P/N 126628-01 Rev. A 10/01/13
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain
replacement parts or accessory items when needed.
Keep it with your other important papers.
This fireplace is approved for use as a wood burning
fireplace or for use with a vented gas log approved
to ANS Z21.60, Z21.84 standards or for use with a
vent-free gas log heater approved to ANS Z21.11.2
standard. An INNOVATIVE HEARTH PRODUCTS, LLC
hood must be installed when using a vent-free log
heater (see Accessories, page 18).
PFS
®
C
US
REPORT NO. F09-171
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For more information, visit www.Superiorfireplaces.US.com
INSTALLATION AND OPERATION
INSTRUCTIONS
Merit
Wood burning Fireplaces
MODELS
WRT2036WS
WRT2036WSI
WCT2036WS
WCT2036WSI
P126628 01
This wood burning fireplace complies with UL127-
CAN/ULC-S610-M87 standard as a FACTORY BUILT
APPLIANCE.
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before instal-
lation to determine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Series
™
Advertisement
Table of Contents
Related Manuals for Superior Merit WRT2036WS
Summary of Contents for Superior Merit WRT2036WS
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS Merit Series ™ Wood burning Fireplaces MODELS WRT2036WS WRT2036WSI WCT2036WS WCT2036WSI P126628 01 ® REPORT NO. F09-171 P/N 126628-01 Rev. A 10/01/13 KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE This book is valuable. In addition to instructing you...
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Specifications .................4 special attention to all warnings and safety information. Fireplace Installation ..............5 Following these safety, care, and operation instructions will help Venting Installation ................7 ensure many years of dependable and enjoyable service from your Optional Gas Line Installation ............13... - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. CHARCOAL) CAN RESULT IN CARBON MONOXIDE SOME EXAMPLES OF CONDITIONS THAT COULD POISONING, WHICH MAY LEAD TO DEATH! CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning – Early signs of carbon monoxide poisoning resemble the flu with headaches, • BURNING QUANTITIES OF SCRAP LUMBER, PINE BRANCHES, PAPER OR CARDBOARD BOXES...
-
Page 4: Specifications
SPECIFICATIONS 1" AIRSPACE TO COMBUSTIBLE MATERIAL NO COMBUSTIBLE MATERIAL ON FACE 0" TO TOP SPACERS AIR KIT GAS LINE KNOCK OUT KNOCK OUT COMBUSTIBLE WALL BOARD 0.75" AIR SPACE BACK AND 13.875" SIDES 9.125" 9.625" NOT LESS THAN 14" TO 10.188"... -
Page 5: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION To determine safest and most efficient location for fireplace, you must take into consideration the following guidelines: 1. Location must allow for proper clearances (see Figures 1 and 2). 2. Consider a location where fireplace will not be affected by drafts, air conditioning ducts, windows or doors. - Page 6 FIREPLACE INSTALLATION Continued MANTELS WARNING: Hearth extension is to be installed A mantel may be installed if desired (see Figure 4). Woodwork such only as shown in Figure 3. as wood trims, mantels or any other combustible material projecting from front face must not be placed within 9" of fireplace opening (and within 9"...
-
Page 7: Venting Installation
VENTING INSTALLATION FIREPLACE INSTALLATION Continued OPTIONAL OUTSIDE AIR KIT (MODEL AK4/AK4F) FAN/BLOWER KIT ASSEMBLY Fan or blower kit is optional with this fireplace (for circulating models Installation of outside air kit should be performed during rough fram- only). Use of blowers or fans other than those manufactured by IHP ing of fireplace due to the nature of it's location. - Page 8 VENTING INSTALLATION Continued ASSEMBLY AND INSTALLATION OF DOUBLE WALL CHIMNEY WARNING: The opening in collar around chimney SYSTEM at top of fireplace must not be obstructed. Never use Each double wall chimney section consists of a galvanized outer blown insulation to fill chimney enclosure pipe, a stainless steel inner flue pipe and a wire spacer.
