- Page 1 08-09-1371 WIDESCREEN 32" THIN LCD MONITOR...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS SAFETY PRECAUTIONS SAFETY PRECAUTIONS SAFETY PRECAUTIONS SAFETY PRECAUTIONS WARNING: TO REDUCE THE RISK OF CAUTION ELECTRIC SHOCK, DO NOT REMOVE COVER BACK). USER- RISK OF ELECTRIC SHOCK DO NOT OPEN SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL. RISQUE DE CHOC ÉLECTRIQUE NE AVIS PAS OUVRIR... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. 10. Protect the power cord from being walked on or pinched particularly at Keep these instructions. plugs, convenience receptacles, and Heed all warnings. the point where they exit from the Follow all instructions. apparatus. Do not use this apparatus near 11. -
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ..........2 IMPORTANT SAFETY INSTRUCTIONS ....... 3 REMOTE CONTROL ............5 ACCESSORIES ............5 REMOTE CONTROL REFERENCE GUIDE ......6 UNIT REFERENCE GUIDE .......... 7-8 CONNECTIONS ............9-13 Connecting to A/V devices (VCR, Camcor der, Game System, etc.) ........... -
Page 5: Remote Control
REMOTE CONTROL USING THE REMOTE CONTROL USING THE REMOTE CONTROL USING THE REMOTE CONTROL USING THE REMOTE CONTROL USING THE REMOTE CONTROL • Point the remote control at the REMOTE SENSOR located on the unit. • When using this unit in very bright light, the infrared REMOTE CONTROL SENSOR may not work properly. -
Page 6: Remote Control Reference Guide
REMOTE CONTROL REFERENCE GUIDE 8) 8) 8) 8) 8) MENU Button MENU Button MENU Button MENU Button MENU Button Display and exit the menu screen. 9 9 9 9 9 ) ) ) ) ) Cursor ( Cursor ( Cursor ( Cursor ( Cursor ( , , , , ,... -
Page 7: Unit Reference Guide
UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE TOP & FRONT VIEW TOP & FRONT VIEW TOP & FRONT VIEW TOP & FRONT VIEW TOP & FRONT VIEW 1) 1) 1) 1) 1) HEADPHONE jack HEADPHONE jack HEADPHONE jack... -
Page 8: Unit Reference Guide
UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE UNIT REFERENCE GUIDE BACK & BOTTOM VIEW BACK & BOTTOM VIEW BACK & BOTTOM VIEW BACK & BOTTOM VIEW BACK & BOTTOM VIEW 22 23 17 18 19 12) Power Cord Power Cord Power Cord... -
Page 9: Connections
CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTING TO A/V DEVICES CONNECTING TO A/V DEVICES CONNECTING TO A/V DEVICES CONNECTING TO A/V DEVICES CONNECTING TO A/V DEVICES (VCR, Camcor (VCR, Camcor (VCR, Camcor (VCR, Camcor (VCR, Camcorder der, Game System, etc.) , Game System, etc.) , Game System, etc.) , Game System, etc.) , Game System, etc.) - Page 10 CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS Connecting to Devices with a Composite (yellow RCA-type) Video Output To connect to A/V devices such as a VCR or camcorder: - Connecting a VCR - Connecting a VCR - Connecting a VCR - Connecting a VCR - Connecting a VCR Connect the right (red) and left (white) audio output from the VCR to the right...
- Page 11 CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTING TO CONNECTING TO CONNECTING TO SOURCES WITH COMPONENT VIDEO OUTPUT SOURCES WITH COMPONENT VIDEO OUTPUT SOURCES WITH COMPONENT VIDEO OUTPUT SOURCES WITH COMPONENT VIDEO OUTPUT CONNECTING TO CONNECTING TO SOURCES WITH COMPONENT VIDEO OUTPUT (DVD - only 480i, 480p, 720p &...
