  • Page 1 Radio / Cassette Santiago CR 87 Operating instructions...
  • Page 2: Table Of Contents

    Instructions – General Operation ... 27 Audio Operation ... 28 Radio Operation ... 29 Cassette Tape Player Operation ... 30 Auxiliary Input Jack (cable connection with ø 3.5 mm pigtail coupler) ... 31 Troubleshooting Guide ... 32 Blaupunkt Telephone Hotline ... 32 Specifications ... 33...
  • Page 3: Features

    - Detachable Wire Harness - Snap-In DIN Sleeve and Mounting Hardware Your unit’s detachable front faceplate makes the unit useless to would-be thieves. Designed, Engineered and Manufactured By Blaupunkt. Traffic Safety and Precautions • Do not adjust your unit in difficult driving conditions that demand your full attention.
  • Page 4: Detachable Face (Release Panel)

    Detachable Face (Release Panel) Detaching and Attaching the Face: The face of this unit can be detached and taken with you to prevent it from being stolen. Detaching the Face: Press the REL (Release) Button and detach the face by gently pulling it off as illustrated. Note: Do not pull it straight out from the chassis.
  • Page 5: Electrical Connections

    Carefully follow all instructions. General Recommendations • If you’re not confident that you can install the unit correctly, have it installed by a qualified Blaupunkt installation technician. • Use this unit only with negative ground 12 Volt (11-16 Volt) direct current (DC). •...
  • Page 6: Speaker Connections

    Speaker Connections Attach the faceplate and test the unit. Once the connections have been successfully made, you can begin to mount the unit. Speaker Connections...
  • Page 7: Installation

    The illustration below shows a typical installation, however, you may need to adjust the installation, depending on the unit. If you have questions or need additional installation hardware, consult your Blaupunkt dealer. • Make sure the unit is firmly anchored and does not vibrate.
  • Page 8 You may have difficulty mounting this unit in some Japanese cars that have ISO mounting features. In this case, consult your Blaupunkt dealer. 1. Run a blade along the slits on the back of the front trim ring, unscrew the two side screws, and separate it from the unit.
  • Page 9: Maintenance

    Maintenance Removing the Unit Use the Release Keys as shown below. Keep them in a safe place in case you need them in the future. Fuse Replacement When replacing the fuse, be sure to use one with the correct amperage, which will be stated on the fuse case.
  • Page 10: Location Of Controls

    Location of Controls REL (Release) – Detaching Faceplate ON (Power) – Power On/Off – Source and Radio Band Select – Cassette Eject – Mute AUDIO – Audio – Scan – Travelstore – Loudness SENS – Tuning Sensitivity Cassette Insertion Slot –...
  • Page 11: Instructions - General Operation

    Instructions – General Operation See Traffic Safety and Precautions on page 19. “Press” means a momentary press of less than 1/2 second. All presses requiring more than 1/2 second are followed by beep. “Time Out” When additional button presses are anticipated to complete a procedure, the unit will automatically exit the procedure after 4 seconds of inactivity.
  • Page 12: Audio Operation

    Audio Operation Volume Control Buttons Press + and – to increase/decrease volume from 0 to 63. Adjustable Maximum Turn-On Volume Press and hold the ON Button for more than two seconds. The unit turns off and the turn-on volume level is memorized. Mute Press to temporarily reduce volume.
  • Page 13: Radio Operation

    Radio Operation Selecting Bands Press SRC as needed to access FM1, FM2, FM3/FMT, AM/AMT banks. Tuning Sensitivity Press SENS for more that 2 seconds to switch between lo and dx search sensitivity. In general, set SENS to “lo” when in metropolitan areas or where stations tend to be strong and local, and to “dx”...
  • Page 14: Cassette Tape Player Operation

    Cassette Tape Player Operation Tape Playback: • Insert cassette into Cassette Door. (Note: Make sure that the side of the cassette exposed is facing right.) • If ignition switch is already in “on” or accessory position, insertion of cassette will turn unit on.
  • Page 15: Auxiliary Input Jack (Cable Connection With Ø 3.5 Mm Pigtail Coupler)

    Auxiliary Input Jack (cable connection with ø 3.5 mm pigtail coupler) Connect other audio equipment, such as a portable CD or DAT player, through a 3.5 mm pigtail connector. Press SRC until “InP” appears. Adjust volume, bass, and treble settings through the head unit.
  • Page 16: Troubleshooting Guide

    Address of the next service centre in your vicinity (only for Germany) If you would like to know the address of the next Blaupunkt service centre of your area without having our service list at hand: Find out your area code.
  • Page 17: Specifications

    Specifications Audio Power Specifications Power Output and Total Harmonic Distortion: 13 watts per channel minimum continuous average output into 4 ohms, 4 channels driven, from 35-15 000 Hz. Other Specifications Tuner Tuning Range: FM Mono Sensitivity: Signal-to-Noise Ratio: Frequency Response: Tuning Range: Signal-to-Noise Ratio: Frequency Response:...
  • Page 18 Blaupunkt-Werke GmbH Bosch Gruppe 02/97 K7/VKD 8 622 400 896...
