P/N 126622-01 Rev. D 10/2014
This book is valuable. In addition to instructing you
on how to install and maintain your appliance, it also
contains information that will enable you to obtain
replacement parts or accessory items when needed.
Keep it with your other important papers.
This fireplace is approved for use as a wood burning
fireplace or for use with a vented gas log approved
to ANS Z21.60, Z21.84 standards or for use with a
vent-free gas log heater approved to ANS Z21.11.2
standard. An INNOVATIVE HEARTH PRODUCTS, LLC
hood must be installed when using a vent-free log
heater (see Accessories, page 18).
PFS
®
C
US
REPORT NO. 10-078
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For more information, visit Superiorfireplaces.US.com
INSTALLATION AND OPERATION
INSTRUCTIONS
Pro Series
Wood burning Fireplaces
MODELS
WRT3042RS
WRT3042RSI
WRT3042RH
WRT3042WS
WRT3042WSI
WRT3042WH
P126622 01
This wood burning fireplace complies with UL127-
CAN/ULC-S610-M87 standard as a FACTORY BUILT
APPLIANCE.
FOR CANADA: The authority having jurisdiction
(such as the municipal building department, fire
department, etc.) should be contacted before instal-
lation to determine the need to obtain a permit.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WCT3042RS
WCT3042RSI
WCT3042RH
WCT3042WS
WCT3042WSI
WCT3042WH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Superior WRT3042RS
Summary of Contents for Superior WRT3042RS
- Page 1 INSTALLATION AND OPERATION INSTRUCTIONS Pro Series Wood burning Fireplaces MODELS WRT3042RS WCT3042RS WRT3042RSI WCT3042RSI WRT3042RH WCT3042RH WRT3042WS WCT3042WS WRT3042WSI WCT3042WSI WRT3042WH WCT3042WH ® P126622 01 REPORT NO. 10-078 P/N 126622-01 Rev. D 10/2014 KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE This book is valuable. In addition to instructing you...
-
Page 2: Table Of Contents
Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety .....................2 Please carefully read and follow all instructions in this manual. Pay Specifications .................4 special attention to all warnings and safety information. Fireplace Installation ..............5 Following these safety, care, and operation instructions will help Venting Installation ................7 ensure many years of dependable and enjoyable service from your Optional Gas Line Installation ............13... - Page 3 SAFETY Continued WARNING: CONTINUED OVERFIRING CAN PER- WARNING: BURNING IMPROPER FUEL (I.E. MANENTLY DAMAGE YOUR FIREPLACE SYSTEM. CHARCOAL) CAN RESULT IN CARBON MONOXIDE SOME EXAMPLES OF CONDITIONS THAT COULD POISONING, WHICH MAY LEAD TO DEATH! CAUSE OVERFIRING ARE: Carbon Monoxide Poisoning – Early signs of carbon monoxide poisoning resemble the flu with headaches, • BURNING QUANTITIES OF SCRAP LUMBER, PINE BRANCHES, PAPER OR CARDBOARD BOXES...
-
Page 4: Specifications
SPECIFICATIONS PIPE 1" AIRSPACE TO COMBUSTIBLE GAS LINE MATERIAL KNOCK OUTS RIGHT SIDE ELECTRICAL OUTLET STARTER NO COMBUSTIBLE SECTION MATERIAL BELOW TOP SPACERS 0" TO NO COMBUSTIBLE TOP SPACERS " MATERIAL ON FACE " " " 12" AIR KIT COMBUSTIBLE KNOCK OUT WALL BOARD 3/4"... -
Page 5: Fireplace Installation
FIREPLACE INSTALLATION SELECTING LOCATION To determine safest and most efficient location for fireplace, you must take into consideration the following guidelines: 2 x 4 Header 1. Location must allow for proper clearances (see Figures 1 and 2). Turned 2. Consider a location where fireplace will not be affected by drafts, Flat air conditioning ducts, windows or doors. - Page 6 FIREPLACE INSTALLATION Continued *Note: Drawing Not To Scale WARNING: Hearth extension is to be installed only as shown in Figure 3. Combustible " Ref. Material Safe Zone For 6" Projection of Ref. Combustible 33° Seal Gap Materials Fireplace Front Non Combustible 3"...
-
Page 7: Venting Installation
FIREPLACE INSTALLATION Continued VENTING INSTALLATION OPTIONAL OUTSIDE AIR KIT (MODEL AK4/AK4F) FAN/BLOWER KIT ASSEMBLY (FOR CIRCULATING MODELS ONLY) Fan or blower kit is optional with this fireplace (for circulating mod- Installation of outside air kit should be performed during rough fram- els only). - Page 8 VENTING INSTALLATION Continued ASSEMBLY AND INSTALLATION OF DOUBLE WALL CHIMNEY WARNING: The opening in collar around chimney SYSTEM at top of fireplace must not be obstructed. Never use SS-8DM starter section must be installed first. blown insulation to fill chimney enclosure Each double wall chimney section consists of a galvanized outer pipe, a stainless steel inner flue pipe and a wire spacer.
