Summary of Contents for Sea-doo GSX Limited 5625

  • Page 1 www.SeaDooManuals.net...
  • Page 2 CAUTION The GSX Limited model features a 947 engine type which requires the use of BOMBARDIER-ROTAX FORMULA XP-S SYNTHETIC INJECTION OIL (P/N 413 710 500) (or the equivalent synthetic oil). The use of any other non-synthetic type oil may cause severe damage to internal parts of the engine.
  • Page 3: Location Of The Important Labels

    SEA-DOO GSX LIMITED (5625) OPERATOR’S GUIDE SUPPLEMENT____________________________ NOTE: This supplement must be used in conjunction with the 1997 Sea-Doo Operator’s Guide (P/N 219 000 059), which contains all the general information. When specific models are listed, refer to the information regarding the GSX mod-...
  • Page 4 "THIS BOAT IS NOT REQUIRED TO COMPLY WITH THE FOLLOWING U.S. COAST GUARD SAFETY STANDARDS IN EFFECT ON THE DATE OF CERTIFICATION: Safe Loading Fuel System - CAUTION Flotation Display of Capacity Information Powered Ventilation USE ONLY BOMBARDIER ROTAX SYNTHETIC AS AUTHORIZED BY U.S.
  • Page 5: Engine Identification Number

    – low oil – low battery – hi temp – fuel level – VTS indicator NOTE: Refer to the 1997 Sea-Doo Op- erator’s Guide for an overview of the Info Center gauge operation. F06D15Y 1. Engine Identification Number PAGE 46 and 47...
  • Page 6: Steering And Throttle Systems

    The PTO flywheel and seal carrier of If the starter does not operate, check the drive system should be lubricated the 5 A fuse. with SEA-DOO synthetic grease every If the variable trim system does not 10 operating hours. operate, check the 7.5 A fuse.
  • Page 7 F06H0SY TYPICAL — MULTI-PURPOSE ELECTRONIC F06H0TY MODULE 1. Fuse cover REAR ELECTRICAL BOX OPENED 1. Fuse holder To access the 15 A fuse in the rear electrical box, remove seat and vent Unclip and pull out fuse holder to tube support. check fuse condition.
  • Page 8: Additional Recommended Protection

    PAGE 80 Insert a funnel into the hose and pour about 1 liter (1 quart) of antifreeze so- lution mixed with water. Additional Recommended Protection CAUTION Proceed as follows for adding anti- freeze solution in the engine: Always use antifreeze specially formulated for aluminum en- Install a hose pincher to engine drain gines.
  • Page 9: Specifications

    SPECIFICATIONS ________________________________ ENGINE GSX LIMITED (5625) Engine type Bombardier-Rotax 947, 2-stroke Induction type Reed valves Exhaust system Water cooled/water injected with regulator Exhaust valve Rotax Adjustable Variable Exhaust (R.A.V.E.) Lubrication Type Oil injection Oil type BOMBARDIER ROTAX FORMULA XP-S SYNTHETIC INJECTION OIL (or equivalent synthetic oil) Number of cylinders Displacement...
  • Page 10 Bombardier Formula pump Jet pump type Axial flow, single stage Transmission Direct drive Impeller shaft reservoir oil type SEA-DOO jet pump synthetic polyolester oil 75W90 GL5 Pivoting angle of direction (nozzle) ~ 20° Pivoting angle of variable trim system ± 8°...
  • Page 11 www.SeaDooManuals.net...
