The model and warranty numbers are located on the top of the unit. Record the warranty (serial) number in the space provided below. Refer to these numbers whenever you call upon your Blaupunkt dealer regarding this product. Warranty Number Attach Sales Receipt Here...
Features Congratulations on your purchase of this Blaupunkt Cassette Receiver. Its Codem III-US FM/AM Tuner and Autoreverse Cassette Tape Player mechanism provide the ultimate in sound reproduction. The Travelstore Feature allows you to automatically store stations onto all 5 preset...
Detachable Face Detaching & Attaching the Face: The face of this unit can be detached and taken with you to prevent it from being stolen. Detaching the Face: Press the REL (Release) Button and detach the face by gently pulling it off as illustrated. Note: Do not pull it straight out from the chassis.
GENERAL RECOMMENDATIONS If you’re not confident that you can install the unit correctly, have it installed by a qualified Blaupunkt installation technician. Use this unit only with negative ground 12 Volt (11-16 Volt) direct current (DC). Be sure to detach the faceplate before you start to connect or install the unit.
Page 7
REAR OF UNI ANTENNA MOTOR /&??i TRIGGER SWITCH o LEFT FRONT RIGHT FRONT SPEAKER SPEAKER GREEN GREEN W/BLACK VIOLET W/BLACK STRIPE STRIPE VIOLET LEFT REAR RIGHT REAR SPEAKER SPEAKER...
Page 8
The illustration below shows a typical installation, however, you may need to adjust the installation, depending on the unit. If you have questions or need additional installation hardware, consult your Blaupunkt dealer. Make sure the unit is firmly anchored (preferably at both front and back) and does not vibrate.
Page 9
You may have difficulty mounting this unit in some Japanese cars that have IS0 mounting features (side-bracket mounting systems). In this case, consult your Blaupunkt dealer. Run a blade along the slits on the back of the front trim ring, unscrew the two side screws, and separate it from the unit.
Maintenance Removing the Unit Use the Release Keys as shown below. Keep them in a safe place in case you need them in the future. Fuse Replacement When replacing the fuse, be sure to use one with the correct amperage, which will be stated on the fuse case.
Specifications Power Specifications Audio Power Total Harmonic Distortion: 13 watts per channel minimum continuous average Output and output into 4 ohms, 4 channels driven, from 30-l 5,000 Hz with no more than 1% total harmonic distortion. Other Specifications Tuner 87.5 - 107.9 MHz Tuning Range: 10.7 MHz Intermediate Frequency:...
Page 12
Location of Controls 14 15 16 Button 1. REL (Release) Button Volume 2. PWR (Power) Button Bass Source (and Radio Band) Select Treble 4. Cassette Eject Balance Right 5. Mute/Audio Button/Clock Adjust:00 Fade to Rear SCA (Scan) TS (Travelstore) 14. A Button LD (Loudness)/ SENS (Tuning Sensitivity) Seek and Manual Tuning 8.
Release for Detachable Faceplate Push REL to detach face. Already-inserted cassette remains in unit..Current settings and source mode are stored. If power was not switched off before face removed, unit will automatically power- on when face is reattached. Power (PWR) On/Off When ignition on, press PWR or insert a cassette to turn unit on.
AUTOREVERSE HIGH POWER SENS TUNE AUDIO BLAUWNKT Loudness (LD) Press LD to increase sound of low and high frequencies. LOUD icon appears. To cancel, press LD again. Radio Operation Last Station Memory Each FM bank and AM band has its own last station memory which holds last-tuned frequency for that band or bank irrespective of whether that frequency is stored into a preset.
beep acknowledges storage. Preset Station Selection Press desired Preset Button. Travelstore This feature allows you to automatically store stations onto all 5 preset buttons and is especially useful when traveling outside your normal listening area. In any FM Bank, press SCA/TS for 2 seconds to activate FM Travelstore.
Travel Store feature does not complete Not enough broadcast frequencies are receivable. storing of six stations. If the above mentioned solutions do not help to improve the situation, consult your nearest Blaupunkt dealer or in the United States call l-800-266-2528.
Page 17
Bosch Group German Headquarters: Blaupunkt-Werke GmbH Postfach 77 77 77 D-31 132 Hildesheim Germany Robert Bosch Corporation Sales Group - B l a u p u n k t D i v i s i o n 2800 South 25th Avenue, Broadview, Illinois 60153 Robert Bosch, SA., DE, C.
