless Security Settings iPod / iPhone iPad In order to change the Network Name (SSID) or password (Network Key) for the wireless network created by NetShair Nano, please refer to the following steps: Option 1: Wireless Password To change the pre-shared network key, enter a new key with a minimum of 8 characters.

  • Page 13: Netshair Nano Setup Android

    NetShair Nano Setup Android Do not connect Ethernet cable until last step! (See Internet Connection) 1. Make sure you have downloaded the NetShair Nano App prior to setup! 2. To download the NetShair Nano App, open the Google Play™ Store on your Android device. Search for the “NetShair Nano”...

  • Page 14: Internet Connection Android

    Internet Connection Android Router Mode Setting Follow the steps below to setup the NetShair Nano for Router Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1.
  • Page 15 Router Mode: DHCP (Default) 1. On the Home screen, tap Advance Settings, then Set WAN Interface. 2. By default the NetShair Nano is set to DHCP client. If the network requires a username and password to access, select PPPoE. Enter the username and password then tap OK.
  • Page 16 Router Mode: PPPoE NetShair Nano comes preset for DHCP Mode which is the standard mode for cable internet providers. When using NetShair Nano with a DSL Modem please follow the steps below: 1. Make sure the NetShair_Nano_XXXX Wi-Fi Network is connected. 2.
  • Page 17 Access Point Mode Setting Follow the steps below to setup the NetShair Nano for AP Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1. Make sure the “NetShair_Nano_XXXX” Wi-Fi network is connected.

  • Page 18: Wireless Security Settings Android

    Wireless Security Settings Android In order to change the Network Name (SSID) or password (Network Key) for the wireless network created by NetShair Nano, please refer to the following steps: Option 1: Wireless Password To change the pre-shared network key, enter a new key with a minimum of 8 characters.

  • Page 19: Netshair Nano Setup Computer / Other

    NetShair Nano Setup Computer / Other Note: Follow the steps below to setup NetShair Nano using the web client for computers or mobile devices with a full HTML browser. Do not connect Ethernet cable until last step! (See Internet Connection) 1.

  • Page 20: Internet Connection Computer / Other

    Internet Connection Computer / Other Router Mode Setting Follow the steps below to setup the NetShair Nano for Router Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1.
  • Page 21 Router Mode: DHCP (Default) 1. By default the NetShair Nano is set to DHCP client. If the network the NetShair Nano is connected to requires a username and password to access, select TCP/IP Settings, then click WAN Interface. Enter the username and password provided by the administrator and click Apply Changes.
  • Page 22 5. Once rebooted, connect an Ethernet cable from the modem to the NetShair Nano. 6. Connect back to NetShair_Nano_XXXX Wi-Fi network. Open your web browser to access the internet. Router Mode: PPPoE NetShair Nano comes preset for DHCP Mode which is the standard mode for cable internet providers.
  • Page 23 Access Point Mode Setting Follow the steps below to setup the NetShair Nano for AP Mode. If you are unsure about which mode to use, see Router Mode or AP Mode (page 5) to confirm the proper setting. 1. Make sure the “NetShair_Nano_XXXX” Wi-Fi network is connected.

  • Page 24: Wireless Security Settings Computer / Other

    Wireless Security Settings Computer / Other In order to change the Network Name (SSID) or password (Network Key) for the wireless network created by NetShair Nano, please refer to the following steps: Option 1: Wireless Password 1. Make sure the “NetShair_Nano_XXXX” Wi-Fi network is connected.
  • Page 25 Option 2: Network Name (SSID) 1. Make sure the “NetShair_Nano_XXXX” Wi-Fi network is connected. Open the Browser and enter 192.168.1.254 into the address bar to access the web client. 2. Select Wireless, then click Basic Settings 3. Enter the new network name in the SSID box and click Apply Changes.

  • Page 26: Hotel Usage Explanation Note

    Hotel Usage Explanation Note Hotel provides wired Internet access 1. Do not connect the Ethernet cable until app/client setup is complete. 2. Power on the NetShair Nano by plugging it into a powered USB port on your Laptop or Desktop or by plugging it into a USB charging adapter of a USB mobile device.

  • Page 27: Ic Statement

    IC Statement IC Caution: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil est conforme la norme d’Industrie Canada de licence RSS(s).

  • Page 28: Fcc Statement

    FCC Statement This product has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful radio frequency interference when operated in a commercial environment.

  • Page 29: Limited Warranty

    WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support Warranty Information This product carries a 1 Year Limited Warranty. For the terms and conditions of this warranty, please go to http://www.iogear.com/support/warranty...
  • Page 30 GEAR ® © 2014 IO...