- Page 9 VENTING INSTALLATION Continued 30E-8DM 30E-8DM Return Elbow Return Elbow 30E-12DMO-8DMR Return Elbow 30E-8DM 30E-8DM Offset Elbow 6' Max. 6' Max. Offset Elbow Ceiling Support Pipe 6' Max. 30E-12DMO-8DMR 30E-12DMO-8DMR 12S-8DM Return Elbow Return Elbow 8 DM Pipe 6' Max. 8 DM Pipe Starter Starter Section...
- Page 10 VENTING INSTALLATION Continued OFFSET CHART WITH TRANSITION PIPE OFFSET RISE OFFSET/ TRANSITION CHIMNEY LENGTH RETURN PIPE 12" 18" 36" 48" ELBOW " " 19" 41" 22" " " " " " " Screws " 65" " " " " " " " " " " "...
- Page 11 VENTING INSTALLATION Continued If area above is an attic or insulated area, install firestop above framed hole. Minimum Measurements " (48.3 cm) 30" 1" (76.2 cm) (2.54 1" (2.54 cm) 1" (2.54 Figure 14 - Firestop Spacer with Attic Space Above Ceiling IMPORTANT NOTICE Opening "A"...
- Page 12 VENTING INSTALLATION Continued Storm Collar Installation (SC1) CHASE INSTALLATIONS Place storm collar over pipe and slide down until it is snug against Instructions for chase installations are included with chase style ter- open edge of flashing (see Figure 17). Use SC1 for all round termina- mination chosen.
-
Page 13: Optional Gas Line Installation
VENTING INSTALLATION Continued EFFECTIVE HEIGHT EFFECTIVE HEIGHT OF TERMINATION CAP OF TERMINATION CAP MIN. HEIGHT OF 22 FT. (WITH 2 ELBOW SETS) MAX. HEIGHT OF 50 FT. MAX. HEIGHT 50 FT. (ANY SYSTEM) EFFECTIVE HEIGHT EFFECTIVE HEIGHT OF TERMINATION CAP OF TERMINATION CAP STARTER STARTER... -
Page 14: Operation And Maintenance
OPTIONAL GAS LINE INSTALLATION Continued OPERATION AND MAINTENANCE If you install a decorative gas appliance (vented gas log), decorative GLASS DOORS gas appliance must comply with the Standard for Decorative Gas Glass doors are optional with this fireplace. When fireplace is in Appliance for Installation in Solid Fuel Burning Fireplaces, ANSI operation, doors must be fully opened or fully closed position only Z21.60/CSA 2.26 or Z21.84 and shall also be installed in accordance... -
Page 15: Replacement Parts
REPLACEMENT PARTS OPERATION AND MAINTENANCE Continued Note: Use only original replacement parts. Cleaning Glass This will protect your warranty coverage for parts replaced under Clean glass with any commercial glass cleaner or soap and water. warranty. Do not use any abrasive material to clean the glass. Do not clean Contact authorized dealers of this product. -
Page 16: Parts
PARTS WOOD BURNING FIREPLACE MODELS: MODEL NO. CATALOG NO. WRT3042RS F0653 WRT3042RSI F0654 WRT3042RH F0655 WCT3042RS F0656 WCT3042RSI F0657 WCT3042RH F0658 WRT3042WS F0665 WRT3042WSI F0666 WRT3042WH F0667 WCT3042WS F0668 WCT3042WSI F0669 WCT3042WH F0670 Superiorfireplaces.US.com 126622-01D... - Page 17 This list contains replaceable parts used in your fireplace. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. WRT3042RS WCT3042RS WRT3042WS...
-
Page 18: Accessories
Right - 107814-01 Bottom Rear - 108172-01 Rear - 107816-01 Bottom Front - 108173-01 Bottom Rear - 107818-01 Bottom Front - 107820-01 WRT3042RH(F0658)/WCT3042RH(F0655) WRT3042RS(F0653)/WRT3042RSI(F0654) Left - 108169-02 WCT3042RS(F0656)/WCT3042RSI(F0657) Right - 108170-02 Left - 107812-02 Rear - 108171-02 Right - 107814-02... - Page 19 ACCESSORIES Continued BLOWER KIT - MESH ROUND TOP TERMINATIONS RT-8DM, TR-8HT, RTL-8DM AND RTL-8HT 1" FIRESTOP SPACER 3600FS-8DM-1 MESH ROUND TOP TERMINATIONS WITH SLIP SECTION RTT-8DM, RTT-8HT, RTTL-8DM AND RTTL-8HT 38FST FIRESTOP THIMBLE 8" FST30 FIRESTOP THIMBLE,8",30 DEGREES SQUARE TOP TERMINATION WITH LOUVERS ET-8DM, ET-8HT SQUARE TOP TERMINATION WITH LOUVERS AND SLIP OUTSIDE AIR KIT FOR SIDE WALL INSTALLATION...
- Page 20 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. P126622 01 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 1-800-655-2008 Printed in U.S.A.