-
Page 12: Connecting An Audio Amplifier
CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTING AN AUDIO AMPLIFIER CONNECTING AN AUDIO AMPLIFIER CONNECTING AN AUDIO AMPLIFIER CONNECTING AN AUDIO AMPLIFIER CONNECTING AN AUDIO AMPLIFIER This connection allows you to use an audio amplifier and external speakers. Connect the right (red) and left (white) audio OUTPUT from this unit to the right (red) and left (white) audio INPUT on your amplifier. -
Page 13: Connecting The Power Cord
CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTIONS CONNECTING THE POWER CORD CONNECTING THE POWER CORD CONNECTING THE POWER CORD CONNECTING THE POWER CORD CONNECTING THE POWER CORD • Plug the power cord into an outlet. STANDBY/ON STANDBY/ON • Press the STANDBY/ON STANDBY/ON STANDBY/ON button on top of the unit or on the remote control to turn on the unit. -
Page 14: Installation
INST INST ALLA INST ALLA ALLA TION ALLA TION TION TION INST INST ALLA TION REMOVING THE BASE ST REMOVING THE BASE STAND REMOVING THE BASE ST REMOVING THE BASE ST REMOVING THE BASE ST WARNING: The LCD Display is very fragile, and must be protected at all times when removing the base stand. -
Page 15: Using Headphones
USING HEADPHONES USING HEADPHONES USING HEADPHONES USING HEADPHONES USING HEADPHONES • Turn down the volume before connecting headphones to the unit, then adjust the volume to your desired level. • When headphones are connected, no sound will come from the front speakers. Note: Note: Note:... -
Page 16: Menu Setup
MENU SETUP MAIN MENU MAIN MENU MAIN MENU MAIN MENU MAIN MENU 1. Press the INPUT INPUT INPUT INPUT button. INPUT 2. Use button to select the options (AV1, (AV1, (AV1, (AV1, (AV1, AV2, YUV1, YUV2, PC IN) AV2, YUV1, YUV2, PC IN) AV2, YUV1, YUV2, PC IN) . -
Page 17: Screen Menu
MENU SETUP SCREEN MENU SCREEN MENU SCREEN MENU SCREEN MENU SCREEN MENU 1. Press the MENU MENU MENU button. MENU MENU 2. Use button to select the Screen Screen Screen Screen menu. Screen (Size mode, DLC mode, H- (Size mode, DLC mode, H- 3. - Page 18 MENU SETUP SOUND MENU SOUND MENU SOUND MENU SOUND MENU SOUND MENU 1. Press the MENU MENU MENU button. MENU MENU Sound Sound 2. Use button to select the Sound Sound Sound menu. 3. Use button to select the options (Sound mode, Bass, T (Sound mode, Bass, T (Sound mode, Bass, T (Sound mode, Bass, Tr r r r r eble &...
-
Page 19: Setup Menu
MENU SETUP SETUP MENU SETUP MENU SETUP MENU SETUP MENU SETUP MENU 1. Press the MENU MENU MENU MENU button. MENU 2. Use button to select the Set up Set up Set up Set up Set up menu. 3. Use button to select the options (Restore setting, Sleep (Restore setting, Sleep (Restore setting, Sleep... -
Page 20: Parental Control
MENU SETUP PARENT PARENT AL CONTROL AL CONTROL PARENT PARENTAL CONTROL PARENT AL CONTROL AL CONTROL 1. Press the MENU button. 2. Use button to select the Set up Set up Set up Set up Set up menu. Parental control Parental control 3. -
Page 21: Closed-Captioning
MENU SETUP CLOSED CAPTIONING CLOSED CAPTIONING CLOSED CAPTIONING CLOSED CAPTIONING CLOSED CAPTIONING Allows conversations, narration, and sound effects in home videos to be viewed as captions on the screen. MENU MENU 1. Press the MENU MENU MENU button. 2. Use button to select the Setup Setup Setup... -
Page 22: On-Screen Display Setting
MENU SETUP ON SCREEN DISPLA ON SCREEN DISPLA Y SETTING Y SETTING ON SCREEN DISPLA ON SCREEN DISPLAY SETTING ON SCREEN DISPLA Y SETTING Y SETTING 1. Press the MENU MENU MENU MENU MENU button. 2. Use button to select the OSD OSD menu, and then press button to enter. -
Page 23: Troubleshooting Guide
TROUBLE SHOOTING GUIDE SYMPTOM CAUSE (AND REMEDY) • Ensure that the AC power cord is connected. No power. • Turn on the unit. • Remove any obstacles between the remote and the The remote does not function. unit. • Use the remote near the unit. •... - Page 24 Printed in China 811-173291-011...