- Page 9 VENTING INSTALLATION Continued Return Elbow Return Elbow Return Elbow Offset Offset Elbow 6' Max. 6' Max. Elbow Ceiling Support Pipe Return 6' Max. 12S-8DM Elbow 6' Max. Return Offset Offset Elbow Elbow Offset Elbow 6' Max. 6' Max. Elbow Figure 9 - Typical Offset Installation See Detail A Ceiling Support Pipe 12S-8DM...
- Page 10 VENTING INSTALLATION Continued FIRESTOP SPACERS (3600FS-8DM-1) OFFSET RISE CHIMNEY LENGTH 48" 36" 24" 18" 12" Firestop spacers are required at each point where chimney penetrates " " ELBOW SET ONLY a floor space. Their purpose is to establish and maintain required "...
- Page 11 VENTING INSTALLATION Continued Storm Collar Installation (SC1) Minimum Measurements Place storm collar over pipe and slide down until it is snug against " open edge of flashing (see Figure 16). Use SC1 for all round termina- (36.5 cm) 30" tions. Apply waterproof caulk around perimeter of collar to provide 1"...
- Page 12 VENTING INSTALLATION Continued CHASE INSTALLATIONS Level of Flue Gas Instructions for chase installations are included with chase style ter- Outlet mination chosen. In a multiple chase installation, be sure to provide adequate distance between terminations to prevent smoke spillage 2' Min. from one termination to another.
-
Page 13: Optional Gas Line Installation
OPTIONAL GAS LINE INSTALLATION A gas line or gas log lighter may be installed for the purpose of If you install a decorative gas appliance (vented gas log), decorative installing a vented or vent-free decorative gas appliance incorporat- gas appliance must comply with the Standard for Decorative Gas ing an automatic shutoff device and complying with the Standard Appliance for Installation in Solid Fuel Burning Fireplaces, ANSI for Decorative Gas Appliances for Installation in Vented Fireplaces,... -
Page 14: Operation And Maintenance
OPERATION AND MAINTENANCE GLASS DOORS WARNING: Risk of fire! Replace grate with IHP Glass doors are optional with this fireplace. When fireplace is in model 107001-01 only. This grate has been designed to operation, doors must be fully opened or fully closed position only keep the operation of your fireplace safe and efficient. -
Page 15: Technical Service
REPLACEMENT PARTS TECHNICAL SERVICE Note: Use only original replacement parts. You may have further questions about installation, operation, or troubleshooting. Please contact your IHP dealer for any questions This will protect your warranty coverage for parts replaced under or concerns a. When calling your dealer please have your model and warranty. -
Page 16: Parts
PARTS WOOD BURNING FIREPLACE MODELS WRT2036WS, WRT2036WSI, WCT2036WS, WCT2036WSI www.Superiorfireplaces.US.com 126628-01A... - Page 17 PARTS WOOD BURNING FIREPLACE MODELS WRT2036WS, WRT2036WSI, WCT2036WS, WCT2036WSI This list contains replaceable parts used in your fireplace. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards.
-
Page 18: Accessories
ACCESSORIES DOUBLE WALL PIPE BI-FOLD GLASS DOOR 12-8DM 12-8HT BDB36 - Black 18-8DM 18-8-HT BDB36B - Brushed Brass 24-8DM 24-8HT BDB36P - Platinum 36-8DM 36-8HT 48-8DM 48-8HT ROOF FLASHING 0 TO 6/12 PITCH - V6F-8DM 6/12 TO 12/12 PITCH - V12F-8DM STORM COLLAR SC1-1 1"... - Page 19 ACCESSORIES Continued ROUND TOP TERMINATIONS WITH LOUVERS OUTSIDE AIR KIT FOR SIDE WALL INSTALLATION - AK4 RLT-8DM, RLT-8HT ROUND TOP TERMINATIONS WITH LOUVERS WITH SLIP SECTION RLTT-8DM, RLTT-8HT OUTSIDE AIR KIT FOR FLOOR INSTALLATION AK4F SQUARE TOP TERMINATION WITH LOUVERS ET-8DM, ET-8HT SQUARE TOP TERMINATION WITH LOUVERS AND SLIP SECTION...
- Page 20 IHP reserves the right to make changes at any time, without notice, in design, materials, specifica- tions, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. 1508 Elm Hill Pike, Suite 108 P126628 01 Nashville, TN 37210 1-800-655-2008...
