Wireless-G Broadband Router
GWA502 Quick Start Guide
Read this guide thoroughly and follow the installation and operation procedures
carefully to prevent any damage to the unit and/or any of the devices it connects to.
GWA502 package contains:
1 Wireless-G Broadband Router
1 Power Adapter
1 Ethernet Cable
1 Manual CD
1 Quick Start Guide
1 Warranty/Registration Card
Copyright © 2004 IOGEAR
All brand names and trademarks are the registered
property of their respective owners
PKG-M0108/QS
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWA502 and is the answer not in the manual?

Questions and answers

Related Manuals for IOGear GWA502

Summary of Contents for IOGear GWA502

  • Page 1 Wireless-G Broadband Router GWA502 Quick Start Guide Read this guide thoroughly and follow the installation and operation procedures carefully to prevent any damage to the unit and/or any of the devices it connects to. GWA502 package contains: 1 Wireless-G Broadband Router...
  • Page 2 1. Welcome Thank you for choosing IOGEAR or surfing the Internet wirelessly. We hope you will have as much fun using your IOGEAR Wireless-G Broadband Router, as we had designing it. Rest assured, your IOGEAR up-time for you to stay up-and-running. If for any reason you have a problem, we stand behind our products with an industry-leading 3 year factory warranty, so you can have peace-of-mind with your ®...

  • Page 3: Installation

    3. Installation Step. 1 Take your IOGEAR ® Wireless-G Broadband Router out of box. Simply plug-in the included AC Adapter to the wall outlet, then to the Broadband Router. Make sure the power LED illuminates; otherwise, try another AC Wall Outlet.
  • Page 4 Step. 4 To proceed to the basic setup options, click on the Typical button. Step. 5 You will now be asked for the Time Zone you are in. Select your Time Zone, and select whether you wish to enable Daylight Savings Time. Click Next to continue. Step.
  • Page 5 a. Cable Modem and DHCP Client - If your broadband access is through a cable modem, or if your IP address is automatically assigned by your service provider or a DHCP server, you should choose this type. • If your ISP gave you a Host Name or a MAC address, you can enter them on the following page b.
  • Page 6 Step. 8 You will now see the Firewall settings. IOGEAR Firewall. Please note high Firewall protection will make your network securer, but may cause wireless gateway's performance to be lower. Click Next when you are done. Step. 9 This is the summary page showing all configurations you've set. Click Next when you are done.

  • Page 7: Firmware Upgrade

    Step. 2 Click the Browse button, a file window will be brought up. Locate the updated Firmware file you downloaded from IOGEAR website, click Ok; it will appear in the Upgrade Firmware box. Step. 3 Click Upgrade button, a warning message will pop out. Please do not unplug the power of the device or turn off your computer during firmware upgrading.

  • Page 8: Advanced Setup

    5. Advanced Setup Step. 1 Log-in to your Wireless Broadband Router (Default as http://192.168.62.10) Step. 2 You will now be asked for User Name and Password. Unless you have changed them, they should be default as admin (user name); admin (Password). Step.
  • Page 9 Step. 4 The Customized Configuration menu is separated into seven categories. System It includes all the basic configuration tools, such as options to control management access, upgrading system firmware and restart system. The router must have an IP address for the local network. You can also enable DHCP service for dynamic IP address allocation to your clients, or configure filtering functions based on specific clients or protocols.

  • Page 10: Radio And Tv Interference

    6. Radio and TV Interference This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
