Battery Removal/Replacement - Alexor PC9155-433/868 Installation Manual

PC9155 Wireless Alarm Panel
Trouble [7] Wireless Device Low Battery
1st press - Wireless Zones
2nd press - Wireless Keys
3rd press - Wireless Keypads
4th press - Wireless Sirens
5th press - Proximity Tags
Trouble [8] Loss of Clock
Loss of Time & Date

6.5 Battery Removal/Replacement

Disconnect AC power and battery before proceeding.
Removal:
(1) Disconnect battery cable from the battery terminals.
(2) Remove GPRS/Ethernet module if present.
(3) Depress the right battery retaining bracket, simultaneously lift battery free of retaining clip.
(4) Slide battery up and right to clear the left retaining clip.
(5) Dispose of battery in accordance with local regulations.
Replacement:
(1) Remove terminal protection from battery.
(2) Install battery cable on battery spade lug terminals
i
Ensure red cable is connected to the positive (+) terminal and the black cable is connected to the negative (-) terminal.
(3) Slide left side of battery under the left battery retaining bracket.
(4) Insert a flat head screwdriver between the battery and right retaining bracket. Lever the right retaining bracket to the right while pressing
the battery firmly in place.
(5) If required route battery cable through wire guides and connect to the PC9155 terminal board.
Press [7] to scroll through specific devices with a Low Battery Trouble
One or more wireless devices has a low
battery.
NOTE: The event is not logged to the
event buffer until the wireless device low
battery delay time expires.
Program section [377].
The main panel internal clock is not set.
.
Replace Battery
• Verify zone operation.
• Verify that tamper and low battery condition is cleared and reported.
A flashing Trouble LED on a keypad indicates that it's battery is low.
To determine which indoor siren is in low battery, press the test button.
If no test indications are sounded, replace the batteries.
To determine which outdoor siren is in low battery, remove the battery
and reconnect it. If the strobe doesn't flash, replace the battery.
If a proximity tag is in low battery, the tag must be deleted and replaced
before the trouble will be cleared from [*][2].
NOTE: Replacing batteries will cause a tamper condition. Replacing the
cover will clear the tamper causing the associated reporting codes to be
sent to the central station.
To program the time and date:
• Enter [ ][6][Master Code] then press [1].
• Enter the time and date (in military) using the following format:
HH:MM MM/DD/YY
Example: For 6:00 pm, Nov. 30, 2008
Enter: [18] [00] [11] [30] [08]
6-5
